Ozito PIM-300 Instruction Manual

Ozito PIM-300 Instruction Manual

Advertisement

Quick Links

POWER
INVERTER
12V 300W
INSTRUCTION MANUAL

SPECIFICATIONS

Input Voltage:
12V DC
Output Voltage:
240V ~ 50Hz
Output Power:
300W
Peak Output Power:
600W (0.1s)
USB Output:
5V, 2A
Low Voltage Warning:
11V DC
Low Voltage Cut-off:
10.5V DC
Overload Cut-off:
15V DC
Operating Temp.:
0° to 40°C
40A
Battery Min. Capacity: 25Ah
Weight:
0.8kg
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY
YOU MUST RETURN THE PRODUCT TO YOUR NEAREST
BUNNINGS WAREHOUSE WITH YOUR BUNNINGS
REGISTER RECEIPT. PRIOR TO RETURNING YOUR
PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR
CUSTOMER SERVICE HELPLINE:
Australia: 1800 069 486
New Zealand: 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE
THE MODEL NUMBER AND DATE OF PURCHASE
AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE
WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
Ozito Industries Pty. Ltd.
25 Fox Drive, Dandenong South, Victoria, Australia 3175.
12V
MODIFIED SINEWAVE POWER
INVERTER
300W

WARRANTY

The benefits provided under this warranty are in addition to other rights and remedies which
are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this warranty,
however, where you have suffered any additional direct loss as a result of a defective product
you may be able to claim such expenses by contacting our customer service helpline above.
3 YEAR REPLACEMENT WARRANTY*
Your product is guaranteed for a period of 36 months from the original date of purchase. If
a product is defective it will be replaced in accordance with the terms of this warranty. Warranty
excludes consumable parts, for example: valve adapters and accessories.
*This product is intended for DIY use only and replacement warranty covers domestic use.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other than that specified on the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse, accidents
or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
STANDARD EQUIPMENT
12V
MODIFIED SINEWAVE POWER
INVERTER
300W
Power Inverter
2 x Alligator Clamp Leads & 2 x
Terminal Covers
PIM-300
0822

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIM-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ozito PIM-300

  • Page 1 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. Ozito Industries Pty. Ltd. 25 Fox Drive, Dandenong South, Victoria, Australia 3175. 0822...
  • Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION POWER INVERTER 1. ASSEMBLY 1. AC Socket 6. Positive Terminal Cover 2. Power Switch 7. Ring Connector 3. Indicator LED 8. Negative Terminal Cover WARNING! ENSURE THE TOOL IS TURNED OFF AND 4. USB Socket 9.
  • Page 3 2. CONNECTING THE POWER INVERTER WARNING! ALWAYS CONNECT THE CLAMPS TO THE WARNING! DO NOT INSERT FOREIGN OBJECTS IN TO POSITIVE BATTERY TERMINALS FIRST. THE POWER INVERTER’S AC OUTLET, FAN OR VENT OPENINGS. WARNING! ONLY USE WITH CLASS II EQUIPMENT. WARNING! THE POWER INVERTER GENERATES THE SAME POTENTIALLY LETHAL AC POWER AS A NORMAL...
  • Page 4 If the interior temperature of the power inverter exceeds 60°C, the unit will automatically shut off to protect the circuitry. If the thermal protection activates, switch off the power inverter and allow it to cool completely before restarting the unit. 10A240V AC PIM-300...
  • Page 5 Australia 1800 069 486 Note: Ozito Industries will not be responsible for any damage or New Zealand 0508 069 486 injuries caused by the repair of the tool by an unauthorised person E-mail: enquiries@ozito.com.au...
  • Page 6 ELECTRICAL SAFETY WARNING! When using mains-powered tools, basic safety precautions, including the following, should before operating the tool. always be followed to reduce risk of fire, electric shock, personal injury and material damage. Save these instructions and other documents supplied with this tool for future reference. Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, POWER INVERTER SAFETY WARNINGS The appliance is not to be used by persons (including children) with reduced physical, sensory or...
