Analog (Jp1); Digital (Jp2) - Arduino Nano ESP32 Product Reference Manual

12.1 Analog (JP1)

Pin Function
1 SCK
2 +3V3
3 BOOT0
4 A0
5 A1
6 A2
7 A3
8 A4
9 A5
10 A6
11 A7
12 VUSB
13 BOOT1
14 GND
15 VIN

12.2 Digital (JP2)

Pin Function
1 D12 / CIPO*
2 D11 / COPI*
3 D10
4 D9
5 D8
6 D7
7 D6
8 D5
9 D4
10 D3
11 D2
12 GND
13 RST
14 D1/RX
15 D0/TX
*CIPO/COPI replaces the MISO/MOSI terminology.
15 / 20
Type Description
NC Serial Clock
Power +3V3 Power Rail
Mode Board Reset 0
Analog Analog input 0
Analog Analog input 1
Analog Analog input 2
Analog Analog input 3
Analog Analog input 4 / I²C Serial Datal (SDA)
Analog Analog input 5 / I²C Serial Clock (SCL)
Analog Analog input 6
Analog Analog input 7
Power USB power (5V)
Mode Board Reset 1
Power Ground
Power Voltage Input
Type
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Power
Internal
Digital
Digital
Arduino® Nano ESP32
Arduino® Nano ESP32
Description
Controller In Peripheral Out
Controller Out Peripheral In
Chip Select
GPIO 9
GPIO 8
GPIO 7
GPIO 6
GPIO 5
GPIO 4
GPIO 3
GPIO 2
Ground
Reset
GPIO 4 / Serial 0 Receiver (RX)
GPIO 3 / Serial 0 Transmitter (TX)
Modified: 17/07/2023
