Samsung SCC-B5313 Specifications

SCC-B5313
1/3" High Resolution, Color, DNR, Fixed Dome
Camera
Dimensions (unit : in)
Front/Rear Panel
Summary
The SCC-B5313 fixed dome camera is the perfect choice for low profile
surveillance camera applications.
The SCC-B5313 features a 1/3" Super HAD CCD imager with 540TV
Lines of resolution and electronic Day/Night capability. The camera oper-
ates as a color camera in daylight and in Black and White in nighttime or
low light. It provides noiseless clarity by using Auto Gain Control (AGC)
and Digital Noise Reduction (DNR) technology.
Features
• 1/3 inch IT Super HAD CCD
• 540TV Lines Resolution
• Minimum scene illumination: 0.002 lux @ 15 IRE, Sens-Up x128 (F2.0)
• 3.0 mm Fixed Lens
• Horizontal & Vertical Image Mirroring
• DSP (Digital Signal Processing)
• Electronic Day & Night Function
• Digital Noise Reduction (DNR)
• Dynamic Defect Reduction
• 12 VDC / AC24V (60Hz)
• 3 Axis Dome Design
• Built-In ground fault isolation
3.07
ø4.1
SAMSUNG | GVI Security • Toll Free: 888-595-2288 • Fax: 972-245-7333
This product specifications and manual are also available in pdf format at www.gviss.com
The information is subject to change without notice • v2.6.09
3 Axis
The camera rotates inside its dome and moves up to 340o horizontally and up to 90o
vertically. It can easily be installed in difficult areas such as a wall or an inclined surface
where it is difficult to install a surveillance camera.
Wall Surface Ceiling
Digital Noise Reduction (DNR)
SAMSUNG Electronics' exclusive Digital Noise Reduction (DNR) provides the
clearest images.
Competitor DNR SAMSUNG DNR

Specifications

Image Device
Pixels
Scanning System
Min. Scene Illumination Color, B/W
Functions Day & Night
Line Lock
LSS
H/V Reverse
BLC
AGC
D/N
AWB
Resolution Horizontal
Video Output
Lens Focal Length
Viewing: Horizontal
Angle: Vertical
PAN / TILT
Environmental Operating Temperature
Conditions Humidity
Power Requirement
Power Consumption
Weight
Dimensions (W x H)
Body Color White
Inclined Plane
Super-HAD IT CCD
Total: 811 (H) x 508 (V)
Effective: 768(H) x 494(V)
525 Line, 2:1 Interlace
0.002 Lux @ 15IRE, Sens-Up
x128 (F2.0)
1 Lux @ 50IRE (F2.0)
Yes (Electronic)
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
540 TV Lines
VBS 1.0Vp-p (75Ω, comp.)
3.0mm
92°
72°
0°~340° / 0°~90°, Manual
14º ~ 122ºF (-10° ~ 50°C)
Within 90% RH
AC 24V (60Hz), DC 12V, Dual
1.6W
0.42 lb / 190 g
4.01 x 3.07 in / 102 x 78 mm
