- Page 1 Mareli Systems ONYX HYDRO 12/18/24/30 Pellet stove Assembly and exploitation manual e present stove is designed and manufactured according to Standards: BNS (Bulgarian National Standard) EN 14785-2006...
- Page 2 Mareli Systems Observing the prescriptions of the present manual is in the user’s favour and is one of the warranty conditions. Compliance with this instruction is in the interest of the con- sumer and one of the warranty terms. INSTRUCTIONS FOR SECURITY: •...
- Page 3 Mareli Systems 1. PURPOSE e stove is purposed to heat domestic and public premises by the means of pellets. e stove is equipped with a steel water jacket designed for heating systems with water temperature up to 90º C at a maximum super pressure up to 0,15 Mpa. Tests are run at pressure of 0,3 Mpa.
- Page 4 Mareli Systems 2. TECHNICAL DATA Maximum output Heated area m³ Height H 1047 1047 1127 1127 1177 Width W Depth D Pellet bunker volume Fresh air pipe ф mm Exhaust gas pipe ф mm Weight Fuel type Pellets Pellets Pellets...
- Page 5 Mareli Systems 3. ASSEMBLY 3.1 General conditions. All national, regional and European requirements for safe operation of the appliance must be respected during installation and operation. Prior to installation, load capacity of the place where the stove will be intended must be ensured.
-
Page 6: Connection To Chimney
Mareli Systems Mareli Systems CHECK ITEMS BEFORE INSTALLATION Chimney exit Chimney Connection to chimney Connection to the stove Security e chimney distances revision door Inlet air e oor... - Page 7 • “Mareli Systems” provides a warranty and out of warranty service and replacement of the water jackets. • e warranty is not valid in case of a stove with a swollen water jacket which is a result of pressure increase in the system and improper connecting.
- Page 8 Mareli Systems 3.3 Assembly of the duct components. Duct components and pipes For the assembly of the duct pipes the use of non- ammable materials, resistant to the ammable products and condensation is obligatory. e assembly must be performed in such a manner so it guarantees the airtight sealing and prevents condensation.
- Page 9 Mareli Systems 3.4 Types of connection to the chimney Chimney exit Moisture channel Chimney ermal insulation External wall Connection to chimney Flue gas connection Heat generator e chimney revision door “T” connection...
- Page 10 Mareli Systems 3.5 Air intake Suction pipe or air intake is placed in the back and has a circular section with a diameter of 48 mm. e combustion air can be aspirated: • From the camera, as long as it is near an air intake communicating with the outside wall having a minimum area of 100 cm2, properly positioned and protected by a grid.
- Page 11 Mareli Systems Cleaning the glass Use an non-abrasive cloth Cleaning the pellet bunker Combustion chamber Clean the ue gas outlet Clean the ashtray...
-
Page 12: Maintenance Program
Mareli Systems Maintenance program At each Weekly Twice Annual ignition per season Combustion chamber Clean the ashtray Glass e Door Clean the ue gas outlet Door seals Chimney 5 Safety and unexpected risks Terms of danger may arise in the following cases: •... - Page 13 Mareli Systems K400 TOUCH SCREEN DISPLAY 1. HOMEPAGE Date & Time Errors Code 11:24 Fri 14 Oct 2016 Er.01 21° Main Temperature IGNITION Functioning State 65° Main ermostat ON/OFF Settings Display Info Chrono...
- Page 14 Mareli Systems Main Commands In order to go to Homepage 2 a horizontal swipe must be performed to the right side of the screen. 12:18 Fri 14 Oct 2016 Er.01 Igniter Auger Pump 1 Pump 2 Pump 3 Aux1 Aux1...
-
Page 15: Error List
Mareli Systems Quick visualization of the system main function 2. ERROR LIST 12:18 Fri 14 Oct 2016 Blocking or non-blocking error Er.01 21° is highlighted with a and the related error code. When pressed the error window opens IGNITION 65°... -
Page 16: Main Commands
Mareli Systems IGNITION Blocking / Removing Error 65° 4. MAIN COMMANDS 11:24 Ven 14 Ott 2016 Er.01 ON/OFF Menu 21° Screen image : Swipe to Ignite • System power ON • System power OFF IGNITION • Alarms reset 65° 11:24 Ven 14 Ott 2016 Er.01... - Page 17 IGNITION Mareli Systems 65° 5. CHRONO 12:18 12:18 Ven 14 Ott 2016 Ven 14 Ott 2016 Er52 Er52 Chrono - Daily CHRONO 22° 22° 22° 22° 22° 22° 22° 22° 22° 22° 22° 22° 22° 22° 22° 22° 22° 22°...
- Page 18 Mareli Systems 5. INTERNAL MENU STRUCTURE From the display Menu the user can access the panel settings and select one of 24 languages Brightness. Minimum brightness: this function allows you to choose the minimum brightness level which the device automatically sets to a er 30 sec. of inactivity.
- Page 19 V2: Pump 1 ON Lack of pellet Mareli Systems R: Igniter ON Local Room Thermostat reached Sanitary water demand Aux2: Pump 2 ON ALARMS Er01 - Security Error High Voltage 1. It may also intervene with the system o ;...
- Page 20 Mareli Systems ONYX HYDRO (MB250) FAN ENCODER N.O. TURBULATOR CLEANING MOTOR POWER CABLE COMBUSTION PROGRAMMER MOTOR FOR CLEANING MECHANISM PUMP 1 IGNITER SENSOR OF WATER PRESSURE WATER OVERHEATING PROTECTION PROTECTION RETURN FLAME BUFFER PROBE AUGER BOILER PROBE 31 GND 29 GND N.C.
- Page 21 Mareli Systems ONYX HYDRO (NG21) LINEA...
- Page 22 Mareli Systems...
- Page 24 MARELI SYSTEMS disclaims any responsibility for possible inaccuracies contained in this manu- al if they are due to printing or transcription errors. We reserve the right to make any change that appears to be necessary or useful without harm the essential characteristics.
