- Page 1 Mareli Systems AURORA SLIM Pellet stove Assembly and exploitation manual e present stove is designed and manufactured according to Standards: BNS (Bulgarian National Standard) EN 14785-2006...
-
Page 2: Safe Distances
Mareli Systems Observing the prescriptions of the present manual is in the user’s favour and is one of the warranty conditions. Compliance with this instruction is in the interest of the con- sumer and one of the warranty terms. INSTRUCTIONS FOR SECURITY: •... - Page 3 Mareli Systems 1. PURPOSE e stove is purposed to heat domestic and public premises by the means of pellets. stove is designed and manufactured to work with A-class pellets only ( DIN plus 51731 ) with the following characteristics: • Material 100% pure conifer or broad-leaf wood;...
-
Page 4: Technical Data
Mareli Systems 2. TECHNICAL DATA Maximum output Heated area m³ Height H Width W Depth D Pellet bunker volume 12.5 Fresh air pipe ф mm Air Duct pipe ф mm Exhaust gas pipe ф mm Weight Fuel type Pellets Φ6-Φ8... - Page 5 Mareli Systems 3. ASSEMBLY 3.1 General conditions. All national, regional and European requirements for safe operation of the appliance must be respected during installation and operation. Prior to installation, load capacity of the place where the stove will be intended must be ensured.
-
Page 6: Connection To Chimney
Mareli Systems Mareli Systems CHECK ITEMS BEFORE INSTALLATION Chimney exit Chimney Connection to chimney Connection to the stove Security e chimney distances revision door Inlet air e oor... - Page 7 Mareli Systems 3.3 Assembly of the duct components. Duct components and pipes For the assembly of the duct pipes the use of non- ammable materials, resistant to the ammable products and condensation is obligatory. e assembly must be performed in such a manner so it guarantees the airtight sealing and prevents condensation.
- Page 8 Mareli Systems 3.4 Types of connection to the chimney Chimney exit Moisture channel Chimney ermal insulation External wall Connection to chimney Flue gas connection Heat generator e chimney revision door “T” connection...
- Page 9 Mareli Systems 3.5 Air intake Suction pipe or air intake is placed in the back and has a circular section with a diameter of 48 mm. e combustion air can be aspirated: • From the camera, as long as it is near an air intake communicating with the outside wall hav- ing a minimum area of 100 cm2, properly positioned and protected by a grid.
- Page 10 Mareli Systems Cleaning the glass Use an non-abrasive cloth Cleaning the pellet bunker...
-
Page 11: Combustion Chamber
Mareli Systems Clean the ue gas outlet Combustion chamber Clean the ashtray... - Page 12 Mareli Systems cleaning CLEANING THE INTERNAL HEAT EXCHANGER Open the stove door. Remove the upper and lower grille.
- Page 13 Mareli Systems Remove all screws on the right side of the door to release the front panel. Remove the front cover.
- Page 14 Mareli Systems Remove the outer heat exchanger cover Remove the inner heat exchanger cover...
-
Page 15: Heat Exchanger
Mareli Systems Heat exchanger Maintenance program At each Weekly Twice Annual ignition per season Combustion chamber Clean the ashtray Glass e Door Clean the ue gas outlet Door seals Chimney... - Page 16 Mareli Systems 5 Safety and unexpected risks Terms of danger may arise in the following cases: • Automated pellet stove is used incorrectly; • e unit is installed by unquali ed personnel; • e safety instructions described in this management are not met;...
- Page 17 Mareli Systems Control Panel: Use and Functions CLICK LONG PRESSURE Ignition / Extinguishing / Visualisations / Exit Menu Block reset Combustion Power modify / Manual pellet loading Save data ermostat modify (+) / Pellet loading correction Increase data ermostat modify (-) /...
- Page 18 Mareli Systems MESSAGES D e s c r i p t i o n C o d e Sond Anomaly of the probes checking, during Check Up phase. Room temperature greater than 50 °C. is message noti es that the planned hours of functioning (parameter T67) are reached.
- Page 19 Mareli Systems Pellet Loading Correction P3 CLICK (3 sec) e long pressure of button activates this function (You have to do it two times to access the modify modality). e bottom display shows PELL, the P3/P4 upper display the value. With buttons the value is increased or decreased;...
- Page 20 Mareli Systems P3/P4 Using the buttons is possible to view all programs: STOP • e top of the display shows programs; • No Programs is shown with (- - - -); • e bottom of the display shows: day / time zone / start / stop;...
- Page 21 Mareli Systems LINEA...
- Page 22 Mareli Systems...
- Page 24 MARELI SYSTEMS disclaims any responsibility for possible inaccuracies contained in this manu- al if they are due to printing or transcription errors. We reserve the right to make any change that appears to be necessary or useful without harm the essential characteristics.
