- Page 1 Mareli Systems PSN 12/18/25/30 Pellet stove Assembly and exploitation manual PBN 12/18/25/30 Pellet stove Assembly and exploitation manual e present stove is designed and manufactured according to Standards: BNS (Bulgarian National Standard) EN 14785-2006...
-
Page 2: Safe Distances
Mareli Systems Observing the prescriptions of the present manual is in the user’s favour and is one of the warranty conditions. Compliance with this instruction is in the interest of the con- sumer and one of the warranty terms. INSTRUCTIONS FOR SECURITY: •... - Page 3 Mareli Systems 1. PURPOSE e stove is purposed to heat domestic and public premises by the means of pellets. e stove is equipped with a steel water jacket designed for heating systems with water temperature up to 90º C at a maximum super pressure up to 0,15 Mpa. Tests are run at pressure of 0,3 Mpa.
-
Page 4: Combustion Chamber
Mareli Systems 2. TECHNICAL DATA Maximum output Heated area m³ Height H 1040 1091 Width W Depth D Pellet bunker volume Fresh air pipe ф mm Exhaust gas pipe ф mm Weight Fuel type Pellets Pellets Pellets Pellets Φ6-Φ8 Φ6-Φ8 Φ6-Φ8... - Page 5 Mareli Systems 3. ASSEMBLY 3.1 General conditions. All national, regional and European requirements for safe operation of the appliance must be respected during installation and operation. Prior to installation, load capacity of the place where the stove will be intended must be ensured.
-
Page 6: Connection To Chimney
Mareli Systems CHECK ITEMS BEFORE INSTALLATION Chimney exit Chimney Connection to chimney Connection to the stove Security e chimney distances revision door Inlet air e oor... - Page 7 • “Mareli Systems” provides a warranty and out of warranty service and replacement of the water jackets. • e warranty is not valid in case of a stove with a swollen water jacket which is a result of pressure increase in the system and improper connecting.
- Page 8 Mareli Systems 3.3 Assembly of the duct components. Duct components and pipes For the assembly of the duct pipes the use of non- ammable materials, resistant to the ammable products and condensation is obligatory. e assembly must be performed in such a manner so it guarantees the airtight sealing and prevents condensation.
- Page 9 Mareli Systems 3.4 Types of connection to the chimney Chimney exit Moisture channel Chimney ermal insulation External wall Connection to chimney Flue gas connection Heat generator e chimney revision door “T” connection...
- Page 10 Mareli Systems 3.5 Air intake Suction pipe or air intake is placed in the back and has a circular section with a diameter of 48 mm. e combustion air can be aspirated: • From the camera, as long as it is near an air intake communicating with the outside wall hav- ing a minimum area of 100 cm2, properly positioned and protected by a grid.
- Page 11 Mareli Systems Cleaning the glass Use an non-abrasive cloth Cleaning the pellet bunker Combustion Clean the ue gas chamber outlet Clean the ashtray...
- Page 12 Mareli Systems Cleaning the glass Use an non-abrasive cloth Cleaning the pellet bunker Combustion Clean the ue gas chamber outlet Clean the ashtray...
-
Page 13: Maintenance Program
Mareli Systems Maintenance program At each Weekly Twice Annual ignition per season Combustion chamber Clean the ashtray Glass e Door Clean the ue gas outlet Door seals Chimney 5 Safety and unexpected risks Terms of danger may arise in the following cases: •... - Page 14 Mareli Systems CONTROL PANEL: USE AND FUNCTIONS The main frame shows: time and date, chrono activation, combustion power and recipe, functioning state, error code, main temperature, main thermostat, summer/winter mode. Button Function Exit Menu/Submenu; Ignition and extinguishing (push for 3 seconds), Reset errors (push for 3 seconds), Enable/disable chrono;...
- Page 15 Mareli Systems MESSAGES Description Code PRob Anomaly of the probes checking, during Check Up phase. Room temperature greater than 99 °C. Clean This message noti es that the planned hours of functioning (parameter T67) are reached. Port Door Open. Ignition The message appears if the system is turned o during Ignition (after Preload) not manually: the system will stop only when it goes in Run Mode.
- Page 16 Mareli Systems CHRONO This Manu allows selecting the programming modalities and and the Ignition/Extinguishing time slots. Modality - It allows selecting the disired modality, or disable all set programming. Disable 1. Enter modi cation mode through the key P3. Daily 2.
- Page 17 Mareli Systems CONTROL PANEL K500 Chrono Main Temperature Winter / Summer 65 C RUN MODE Power Main ermostat State - Exit from menu/submenu re ll Function (push for 3 seconds) - Ignition, extinguishing and errors reset (push for 3 seconds) Enable/Disable Chrono...
- Page 18 Mareli Systems CHRONO This Manu allows selecting the programming modalities and and the Ignition/Extinguishing time slots. Modality - It allows selecting the disired modality, or disable all set programming. Disable 1. Enter modi cation mode through the key P3. Daily 2.
- Page 19 LINEA...
- Page 20 MARELI SYSTEMS disclaims any responsibility for possible inaccuracies contained in this manu- al if they are due to printing or transcription errors. We reserve the right to make any change that appears to be necessary or useful without harm the essential characteristics.
