- Page 1 Mareli Systems PRIMAVERA 18/24 Pellet stove Assembly and exploitation manual The present stove is designed and manufactured according to Standards: BNS (Bulgarian National Standard) EN 14785-2006...
-
Page 2: Safe Distances
Mareli Systems Observing the prescriptions of the present manual is in the user’s favour and is one of the warranty conditions. Compliance with this instruction is in the interest of the con- sumer and one of the warranty terms. INSTRUCTIONS FOR SECURITY: •... - Page 3 Mareli Systems 1. PURPOSE The stove is purposed to heat domestic and public premises by the means of pellets. The stove is equipped with a steel water jacket designed for heating systems with water temperature up to 90º C at a maximum super pressure up to 0,15 Mpa. Tests are run at pressure of 0,3 Mpa.
-
Page 4: Combustion Chamber
Mareli Systems 2. TECHNICAL DATA Maximum output Heated area m³ Height H 1051 1051 Width W Depth D Pellet bunker volume Fresh air pipe ф mm Exhaust gas pipe ф mm Weight Fuel type Pellet Pellet Φ6-Φ8 Φ6-Φ8 The chimney draft... - Page 5 Mareli Systems 3. ASSEMBLY 3.1 General conditions. All national, regional and European requirements for safe operation of the appliance must be respected during installation and operation. Prior to installation, load capacity of the place where the stove will be intended must be ensured.
-
Page 6: Connection To Chimney
Mareli Systems CHECK ITEMS BEFORE INSTALLATION Chimney exit Chimney Connection to chimney Connection to the stove Security The chimney distances revision door Inlet air The floor... - Page 7 0,3 litr on a single start-up. The accumulating char reduces the temperature difference and the condensation. • “Mareli Systems” provides a warranty and out of warranty service and replacement of the water jackets. • The warranty is not valid in case of a stove with a swollen water jacket which is a result of pressure increase in the system and improper connecting.
- Page 8 Mareli Systems 3.3 Assembly of the duct components. Duct components and pipes For the assembly of the duct pipes the use of non-flammable materials, resistant to the flammable products and condensation is obligatory. The assembly must be performed in such a manner so it guarantees the airtight sealing and prevents condensation.
-
Page 9: Thermal Insulation
Mareli Systems 3.4 Types of connection to the chimney Chimney exit Moisture channel Chimney Thermal insulation External wall Connection to chimney Flue gas connection Heat generator The chimney revision door “T” connection... - Page 10 Mareli Systems 3.5 Air intake Suction pipe or air intake is placed in the back and has a circular section with a diameter of 48 mm. The combustion air can be aspirated: • From the camera, as long as it is near an air intake communicating with the outside wall hav- ing a minimum area of 100 cm2, properly positioned and protected by a grid.
- Page 11 Mareli Systems Cleaning the glass Use an non-abrasive cloth Cleaning the pellet bunker Combustion chamber Clean the flue gas Clean the outlet ashtray...
-
Page 12: Maintenance Program
Mareli Systems Maintenance program At each Weekly Twice Annual ignition per season Combustion chamber Clean the ashtray Glass e Door Clean the ue gas outlet Door seals Chimney 5 Safety and unexpected risks Terms of danger may arise in the following cases: •... - Page 13 Mareli Systems K400 TOUCH SCREEN DISPLAY 1. HOMEPAGE Date & Time Errors Code 11:24 Fri 14 Oct 2016 Er.01 21° Main Temperature IGNITION Functioning State 65° Main Thermostat ON/OFF Settings Display Info Chrono...
- Page 14 Mareli Systems Main Commands In order to go to Homepage 2 a horizontal swipe must be performed to the right side of the screen. 12:18 Fri 14 Oct 2016 Er.01 Igniter Auger Pump 1 Pump 2 Pump 3 Aux1 Aux1...
-
Page 15: Error List
Mareli Systems Quick visualization of the system main function 2. ERROR LIST 12:18 Fri 14 Oct 2016 Blocking or non-blocking error Er.01 21° is highlighted with a and the related error code. When pressed the error window opens IGNITION 65°... -
Page 16: Main Commands
Mareli Systems IGNITION Blocking / Removing Error 65° 4. MAIN COMMANDS 11:24 Ven 14 Ott 2016 Er.01 ON/OFF Menu Screen image : Swipe to Ignite • System power ON • System power OFF IGNITION • Alarms reset 65° 11:24 Ven 14 Ott 2016 Er.01... - Page 17 IGNITION Mareli Systems 65° 5. CHRONO 12:18 Ven 14 Ott 2016 Er52 Chrono - Daily CHRONO 22° select desired CHRONO program, press on the respective tabs: • Daily • Weekly RECUPERO ACCENSIONE DAILY WEEKLY WEEKEND • Weekend. 28° To change the chrono program, press on .
- Page 18 Mareli Systems 5. INTERNAL MENU STRUCTURE From the display Menu the user can access the panel settings and select one of 24 languages Brightness. Minimum brightness: this function allows you to choose the minimum brightness level which the device automatically sets to after 30 sec. of inactivity.
- Page 19 Auger ON External Chrono reached V2: Pump 1 ON Lack of pellet Mareli Systems R: Igniter ON Local Room Thermostat reached Sanitary water demand Aux2: Pump 2 ON ALARMS Er01 - Security Error High Voltage 1. It may also intervene with the system o ;...
- Page 20 Mareli Systems FAN ENCODER SIGNAL KEY FOR CLEANING MECHANISM VOUT N.O. RELAY FOR THE CLEANING MECHANISM POWER CABLE COMBUSTION PROGRAMMER COMBUSTION FAN 2 PUMP 1 IGNITER WATER OVERHEATING PROTECTION PRESSURE SWITCH BUFFER PROBE AUGER BOILER PROBE 31 GND MOTOR FOR...
-
Page 21: First Configuration
Mareli Systems FIRST CONFIGURATION First select the plumbing installation (parameter from the Enable menu of the Technical menu). - Page 22 Mareli Systems...
- Page 24 MARELI SYSTEMS disclaims any responsibility for possible inaccuracies contained in this manu- al if they are due to printing or transcription errors. We reserve the right to make any change that appears to be necessary or useful without harm the essential characteristics.
