AS200X
OWNER'S INSTRUCTION MANUAL
Please read this manual carefully to ensure correct operation and care of the machine. If you use the AS200X
correctly, it will provide you with years of reliable service saving you time and money.
BRICK & MORTAR SAW______________
Double Insulation used throughout, no
provision for earthing.
Double Insulation used throughout, no
provision for earthing.
www.arbortechtools.com
www.arbortechtools.com
ALL.FG.200240.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS200X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arbortech AS200X

Summary of Contents for Arbortech AS200X

  • Page 1 ALL.FG.200240.00 OWNER’S INSTRUCTION MANUAL Please read this manual carefully to ensure correct operation and care of the machine. If you use the AS200X correctly, it will provide you with years of reliable service saving you time and money. Double Insulation used throughout, no provision for earthing.
  • Page 2 ITEM DESCRIPTION Rear handle Trigger switch Lock-off lever Lock on button Top Handle Leaver- blade locking Vacuum Bracket Handle Locking Button Dust Boot GP Blades...

  • Page 6: General Power Tool Safety Warnings

    (corded) power tool. operation, with the ability to cut to a depth of 120mm (4 3/4”), cut square corners and make variable width cuts. The AS200X is ideally suited to 1) Work area safety a variety of tasks including: a) Keep work area clean and well lit.

  • Page 7: Personal Safety

    3) Personal safety c) Disconnect the plug from the power source a) Stay alert, watch what you are doing and use and/ or the battery pack from the power tool common sense when operating a power tool. before making any adjustments, changing Do not use a power tool while you are tired or accessories, or storing power tools.

  • Page 8: Functional Description

    2) Blade description earthing.) Read the instruction manual The AS200X uses a variety of blades to cut different materials and different profiles. Wear hearing protection General Purpose blades use Tungsten Carbide teeth and are suited for working general masonry.

  • Page 9: Dust Extraction

    Switch Box blades use Tungsten 2) Dust extraction Carbide teeth and have a maximum The AS200X should be fitted with a Dust Boot as cutting depth of 120mm (4 3/4”). shown in diagram , and used with a dust Suitable for installing small electrical extraction vacuum.
  • Page 10 Fig.3 Fig.3 3) Operation Fig. 3 Fig.3 CAUTION: During operation the AS200X may CAUTION: During operation the AS200X may cause hand-arm vibration, which can result in DIRECTION cause hand-arm vibration, which can result in CAUTION: During operation the AS200X may...

  • Page 11: Maintenance

    E: arbortech@arbortech.com.au Brushes The AS200X is fitted with auto-cut off brushes. When the brushes are worn below minimum length, they stop tool operation reducing internal motor damage. Contact your local dealer or...
  • Page 12 ARBORTECH PTY LTD 67 Westchester Rd, Malaga, Perth, Western Australia 6090 Ph: +61 8 9249 1944 Fax: +61 8 9249 2936 ARBORTECH EUROPE GMBH Esloher Str. 188, 57413 Finnentrop, Germany (Germany) +49 2724 2880474 30 Corporate Park Dr, Suite 210...
