- Page 1 TS series HMI manual ［Hardware］ Wuxi Xinje Electric Co., Ltd. Data No. HSC01 20220428EN 1.0...
- Page 2 Thank you for purchasing the Xinje TS series HMI. This manual mainly introduces the hardware characteristics of TS series HMI. Before using the product, please read this manual carefully and conduct wiring on the premise of fully understanding the contents of the manual.
- Page 3 WUXI XINJE ELECTRIC CO., LTD. All rights reserved Without explicit written permission, this material and its contents shall not be copied, transferred or used. Violators shall be liable for the losses caused. All rights provided in patent license and registration, including utility modules or designs, are reserved.
-
Page 5: Table Of Contents
CATALOG 1. TS3 SERIES HMI OVERVIEW ..........................1 1-1. P ............................... 1 RODUCT FEATURES 1-1-1. Product features ............................... 1 1-1-2. Naming rule ..............................2 1-1-3. Model list ................................. 2 1-2. P ............................2 RODUCT SPECIFICATION 1-3. P ..............................3 ART DESCRIPTION 1-3-1. -
Page 7: Ts3 Series Hmi Overview
1. TS3 series HMI overview 1-1. Product features 16.77 million colors TFT-LCD, highlighted screen, full color, more realistic display effect. ◆ High speed A8 600MHz main frequency CPU, 128MB memory, excellent data processing ability, ◆ faster download speed and large. Greatly improve the boot loading speed, reduce the waiting time and screen jump, and the animation effect is better and smooth. -
Page 8: Naming Rule
700：7.0 inch 1000：10.1 inch ③： Interface M：USB-B, USB-A, COM1, COM2 E：USB-B, USB-A, RJ45, COM1, COM2 1-1-3. Model list Xinje TS3 series HMI have the following models according to different display sizes and function types: Display 7〞 10.1〞 TS3-700-M TS3-1000-M General model... -
Page 9: Part Description
Product model TS3-700 TS3-1000 Voltage impact AC1000V, 10mA, less than 1 minute (signal and ground) resistance Above 10MΩ, DC500V Insulation resistance Operation 0-50℃ temperature Storage -10-60℃ temperature Operation 10%RH-90%RH (no condensation) humidity Environment Anti Voltage noise: 1500Vp-p, pulse width 1us, 1 minute interference capability No corrosive gas... -
Page 10: Interface Description
1-3-2. Interface description The HMI of Xinje TS3 series is described as follows: Appearance Name Function Dial switch Used to set forced download, touch calibration, etc COM1 Support RS232/RS485 communication Download COM1 COM2 Support RS232/RS485/RS422 communication COM2 USB flash disk can be inserted to store data, and USB... - Page 11 (2) COM2 port pins definition Definition Explanation RS422 communication send + RS232 communication receive data RS232 communication send data RS485 communication signal + Signal ground RS422 communication send - RS485 communication signal - RDD- RS422 communication receive - RDD+ RS422 communication receive + 3.
- Page 12 5. RJ45 port RJ45 port pin definition: Color Definition Explanation Orange TXD+ Data send + white Orange TXD- Data send - Green white RXD+ Data receive + Blue Blue white Green RXD- Data receive - Brown white Brown...
-
Page 13: Product Dimension And Installation
1-4. Product dimension and installation 1-4-1. Product dimension ◼ TS3-700 (unit: mm) 192.3±0.5 ◼ TS3-1000 (unit: mm) 37.5 277.0 258.2 260.2±0.1... -
Page 14: Product Installation And Use Environment
1-4-2. Product installation and use environment 1. Installation requirement TS3 series HMI is equipped with four iron mounting brackets at the factory. The upper and lower sides of the display are respectively provided with two square fixing holes. The display is tightly fixed to the mounting holes of the control cabinet with the mounting bracket. -
Page 15: Ts5L Series Hmi Overview
2. TS5L series HMI overview 2-1. Product features 16.77 million colors TFT-LCD, highlighted screen, full color, more realistic display effect. ◆ High speed A8 600MHz main frequency CPU, 128MB memory, excellent data processing ability, ◆ faster download speed and large. Greatly improve the boot loading speed, reduce the waiting time and screen jump, and the animation effect is better and smooth. -
Page 16: Naming Rule
E: no module, with Ethernet port G: with 4G module W: with WIFI module 2-1-3. Model list Xinje TS5L series HMI has the following models according to different display sizes and function types: Display size 7〞 10.1〞 TS5L-700 TS5L-1000... -
Page 17: Part Description
Product model TS5L-700 TS5L-1000 Ethernet port Standard RJ45 (10/100M self-adpation) ɸ3.5 coaxial audio plug Audio interface 4G (optional) LTE-FDD (Mbps): 10 (downlink) / 5 (uplink) WIFI (optional) IEEE 802.11 a/b/g/n IEEE 802.11 g: 54Mbps Input voltage DC24V (voltage range: DC22V-DC26V) Current 200mA 270mA... -
Page 18: Interface Description
Expansion module Power supply COM1 Antenna Audio interface interface 2-3-2. Interface description The HMI of Xinje TS5L series is described as follows: Appearance Name Function Dial switch Used to set forced download, touch calibration, etc COM1 Support RS232/RS485 communication COM1... - Page 19 setting functions are as follows: Switch DIP1 DIP2 DIP3 DIP4 Function Undefined USB flash disk import program Status Touch calibration Undefined 2. Communication port (1) COM1 port pin definition: Name Explanation Null signal RS232 communication receive data RS232 communication send data RS485 communication signal + Signal ground Null signal...
- Page 20 Definition Explanation +5V voltage signal DATA- Data﹢signal DATA+ Data﹣signal Signal ground (1) Please use the shielded USB cable (2) The TouchWin Pro editing tool and USB drive must be correctly installed before using. (3) After the drive is correctly installed, confirm that the computer is correctly connected to the TS5L series HMI, click to download HMI program.
-
Page 21: Product Dimension And Installation
2-4. Product dimension and installation 2-4-1. Product dimension ◼ TS5L-700 (unit: mm) 205.8 35.5 190.1 ◼ TS5L-1000 (unit: mm) 37.6 258.2 277.0 260.2±0.1... -
Page 22: Module Installation
2-4-2. Module installation Installation steps (1) Remove the module cover of TS5L series HMI Before After (2) Select the module to be installed, and insert the module into the HMI interface by aligning it with the plug position (3) Screw on the two fixing screws. The positions of the screws are shown in the figure below: (WIFI module) (4G module) - Page 23 (4) SIM card installation (WIFI module no need this step) 4G module needs to install the SIM card. Please insert the SIM card into the card slot in the direction shown in the figure below. See the figure on the right of the card slot for details: The removal of the SIM card is similar to the installation steps.
-
Page 24: Product Installation And Using Environment
(5) Install the rear cover of the module removed in step 1. Notice: (1) 4G or WIFI modules cannot be disassembled with power, and the HMI must be powered off before installation. (2) The SIM card of the 4G module cannot be plugged or unplugged with power. Please install it in the direction shown on the module. - Page 25 +24V +DC- In addition, connecting high voltage or alternating current to the power input terminal in the HMI will make the equipment unusable and may cause electric shock to the human body. Such mistakes or serious electric shock can lead to personal injury, even death, and equipment damage. 【Note】: If the PLC DC output is used to drive the HMI, it must be considered that the +24V DC output of some controllers may not have enough current to support it.
- Page 27 WUXI XINJE ELECTRIC CO., LTD. Address: No. 816, Jianzhu West Road, Binhu District, Wuxi City, Jiangsu Province, China Tel: 0510-85134136 Fax: 0510-85111290 Website: www.xinje.com Email: sales@xinje.com Xinje wechat...
