Summary of Contents for Seca 869 UK
- Page 1 869 UK Instruction manual and guarantee...
- Page 2 English By purchasing the seca 869 electronic In addition to the conventional determina- tion of weight, the seca 869 also has a personal scale, you have acquired a high- ly-accurate and sturdy piece of equip- function for determining body mass index.
-
Page 3: Desk-Top Stand
3. Before you start… Remove the packaging and place the scale on a firm, level surface. The scope of supply includes: • Weighing platform • Display head plus connecting cable • Wall bracket • 2 Screws • 2 Rawlplugs • 6 mignon-type AA 1.5 V batteries Desk-top stand If you prefer, you can stand the display part rather than hang it on the wall:... -
Page 4: Fitting The Wall Bracket
Fitting the wall bracket The display part is intended for mounting on the wall. Use the mounting material supplied to do so. – Screw the wall bracket to the wall as shown. Be aware that you have a length of 2 m of cable between the scale and the dis- play part. -
Page 5: Power Supply
– Then turn the scale back up the right way. Note: the scale is prepared for use with a seca mains unit which is availa- Connection for mains unit ble as an accessory. Connecting the connecting cable to the weighing platform... -
Page 6: Setting Up And Aligning The Scale
Setting up and aligning the scale The screwed feet can be used to level off any slight unevenness in the floor. – Place the scale on a level surface. spirit level – Align the scale by screwing the foot screws. The air bubble in the spirit level must be right in the centre of the circle. -
Page 7: Operation
4. Operation Controls and displays The controls and display are in the display part. Switch scale on and off switch between kg and lbs press briefly switch between lbs and sts hold down in function menu increase value ... -
Page 8: Switching The Weight Display
– Ask the patient to step off the scale. 0. 0 0 The weighing result has been erased. The scale is ready for the next patient. – If a load greater than 250 kg, 550 lbs or St0P 39 sts is placed on the scale, pears in the display. -
Page 9: Store Weight Value (Hold)
0. 0 The display is reset to zero, flashes in the display until weight is detected to be stable. Only then is the Tare function fully activated. The note “NET” appears. – Now take the additional load onto the scale. You can leave the scale to do so, ---- in which case appears. -
Page 10: Evaluating Body Mass Index For Adults
– You can use the arrow keys to adjust the value in increments according to the graduations displayed. – Once the correct value is set, press the bmi key again. The BMI function is now activated. – Step on the scale and keep still. –... - Page 11 Service department. 7. Servicing Your seca scale leaves the factory with an accuracy greater than ± 0.15 %. To ensure that this accuracy is maintained, the product must be carefully set up and regularly maintained.
-
Page 12: Changing The Batteries
Changing the batteries bAtt When appear in the display, you should change the batteries. You need 6 type AA 1.5 V batteries. – Carefully turn over the scale so that the base of the scale is accessible. – Open the cover. –... -
Page 13: Spare Parts And Accessories
Switchmode power adapter, 100-240V~ / 50-60Hz / 12V= / 0.5A seca no. 68-32-10-265 Attention! Use only seca original plug-in mains units with 9 V or controlled 12 V output voltage. Commercially-available mains units may supply a higher voltage than stated and thus lead to damage to the scale. -
Page 14: Warranty
12. Declaration of conformity seca gmbh & co. kg hereby declares that the product meets the terms of the applicable European directives. The unabridged declaration of conformity can be found at: www.seca.com.
