OWNER'S MANUAL
MANUAL DEL USUARIO
Thurlow LED
Please write model number here for future reference:
Por favor, incluya el número del modelo aquí para futura referencia:
Net Weight:
Peso Neto:
1
ETL-ES-Thurlow LED-WH19
17.18 LBS
7.81 KGS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETL-ES-Thurlow LED-WH19 and is the answer not in the manual?

Questions and answers

Related Manuals for Westinghouse ETL-ES-Thurlow LED-WH19

Summary of Contents for Westinghouse ETL-ES-Thurlow LED-WH19

  • Page 1 ETL-ES-Thurlow LED-WH19 OWNER'S MANUAL MANUAL DEL USUARIO Thurlow LED Please write model number here for future reference: Por favor, incluya el número del modelo aquí para futura referencia: Net Weight: 17.18 LBS Peso Neto: 7.81 KGS...

  • Page 2: Safety Tips

    ETL-ES-Thurlow LED-WH19 SAFETY TIPS OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT TO OUTLET BOX MARKED 'ACCEPTABLE FOR FAN SUPPORT OF 35 LBS (15.9 KG) OR LESS' AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX AND/OR SUPPORT DIRECTLY FROM BUILDING STRUCTURE.

  • Page 3: Consejos De Seguridad

    ETL-ES-Thurlow LED-WH19 CONSEJOS DE SEGURIDAD HAGA LO SIGUIENTE: LEA Y GUARDE ESTAS INSTRUCCIONES ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA O HERIDAS GRAVES PERSONALES, MONTE EN UNA CAJA DE EMBUTIR ROTULADA “ADECUADA PARA VENTILADORES DE 35 LB (15,9 KG) O MENOS”...
  • Page 4 ETL-ES-Thurlow LED-WH19 FEATURES CARACTERÍSTICAS DOWNROD INSTALLATION INSTALACIÓN CON VARILLA VERTICAL For normal ceilings COMBO-BLADE Combo-Blades feature two high quality finishes on one blade. Select the one that best complements Para techo normales your decor, or change the style with just a flip of the blade.
  • Page 5 ETL-ES-Thurlow LED-WH19 PREPARING FOR INSTALLATION PREPARANDO PARA DE LA INSTALACIÓN Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose box will cause the fan to wobble).
  • Page 6 ETL-ES-Thurlow LED-WH19 MOUNTING BRACKET INSTALLATION INSTALACIÓN CON SOPORTE DE MONTAJE Remove the screws from the two mating holes (2) on the canopy. Loosen (do not remove) the screws in the mating slots (1) on the canopy. Rotate the mounting bracket and remove from the canopy.
  • Page 7 ETL-ES-Thurlow LED-WH19 MOUNTING BRACKET INSTALLATION MOUNTING OPTIONS OPCIONES DE MONTAJE INSTALACIÓN DEL SOPORTE DE MONTAJE Choose a MOUNTING OPTION Elija una OPCIÓN DE MONTAJE NORMAL DOWNROD OPTION If installing downrod supplied with fan, follow step 6 to prepare downrod, then skip Extended Downrod steps 7-8 and continue with step 9.
  • Page 8 ETL-ES-Thurlow LED-WH19 DOWNROD PREPARATION PREPARACION DE LA VARILLA VERTICAL Remove clamp pin (1) and cross pin (2) from downrod (3). If installing crossbar included with fan, skip to step 9, page 11. Quite el pasador tipo prensa (1) desde el pasador transversal (2) de la varilla vertical (3). Si está instalando una barra transversal incluida con el ventilador, vaya al paso 9,...
  • Page 9 ETL-ES-Thurlow LED-WH19 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA If installing an extended downrod. Loosen downrod ball (1) from downrod (2) by removing set screw (3). Slide downrod ball (1) off of downrod and remove pin (4). Si instala una varilla vertical mas larga. Afloje la bola (1) de la varilla vertical (2) quitando el tornillo de fijacion (3). Deslice la bola de la varilla vertical (1) hasta separarla de la...
  • Page 10 ETL-ES-Thurlow LED-WH19 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Re-install pin into extended downrod, and slide downrod ball up to the top of the downrod. Re-install the set screw to secure ball to downrod. Note: Some extended down- rods have a pre-drilled set-screw hole.
  • Page 11 ETL-ES-Thurlow LED-WH19 DOWNROD INSTALLATION INSTALACION DE LA VARILLA VERTICAL Loosen (but do not remove) the set screws from the down rod coupling. Place down rod assembly into canopy and coupling cover. Feed motor wires though the down rod assem- bly and insert the downrod into the downrod coupling. Make sure to align the hole in the downrod with the hole in the downrod coupling. Install cross pin (1) removed in step 6 through coupling and downrod.
  • Page 12 ETL-ES-Thurlow LED-WH19 MOUNTING MONTAJE Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on downrod ball (1) engages the ridge on the mounting bracket (2). This will allow for hands free wiring. Levante con cuidado el conjunto del ventilador hasta el soporte de montaje. Gire el ventilador hasta que la muesca de la bola de la varilla vertical (1) enganche sobre la...
  • Page 13 ETL-ES-Thurlow LED-WH19 WIRING OPTIONS OPCIÓN DE CABLEADO This remote control unit is equipped with 16 code combinations to prevent possible interference from or to other remote units. The frequency switches on your receiver and transmitter have been preset at the factory. Please recheck to make sure the switches on transmitter and receiver are set to the same position, any combination of settings will operate the fan as long as the transmitter and receiver are set to the same position.
  • Page 14 ETL-ES-Thurlow LED-WH19 WIRING OPTIONS OPCIÓN DE CABLEADO Bare Copper or Green Cobre Pelado o Verde Green Green Verde Verde Make wiring connections from the house and the motor to the remote receiver as shown Once wiring step has been completed, slide the wired remote receiver in between the above.
  • Page 15 ETL-ES-Thurlow LED-WH19 SECURE TO CEILING ASEGURE EL VENTILADOR AL TECHO For downrod fans, slide the canopy up to the mounting bracket. Para ventiladores con varilla vertical, deslice el dosel hacia arriba hasta el soporte de montaje. The canopy has two mating slots (1) and two mating holes (2). Position both slots on canopy directly under and in line with two screws in the mounting bracket (3). Lift the canopy, allow- ing the two screws to slide into the mating slots.
  • Page 16 ETL-ES-Thurlow LED-WH19 BLADE INSTALLATION INSTALACIÓN DE LAS ALETAS Insert the blade assemblies through the slots on the side of the motor housing as shown. Using the access slot in the switch housing plate (shown in diagram) to attach the blade brackets using the provided blade screws and spring washers.
  • Page 17 ETL-ES-Thurlow LED-WH19 LIGHT FIXTURE INSTALLATION BLADE INSTALLATION INSTALACIÓN DEL ARTEFACTO LUMINOSO INSTALACIÓN DE LAS ALETAS Remove the screws (1) from the light kit mounting plate (2) and keep them for use with light kit installation on the step #20. Install light bulbs. Use E26 base, Max.40W light bulbs.
  • Page 18 ETL-ES-Thurlow LED-WH19 LIGHT FIXTURE INSTALLATION INSTALACIÓN DEL ARTEFACTO LUMINOSO Open the three clamps on the side of the cage. Attach the cage onto the lamp shade and make sure to overlap the edge between the cage with the lamp shade. Then push the three clamps into the edge of the lamp shade orderly.
  • Page 19 ETL-ES-Thurlow LED-WH19 LIGHT FIXTURE INSTALLATION INSTALACIÓN DEL ARTEFACTO LUMINOSO Connect both 6-pole plug from the fan body and the switch housing. Then attach switch housing (2) to fan switch housing cover (1) using the side screws you saved from step#17.
  • Page 20 ETL-ES-Thurlow LED-WH19 Mount the transmitter holder onto the wall using screws provided. Place the transmitter into the holder. Monte el soporte para el transmisor a la pared usando los tornillos incluidos. Coloque el transmisor en el soporte.
  • Page 21 ETL-ES-Thurlow LED-WH19 Remote Control Operation 1. Fan Control– press and release. The remote control operates the fan speed as follows: OFF, turns fan off; HIGH, highest fan speed; MED, medium fan speed; M.LOW, medium low fan speed; LOW, low fan speed.

  • Page 22: Operation And Maintenance

    ETL-ES-Thurlow LED-WH19 OPERATION AND MAINTENANCE Operation Turn on the power and check operation of fan. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. The slide switch controls direction, forward or reverse.

  • Page 23: Operación Y Mantenimiento

    ETL-ES-Thurlow LED-WH19 OPERACIÓN Y MANTENIMIENTO Operación Encienda el ventilador y verifique su funcionamiento. Las velocidades para clima cálido o frío dependen de factores como el tamaño de la habitación, la altura del ventilador, el número de ventiladores, etc. El interruptor deslizante controla la dirección, hacia adelante o hacia atrás.

  • Page 24: Troubleshooting Guide

    ETL-ES-Thurlow LED-WH19 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these TROUBLESHOOTING GUIDE installation errors may be mistaken for defects. If you experience any faults, please check this troubleshooting chart. If a problem cannot be remedied, please consult with your qualified electrician and do not attempt any electrical repairs yourself.
  • Page 25 ETL-ES-Thurlow LED-WH19 Si tiene dificultades para hacer funcionar su nuevo ventilador, podría ser a causa del armado, instalación o cableado incorrectos. En algunos GUÍA PARA SOLUCIONAR PROBLEMAS casos, estos errores de instalación podrían ser confundidos con defectos. Si experienca algun fallo, consulte esta guía para solucionar problemas.

  • Page 26: Warranty

    If replacement product is not available through seller, please contact www.westinghouselighting.com/contact-us. GARANTÍA Este ventilador de Westinghouse Lighting se ofrece con una garantía limitada de por vida para el propietario original frente a defectos de material y de mano de obra. Esta garantía sustituye cualquier otra garantía expresa o implícita.
  • Page 27 ETL-ES-Thurlow LED-WH19 PARTS LIST LISTA DE REPUESTOS Description 1 ..Mounting Bracket (assembled with Canopy) 2 ..Blade Bracket (qty. 3) 3 ..Blade (qty 3) 4 ..Cage 5 ..Remote control 6 ..Capacitor 7 ..Hardware pack 8 ..
  • Page 28 ETL-ES-Thurlow LED-WH19 Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. www.westinghouselighting.com , WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF are trademarks of Westinghouse Electric Corporation. Used under license by Westinghouse Lighting All rights reserved. Made in China...
