3.4 LCD display wording index
Abbreviation
ENA
DIS
ESC
HS
LS
ON
OK
TP
CH
FU
EE
BR
3.5 UPS setting
There are two parameters to set up the UPS.
Parameter 1 – Program alternatives. There are 4 programs to set up: output voltage setting,
programmable outlets enable/disable, programmable outlets setting, LCD display direction
and exit.
Parameter 2 – Setting figures.
INFOSEC UPS SYSTEM - 4, rue de la Rigotière - 44700 Orvault - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 01 16 AA 59 204 03
Display content Meaning
Enable
Disable
Escape
High loss
Low loss
ON
OK
Temperature
Charger
Bypass frequency unstable
EEPROM error
Battery Replacement
Parameter 2
Parameter 1
