Summary of Contents for Samsung SyncMaster 56E
- Page 1 56E56V.Cover.auto.fm Page 1 Wednesday, November 8, 2000 4:38 PM USER’S MANUAL 38cm (15”) Color Monitor 56E/56V...
- Page 2 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Connecting Your Monitor ........ -
Page 4: Safety Instructions
Doing so may block the ventilation openings in the bottom of the cabinet. If you put the monitor in a bookcase or some other enclosed space, be sure to provide adequate ventilation. -
Page 5: Your New Monitor
3p-4p.fm Page 3 Friday, December 1, 2000 11:05 AM Your New Monitor Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Manual Stand Connecting Your Monitor Turn off your computer and unplug the power cord. -
Page 6: Front Panel
Contrast and Brightness Direct Access Buttons Most of the adjustments you make to your monitor will be accessed through the on-screen menu described in the next section. The Contrast and Brightness features can also be accessed directly from the front of your monitor. -
Page 7: Operation
5p.fm Page 5 Thursday, November 9, 2000 10:51 AM On Screen Display(OSD) Your monitor has an OSD, accessed by the buttons on the front of your monitor, that allows you to adjust characteristics of the screen image. Display changes are indicated by on-screen adjustment icons. -
Page 8: Monitor Function Control
5p.fm Page 6 Thursday, November 9, 2000 10:51 AM Icon Monitor Function Control Brightness Background brightness of screen. -– Decreases brightness + Increases brightness Contrast Contrast of screen image. -– Decreases contrast + Increases contrast Horizontal Position Horizontal screen position. -
Page 9: Pincushion
5p.fm Page 7 Thursday, November 9, 2000 10:51 AM Icon Monitor Function Control Pincushion Straightens screen vertical edges. -– Curves image inward + Curves image outward Geometry Trapezoid Width of top and bottom of screen. -– Widens bottom of screen... -
Page 10: Language
5p.fm Page 8 Saturday, September 22, 2001 Icon Monitor Function Control Language -– and + scroll through on-screen language options. (English/ Korean/ Deutsch/ Français/ Español/ Italiano / Português/ Svenska/ Russian) The 3 Languages, Korean, Svenska, and Russian are applied only to the product for Europe. -
Page 11: Zoom
+ Enlarges view of display area Degauss Removes color distortion caused by magnetic fields. Do not use more than once in 30 minutes. Recall Returns monitor to original settings. -– No + Yes Display Timing Monitor display settings. -– Factory timing... -
Page 12: Troubleshooting
There is no screen image Check to see that both the monitor and the computer are plugged in and turned on. “No Connection, Check Signal Cable” appears Check the signal cable connection between the computer and the monitor. -
Page 13: Powersaver
This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor into a low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you move the computer's mouse or press a key on the keyboard. -
Page 14: Specifications
5p.fm Page 12 Friday, December 15, 2000 4:39 PM Specifications Specifications Models: Samtron 56E/56V Picture Tube • 15” (38 cm) Full square type (35 cm Viewable) • 90 ° Deflection • Dot pitch: 0.24 mm (H) / 0.14 mm (V) •... -
Page 15: Index
Driver installation diskette, 3 Front panel, 4 Geometry, 7 Horizontal position, 6 Horizontal size, 6 Language, Menu button, 4 Monitor function control, 6, 7, 8, 9 8:50 AM Index Operation, 6, 7, 8, 9 On Screen Display, 5 OSD Lock/Unlock,... -
Page 16: Ic Compliance Notice
Before making the connection, make sure the voltage rating of the computer convenience outlet is the same as the monitor and that the ampere rating of the computer convenience outlet is equal to or exceeds the monitor voltage rating. - Page 17 BOX 713, S- 194 27 UPPLANDS VASBY Tel : 468- 590- 966- 00 Fax : 468- 590- 966- 50 SAMTRON MEXICO SAMSUNG ELECTRONICS MEXICO, S.A. DE C. V. Mina No. 200, ESQ. GAVILANCOL. GUADALUPE DEL MORAL IZTAPALAPA, MEXICO, D.F. C.P. 09300 Tel.
