- Page 1 User Manual User Manual Induction Buffet Warmers CONFORMS TO UL STD. 197 CONFORMS TO NSF/ANSI STD. 4 Models: 177ICW300, 177ICW375, 177IDIW300, 177IDIW375 08/2023 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
-
Page 2: Table Of Contents
User Manual Table of Contents Safety and Warranty ................................3 Induction Technology .................................6 Technical Specifications..............................7 Cutout Dimensions for Drop-Ins ............................8 Parts Identification ................................9 Operation ..................................10 Selection of cookware ..............................11 Maintenance ..................................12 Troubleshooting ................................13 www.AvantcoEquipment.com... -
Page 3: Safety And Warranty
User Manual Important Safeguards To avoid damage or danger by improper use, this instruction manual should be read and followed carefully. Save the instruction manual together with the warranty information and receipt for further reference. If you give the appliance to another person, also supply them with this instruction manual. - Page 4 User Manual CAUTION! DANGER OF ELECTRIC SHOCK! DO NOT IMMERSE CORD, PLUG, OR APPLIANCE IN WATER OR OTHER LIQUID TO AVOID ANY RISK OF ELECTRICAL SHOCK. • Keep the appliance out of reach of children or persons who cannot handle electric appliances properly. When plugged in, the cord should be out of the reach of children to avoid hazard.
- Page 5 User Manual • Do not operate the device if it is damaged in any way or does not function properly. • Do not operate the appliance if any parts of it are damaged to avoid all risks. The appliance is damaged when there are any cracks, excessively broken or frayed parts, or leaks.
-
Page 6: Induction Technology
User Manual Induction Technology When the power connection is ON, the electric current will produce a magnetic field in the induction coil, which is embedded in the machine. As soon as the magnetic force lines in the magnetic field touch the alloy steel pot/boiler, it will produce a heating effect, which then heats the food in the saucepan or pot. - Page 7 User Manual Installation: • Ensure the installation location has dedicated power: • Countertop models can simply be placed on a flat, level surface. There might be at least 2" of clearance around the unit at all times for proper ventilation. To install drop-in models, follow the steps below: Note: Countertop thickness must not exceed 2".
-
Page 8: Cutout Dimensions For Drop-Ins
User Manual Cutout Dimensions for Drop-Ins 15.98" 15.98" 3.14" 15.15" 15.15" 15.55" 15.55" 2.17" Model No. 177ICW300 15.98" 23.03" 3.14" 15.15" 22.24" 22.63" 15.55" 2.17" Model No. 177ICW375 www.AvantcoEquipment.com... -
Page 9: Parts Identification
User Manual Parts Identification Controls for: 177ICW300, 177ICW375 On/Off Key Low Level Key High Level Key Lock Key Mid Level Key Controls for: 177IDIW300, 177IDIW375 Rotating Knob High Level Key On/Off Key Medium Level Key Lock Key Low Level Key... -
Page 10: Operation
User Manual Product Operating Instructions 1. Basic Operation - Place induction compatible cooking utensils in the center of the cooktop plate. - Insert the plug into AC 120V~, 60Hz Socket. The [On/Off] Indicator will flash. - Press [ON/OFF] button to power the unit on. The [On/Off] Indicator will light up, then press any [High/Med/Low] button to start working. -
Page 11: Selection Of Cookware
User Manual Selection of Cookware Suitable cookware It is important that the heat conductance of the cookware is extremely high to guarantee a constant heat distribution. The bottom of the cookware used with the induction plate must be magnetic (ferromagnetic). Recommended for use with enameled pots made of magnetic steel, roasting tins made of cast iron, or special stainless steel cookware with a special steel “sandwich”... -
Page 12: Troubleshooting
User Manual 6. Do not pull out the power cord directly during operation. To extend the appliance’s life, press the “On/Off” button first, then unplug the power cord from the socket. 7. The fan will run to cool the heating plate even after the Unit is powered off. It is better to remove the plug after the fan stops working. - Page 13 User Manual User Manual ERROR SCENARIO CHECK POINTS REMEDY Low/Med Key Indicator Flash Top Plate Sensor Open Circuit or If you can see loose wires, then without connect contact customer service. Med/High Key Indicator Flash IGBT Sensor Overheat or Short Cir- 1.
