Tyco Electronics 58241-1 Instruction Sheet

PROPER U E GUIDELINE
Cumulative Trauma Disorders can result from the prolonged use of manually powered hand tools. Hand tools are intended for occasional use and low volume
applications. A wide selection of powered application equipment for extended-use, production operations is available.

1. INTRODUCTION

ool Kit with
Base Part No.
58241-[ ]
Pin
TOOL KIT 58241-1
Cable Dia
11.43 [.450]
(Max)
Handle 27152-2
Bench Mtg.
313183-1
Plate
Plunger/sleeve
313196-1
Assy
Figure 1

2. INTRODUCTION

This instruction sheet covers use and maintenance of
Shielding Enclosure Expansion Tool Kits 58241–1,
58241–2, and 58241–4. These tools are used to
expand the cable outlet of shielding enclosures for
AMPLIMITE* connectors, allowing the enclosure to be
inserted easily over cable.
2009 Tyco Electronics Corporation, Harrisburg, PA
All nternational Rights Reserved
TE logo and Tyco Electronics are trademarks.
*Trademark. Other products, logos, and company names used are the property of their respective owners.
hielding Enclosure
Expansion Tool Kits
58241-1, -2, and -4
Handle
Plunger
Shaft
Sleeve
T ool Tip
Bench
Mounting
Plate
58241-2 58241-4
14.53 [.572] 8.38 [.330]
27152-2 18963-1
313183-1 ---
313196-2 313196-3
TOOL NG ASS STANCE CENTER 1-800-722-1111
PRODUCT NFORMAT ON 1-800-522-6752
Dimensions in this instruction sheet are in metric
NOTE
units [with U.S. customary units in brackets].
Figures and illustrations are for identification only
and are not drawn to scale.
Read these instructions thoroughly before using the
cover extraction tool.
Reasons for reissue of this instruction sheet are
provided in Section 5, REVISION SUMMARY.
Typical
Clamping
Method
Vise
Mounting
Expansion
T ool
Flat Sides of Shaft
Facing Jaws
Figure 2
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at
nstruction Sheet
408-9199
10 Feb 09 Rev B
Bench
Mounting
Expansion
T ool
Bench
Mounting
Plate
Work
Bench
Vise Jaws
1
of 2
www.tycoelectronics.com
LOC B
