- Page 1 RAY Series IMPORTANT SAFETY PRECAUTIONS BEST PRACTICES GENERAL CARE SYSTEM HARDWARE & ACCESSORIES RAY 22 AC AND DC CABLE INSTALLATION RAY 44 ASSEMBLY INSTRUCTIONS RAY 66 TECHNICAL SPECIFICATIONS USER MANUAL CAUTIONS & WARNINGS PRODUCT GUARANTEE & WARRANTY...
- Page 2 IMPORTANT SAFETY PRECAUTIONS GENERAL CARE • The system should only be cleaned as directed in the Fluence’s Fixture RAY Series systems is passively cooled with zero moving components Cleaning Recommendations which can be downloaded from the Fluence They are designed for accepted horticulture environments and years of Support Center www.fluence.science/support-center/.
-
Page 3: System Hardware & Accessories
SYSTEM HARDWARE & ACCESSORIES SYSTEM HARDWARE RAY fixture pre-configured with: 8’ Cord with Male DC Connector Power Supply pre-configured with: 14” Cord with Male AC Connector 13 5” Cord with Female DC Connector 13 5” Cord with 3-Pin Waterproof Dimming Connector and Dust Cap (dimmer sold separately) Pigtail Dimming Adapter (purple/gray leads) ACCESSORIES... - Page 4 AC AND DC CABLE INSTALLATION WARNING: Risk of Electrical Shock Turn off and disconnect the power before installing, moving, or cleaning to reduce the possibility of serious injury DO NOT connect or disconnect cables to or from the power supply or LED light bar while energized Test all cable connections for correct and secure engagement after installation SCREW-LOCK (THREADED) CONNECTOR INSTALLATION INSTALLATION OF THE DC POWER CABLE TO THE LED LIGHT BAR...
- Page 5 AC AND DC CABLE INSTALLATION INSTALLATION OF THE AC POWER CABLE TO THE POWER SUPPLY The AC power cable uses a screw-lock type M19 3-pin connector to connect the cable to the power supply. The connection to power is available in several plug types for receptacles, or in pigtails for direct wiring To Attach or Remove the Connectors: To install the connector, match up the keyed pins on the cable (male to female) to the receptacle and push it on Twist the locking ring on the connector...
- Page 6 ASSEMBLY INSTRUCTIONS Unbox RAY fixture and place on flush, stable surface Take caution when handling RAY fixtures. To mount fixture, refer to the instructions included in the hanging kit package with the associated accessories Hang the fixture in the Ensure the LED array does desired location and adjust the mounting height to at least 6”...
-
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS STOCK KEEPING UNIT (SKU) CONFIGURATOR & OPTIONS (Example SKU: R-22-I-1-06-N5-R) Family Model Spectrum Input Voltage AC Cord Length AC Plug Mounting Hardware 22” PhysioSpec Indoor 120-277 VAC 6 0’ (1 83m) NEMA 5–15P Standard ™ 44” PhysioSpec Greenhouse 120-277 VAC 15 0’... - Page 8 DIMENSIONS` LIGHT BAR DIMENSIONS AND WEIGHT [ TOP VIEW ] Item SKU Abb Length Width Height Weight 8’ (2 43m) 22" 2 2" 1 4" 1 3 lb RAY 22 RY-2-x-x-xx-xx-R 55 9 cm 5 6 cm 3 6 cm 0 6 kg 44"...
- Page 9 MAXIMUM AC INPUT AMPERAGE Spectrum AC Voltage 120 V 208 V 240 V 277 V Indoor 0 34 A 0 20 A 0 17 A 0 15 A Greenhouse 0 34 A 0 20 A 0 17 A 0 15 A Antho 0 38 A 0 22 A...
-
Page 10: Cautions And Warnings
• DO NOT connect to live power until installation is complete and all connections are made • DO NOT modify or alter the product; doing so will void the warranty Please refer to the Fluence Terms and Conditions and Limited Warranty for further details •... -
Page 11: California Proposition 65 Warning
LED manufacturer’s bin tolerance 2 Wattage values are typical expected values Fluence maintains a tolerance of ±10% on flux and power specifications Target light levels can vary from projected levels depending on ambient temperature, room reflections values and dirt accumulation... - Page 12 OUR PRODUCT GUARANTEE & WARRANTY Every RAY series system is engineered and built by Fluence Bioengineering using state-of-the-art robotics and hand craftsmanship. RAY series systems are guaranteed against manufacturing defects for five years from date of purchase. Contact us at support@fluence-led.com for more warranty information.
