SPYDR 2 Series

2x • 2p • 2i • 2h

USER MANUAL

IMPORTANT SAFETY PRECAUTIONS & EXPLANATION OF SYMBOLS . . . . . . . . . . . 2

CULTIVATION BEST PRACTICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

GENERAL CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

SYSTEM HARDWARE & ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

FIXTURE ASSEMBLY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

FIXTURE MOUNTING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

CAUTIONS & WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

PRODUCT GUARANTEE & WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Need help?

Do you have a question about the SPYDR 2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for FLUENCE SPYDR 2 Series

Page 1: Table Of Contents
SPYDR 2 Series 2x • 2p • 2i • 2h IMPORTANT SAFETY PRECAUTIONS & EXPLANATION OF SYMBOLS . . . . . . . . . . . 2 CULTIVATION BEST PRACTICES .
Page 2: Important Safety Precautions & Explanation Of Symbols
It is important you read, fully understand, and observe the subsequent safety precautions . If you are not comfortable with the installation of Fluence encourages everyone to experiment and pursue their own techniques . high performance lighting systems, you should seek the services of a Every crop is different and everyone has different goals .
Page 3: General Care
To limit degradation, avoid touching the diodes with your hands, even in a powered off state . For detailed instructions for maintenance and cleaning, please visit www.fluence.science/support-center/. SPYDR 2 is a high-performance lighting system. Do not touch while in operation.
Page 4: System Hardware & Accessories
SYSTEM HARDWARE & ACCESSORIES SYSTEM HARDWARE SPYDR 2x, 2p, 2i or 2h light fixture, pre-configured with A1 Standard DC cable Standard DC Cable Power Supply 600W, Power Supply for SPYDR 2i and 2p 320W, Power Supply for SPYDR2x 800W Power Supply for SPYDR 2h MOUNTING HARDWARE OPTIONS (depending on your selection at the time of purchase) Waterfall Mount...
Page 5: Fixture Assembly Instructions
FIXTURE ASSEMBLY INSTRUCTIONS Take caution when handling light bars. Ensure the LED array does not come in contact with sharp objects or force that may damage the diodes. Unbox and unfold light bar module . Place on flush, stable surface . Make sure LEDs are facing down . Install power supply brackets to power supply and then to light bar module .
Page 6: Fixture Mounting Instructions
FIXTURE MOUNTING INSTRUCTIONS SPYDR 2 Series fixtures ship with your choice of hanging hardware . To mount your SPYDR 2 fixture, start by identifying a suitable support structure to hang your fixture from . Common support structures include pallet racks, rolling tables, Unistrut, trusses, and structural channel . For optimal results, two people are recommended to mount the fixtures .
Page 7 WATERFALL MOUNTS RACK Suggested application: Ideal for waterfall (wire) decking on pallet racks or rolling tables. Hardware included: long or short “V” mounts. For proper uniformity and flexibility for adjustments, position SPYDR with light bars perpendicular to the length of the rack. To mount your SPYDR using waterfall mounts, place SPYDR fixture gently below the desired hanging area .
Page 8 WATERFALL MOUNTS CONTINUED Adjust SPYDR module to ensure full contact is made on the hooks of the mounting hardware . With all four mounting brackets attached to the SPYDR module, you can adjust the mounting hardware along the waterfall deck or adjust the SPYDR module along the contact points on the mounting hardware to center on the 4’...
Page 9 SOLID DECKING MOUNTS CONTINUED Left decking to loop each mount on the cross bar, positioned above light bar located second from the end . NOTE: do not attach mounting hardware to the end light bars. Once all four brackets are in place, use two people to lift the fixture up to the mounting hardware .
Page 10 LANCE HANGERS AND ADJUSTABLE KIT Suggested application: Ideal for two-point hanging from areas with high clearance, such as ceilings or other support structures. Hardware included: 2 lance hangers (and adjustable Gripple kit if upgraded at the time of purchase). Before you mount the SPYDR module, complete the steps to attach the power supply to the light bars as outlined in the User Guide .
Page 11 LANCE HANGERS AND ADJUSTABLE KIT CONTINUED Once both hangers are in place, use two people to lift the fixture to the installed handing hardware . Be sure to hang from the center of the lance hanger to ensure a balanced fixture . If using the Adjustable Hanger Kit, hook the Gripple hooks on each lance hanger .
Page 12 RACKS WITH TRAYS AND VAS CONTINUED “CLICK” Hook one of the wire hangers on the 2nd bridge lance furthest from the hinge . Bring wire around the end light bar such that it fits around the end connector as shown . Hook the other end of the wire hanger into slots on the rack system .
Page 13 REMOTE MOUNTING THE POWER SUPPLY (2X, 2P, AND 2I ONLY) Bracket must be perpendicular to PSU to fit into receiver holes . (2) PSU Mounting Brackets...
Page 14: Cautions & Warnings
ETL Rating: SPYDR 2 fixtures are rated suitable for wet locations . A “wet location” is defined as an interior or exterior location in which water or other liquids may drip, splash or flow on or against the electrical components of a lighting fixture . SPYDR 2 Series fixtures and power supply are certified to meet UL standards...
Page 15 WARNING bevor Sie ihn bewegen oder säubern. Der Leuchtkörper võtmist esmalt lahti kaitselüliti ja seejärel eemaldage Elektromos áramütés veszélye. A súlyos sérülések und das Netzteil sind für Nassbereiche gemäß UL 1598 vooluvõrgust vette kastetud komponendid. Silmakahjus- megelőzése érdekében mindig tegye meg a megfelelő zertifiziert, dürfen jedoch nicht unter Wasser getaucht tuste vältimiseks vältige otse varjestamata LED-idesse óvintézkedéseket, és tisztítás vagy áthelyezés előtt...
Page 16 pertraukiklį, tada atjunkite panardintus komponentus, OSTRZEŻENIE (PL) Конструкция устройства и блок питания соответствуют radne elemente nikada nemojte stavljati okrenute licem o tada ištraukite iš vandens. Kad apsaugotumėte akis, Ryzyko porażenia prądem elektrycznym. Aby zmniejszyć требованиям эксплуатации в сырых помещениях ka ravnoj površini. Uvek omogućite dovoljnu ventilaciju stenkitės nežiūrėti tiesiogiai į...
Page 17 positivo: Non smaltire con i rifiuti domestici! Lo smal- Identifikacija izdelka v smislu OEEO: Ne zavrzite (SELV) que no exceda los voltajes superiores timento corretto del prodotto e dell’imballaggio deve med gospodinjske odpadke! Izdelek in embalažo je a SELV. P O produto protege contra o risco de essere effettuato secondo la legge nazionale ap- treba med odpadke zavreči ustrezno in v skladu z choque eletrico com a tensao de seguranca muito...
Page 18 įtampa (SELV) neviršija SELV įtampos. LV Produkts alapvető kovetelmenyeit es vonatkozo előirasait. jer.UKCA-merkteken: Signify verklaart dat dit product izjavlja, da je ta izdelek v skladu z osnovnimi us- pasargā no elektrošoka riska, jo tam ir izteikti zema PL Oznakowanie CE: firma Signify oświadcza, voldoet aan de fundamentele relevante wettelijke treznimi zakonskimi instrumenti Združenega kraljest- strāva (SELV), kas nepārsniedz strāvas līmeni virs...
Page 19 SPYDR 2H Photobiological risk group 2: CAUTION DO radiação óptica possivelmente perigosa emitida располагать так, чтобы не предполагалось possibly hazardous optical radiation emitted from SPYDR 2H Photobiologische Risikogruppe 2: por este produto; Não olhe fixamente para a lâm- длительное вглядывание в светильник с this product;...
Page 20: Product Guarantee & Warranty
OUR PRODUCT GUARANTEE & WARRANTY Every SPYDR 2 series system is engineered and built by Fluence Bioengineering using state-of-the-art robotics and hand craftsmanship. All SPYDR 2 series systems are guaranteed against manufacturing defects for five years from date of purchase. Contact us at support@fluence-led.com...

This manual is also suitable for:

Spydr 2x Spydr 2p Spydr 2i Spydr 2h
