FLUENCE RAY Series User Manual

Hide thumbs Also See for RAY Series:

Advertisement

Quick Links

Download this manual
RAY Series
RAY 22
RAY 44
RAY 66
USER MANUAL
BEST PRACTICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GENERAL CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SYSTEM HARDWARE & ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . 6
ASSEMBLY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
CAUTIONS & WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PRODUCT GUARANTEE & WARRANTY . . . . . . . . . . . . . . . . . . . . . . 12

Advertisement

loading
Need help?

Need help?

Do you have a question about the RAY Series and is the answer not in the manual?

Questions and answers

Related Manuals for FLUENCE RAY Series

Summary of Contents for FLUENCE RAY Series

  • Page 1: Table Of Contents

    RAY Series IMPORTANT SAFETY PRECAUTIONS & EXPLANATION OF SYMBOLS . . . . . 2 BEST PRACTICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 GENERAL CARE .

  • Page 2: Important Safety Precautions & Explanation Of Symbols

    AND EXPLANATION OF SYMBOLS • Please read this manual thoroughly before attempting to install or operate any Fluence RAY Series system . • After successful installation and configuration of the system, be sure to retain this manual in a safe place for future reference . Safety is a key component to a long lasting and trouble free installation .

  • Page 3: Best Practices

    • Mount the fixture at least 6” from the top of your canopy to ensure optimal uniformity and consistent PPFD . The RAY Series was designed to 1 . The power-supply cord or the plug has been damaged . provide uniform light dispersion and requires precise deployment . A 1”...

  • Page 4: General Care

    Never use a cloth to clean the diode array . Doing so can scratch or • RAY Series systems are passively cooled with zero moving components . compromise the integrity of the silicon seal, or dislodge diodes entirely . They are designed for harsh environments and years of maintenance-free performance .
  • Page 5 RAY is a high-performance lighting system. Do not touch while in operation. PLEASE RECYCLE ALL PACKAGING MATERIAL...

  • Page 6: System Hardware & Accessories

    SYSTEM HARDWARE & ACCESSORIES SYSTEM HARDWARE RAY fixture pre-configured with: 8’ Cord with Male DC Connector Power Supply pre-configured with: 14” Cord with Male AC Connector 13 .5” Cord with Female DC Connector 13 .5” Cord with 3-Pin Waterproof Dimming Connector and Dust Cap (dimmer sold separately) Pigtail Dimming Adapter (purple/gray leads) ACCESSORIES...

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Unbox RAY fixture and place on flush, stable surface . Take caution when handling RAY fixtures. To mount fixture, refer to the instructions included in the hanging kit package with the associated accessories . Ensure the LED array does Hang the fixture in the desired location and adjust the mounting height to at least 6”...

  • Page 8: Technical Specifications

    TECHNICAL SPECIFICATIONS STOCK KEEPING UNIT (SKU) CONFIGURATOR & OPTIONS (Example SKU: R-22-I-1-06-N5-R) Family Model Spectrum Input Voltage AC Cord Length AC Plug Mounting Hardware 22” PhysioSpec Indoor 100-277V 6 .0’ (1 .83m) NEMA 5–15P Standard ™ 44” PhysioSpec Greenhouse 15 .0’ (4 .57m) NEMA 6–15P ™...
  • Page 9 DIMENSIONS RAY 22 1 .3 lb (0 .6 kg) 22” x 1 .4” x 2 .2” ((55 .9 cm x 3 .6 cm x 5 .6 cm) RAY 44 2 .2 lb (1 .0 kg) 44” x 1 .4” x 2 .2” (111 .8 cm x 3 .6 cm x 5 .6 cm) RAY 66 3 .1 lb (1 .4 kg) 66”...
  • Page 10 MAXIMUM AC INPUT AMPERAGE Spectrum AC Voltage 120 V 208 V 240 V 277 V Indoor 0 .34 A 0 .20 A 0 .17 A 0 .15 A Greenhouse 0 .34 A 0 .20 A 0 .17 A 0 .15 A Antho 0 .38 A 0 .22 A...

  • Page 11: Cautions & Warnings

    LED manufacturer’s bin tolerance . 2 Wattage values are typical expected values . Fluence maintains a tolerance of ±10% on flux and power specifications . Target light levels can vary from projected levels depending on ambient temperature, room reflections values and dirt accumulation .

  • Page 12: Product Guarantee & Warranty

    OUR PRODUCT GUARANTEE & WARRANTY Every RAY series system is engineered and built by Fluence Bioengineering using state-of-the-art robotics and hand craftsmanship. RAY series systems are guaranteed against manufacturing defects for five years from date of purchase. Contact us at support@fluence-led.com for more warranty information.

This manual is also suitable for:

Ray 22Ray 44Ray 66
