ABW5XTR T13H7EHHSTW WTV19HHP APB5NAG T13H7EHHSTP T13H7EHHSTP APB5XTR WTV19HHM ASS5NAG T13H7EHHST2 ASS5XTR T13H7EHHST2 (Pb,Cd,Hg,Cr6+,PBB,PBDE,DIBP,DBP,BBP,DEHP) (Pb,Cd,Hg,Cr6+,PBB,PBDE,DIBP,DBP,BBP,DEHP) and details should comply with LG standard of LG(THWM)-B-4501-16 LG(THWM)-B-4501-16 Sasipa T. Chatchai An. Naret H. For V+ H700 HEDD suffix NAG/XTR 26/09/2022 26/09/2022 26/09/2022 MFL71959001...
Preparing the Wash Load ................14 Adding Detergents, Softeners and Bleaches..........16 Control Panel ....................18 Programme Table ....................21 Extra Options and Functions ................25 SMART FUNCTIONS LG ThinQ Application ..................29 Smart Diagnosis ....................31 MAINTENANCE Cleaning after Every Wash................33 Cleaning the Appliance Periodically ..............33 TROUBLESHOOTING...
global_main.book.book Page 3 Friday, October 7, 2022 10:05 AM SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below.
Page 5
• The inlet water pressure must be between 50 and 800 kPa. Maximum Capacity The maximum capacity in some cycles for dry clothes to be washed is: WTV17HHD / WTV17HHW WTV19HHP / WTV19HHM 17 kg 19 kg Installation •...
Page 6
global_main.book.book Page 5 Friday, October 7, 2022 10:05 AM SAFETY INSTRUCTIONS • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
Page 7
• Make sure that drainage is working properly. If water is not drained properly, your floor may get flooded. • If, during spinning, opening the door does not stop the drum within about 10 seconds, immediately discontinue operating the appliance and contact your dealer or LG Electronics service centre.
Page 8
• Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
Accessories *1 The included accessories vary depending on the model you purchased. *2 This accessory is not included in the product, but you can purchase it from the LG service centre. Door Tempered Glass Dispenser Drawer Cold and Hot Water Inlet Hoses...
Page 10
Page 9 Friday, October 7, 2022 10:05 AM INSTALLATION Model WTV17HHD / WTV17HHW WTV19HHP / WTV19HHM Max. Watt 1500 W Annual Energy Consumption 312 kWh 306 kWh Annual Water Consumption 42020 L 41800 L IP No.(Degree of protection) IPX4 Dimension(mm) D’...
Contact your local 2 cm 2 cm 10 cm authorised LG repairer. • The power plug must be plugged into an WARNING appropriate outlet socket that is installed and • This appliance must only be used for domestic...
global_main.book.book Page 11 Friday, October 7, 2022 10:05 AM INSTALLATION Connecting the Water Inlet Connecting the Hose to the Water Tap Hoses Connecting Screw-Type Hose to Tap with Thread Before connecting the water inlet hose to the water Screw the hose connector onto the water supply tap, check the hose fitting type and follow the tap.
global_main.book.book Page 12 Friday, October 7, 2022 10:05 AM INSTALLATION Installing the Drain Hose Adjusting and Levelling the Feet Before connecting the drain hose, check your drain hose model and follow the instructions for that When the appliance is not perfectly level, turn the model.
Page 14
global_main.book.book Page 13 Friday, October 7, 2022 10:05 AM INSTALLATION Insert the anti-rat cover to the assembling bracket from the back of the appliance. Insert the 2 screws into the holes to assemble the anti-rat cover to the appliance.
global_main.book.book Page 14 Friday, October 7, 2022 10:05 AM OPERATION OPERATION Operation Overview • When the cycle is finished, a melody will sound. Immediately remove your clothing from the appliance to reduce wrinkling. Using the Appliance NOTE Before the first wash, select the Normal programme and add a half amount of detergent.
Page 16
global_main.book.book Page 15 Friday, October 7, 2022 10:05 AM OPERATION Checking the Fabric Care Label cause irreparable damage to both your appliance and clothes. This will tell you about the fabric content of your clothes and how it should be washed. Symbols on the Care Labels Symbol Wash / Fabric type...
global_main.book.book Page 16 Friday, October 7, 2022 10:05 AM OPERATION Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring Detergent Dosage diluted liquid detergent into the drum might cause the clothes to be damaged, bleached, •...
Page 18
global_main.book.book Page 17 Friday, October 7, 2022 10:05 AM OPERATION Adding Fabric Softeners bleach dispenser . Avoid splashing or overfilling. Add a fabric softener to the maximum fill line. • If the softener is concentrated, then it should be diluted. •...
With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use this function, refer to SMART FUNCTIONS. Wi-Fi Press and hold the Water button for 3 seconds to initiate the connection of the appliance to the LG ThinQ application. START/PAUSE Button •...
Page 20
global_main.book.book Page 19 Friday, October 7, 2022 10:05 AM OPERATION Cycle Status Indicator • The indicators tell you which stage is running and remains during the programme. : Soaking stage : Washsing stage : Rinsing stage : Spinning stage NOTE •...
Page 21
global_main.book.book Page 20 Friday, October 7, 2022 10:05 AM OPERATION This icon lights up when the Temp. option in Hot is activated. This icon lights up when the Temp. option in Cold is activated.
global_main.book.book Page 21 Friday, October 7, 2022 10:05 AM OPERATION Programme Table Washing Programme Wash programmes are designed for the best wash performance for different types of clothes. • Press the washing programme button to select the desired programme. • When you select a wash programme, the light for the corresponding wash programme will turn on. Normal Description Use this programme to wash normal laundry.
Page 23
global_main.book.book Page 22 Friday, October 7, 2022 10:05 AM OPERATION Allergy Care Description This programme is specifically designed for reducing certain allergens at a powerful, high temperature. • Stains that can be easily removed with this programme are coffee, soda, juice, soy sauce etc.
Page 24
global_main.book.book Page 23 Friday, October 7, 2022 10:05 AM OPERATION Duvet Description Use this programme to wash a blanket or bedclothes that have the hand wash sign on the care label. • Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket, infilling (polyester 101), and bed sheets might be damaged if they are allowed to float.
Page 25
global_main.book.book Page 24 Friday, October 7, 2022 10:05 AM OPERATION Test in Conformity with SASO 2885 Set programmers at "Cotton+40 ℃ (Half Load)", "Cotton+60 ℃ (Half Load)" ,"Cotton+60 ℃ (Full Load)" option for test in conformity with SASO 2885 • Cotton 40 ℃ (Half Load) : Normal course + Steam + Soak 3 hours + Cold Wash + Water Level 8 + Wash 25 min + Rinse 2 times + Spin "Mid"...
global_main.book.book Page 25 Friday, October 7, 2022 10:05 AM OPERATION Standard 60 ℃ Normal programme Standard 40 ℃ Normal programme (Half Full Load Half Load Load) Number of washing cycles Water Consumption during washing cycle (liter) Duration of each washing Cycle (minutes) Number of rinse cycles Water Consumption of each rinse cycle...
Page 27
global_main.book.book Page 26 Friday, October 7, 2022 10:05 AM OPERATION Using Special Options during operation depending on the selected programmes, options and functions. You can customize the programmes by using the Customising a Washing following special options: Programme Steam Adding this option helps provide better cleaning Each programme has default settings that are results.
Page 28
global_main.book.book Page 27 Friday, October 7, 2022 10:05 AM OPERATION Using Basic Options NOTE Delay End • Once this function is set, all buttons are locked Use this function to delay ending time. The except the POWER button. appliance will start automatically and finish after a •...
Page 29
global_main.book.book Page 28 Friday, October 7, 2022 10:05 AM OPERATION Beeper • Press and hold the Quick Wash buttons for 3 Use this option to adjust the volume of the sound seconds to adjust the volume of the sound and and turn the beeper off or on.
Page 29 Friday, October 7, 2022 10:05 AM SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application notifications on a smartphone. The notifications are triggered even if the LG ThinQ application is off. The LG ThinQ application allows you to communicate with the appliance using a smartphone.
Page 31
• The wireless network name (SSID) should be a Run the LG ThinQ app and sign in with your combination of English letters and numbers. (Do existing account or create an LG account to not use special characters.)
Page 31 Friday, October 7, 2022 10:05 AM SMART FUNCTIONS turned off remotely from the application or this • Launch the LG ThinQ application and select the function is disabled. Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ •...
Page 33
global_main.book.book Page 32 Friday, October 7, 2022 10:05 AM SMART FUNCTIONS NOTE • For best results, do not move the smartphone while the tones are being transmitted.
global_main.book.book Page 33 Friday, October 7, 2022 10:05 AM MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. •...
Page 35
global_main.book.book Page 34 Friday, October 7, 2022 10:05 AM MAINTENANCE Cleaning the Water Inlet Filter NOTE Water inlet filter collects lime or any small objects • For models without a lint filter, the lint is that may be in water supplied to the appliance. discharged when the water drains during Clean the water inlet filter regularly.
Page 36
global_main.book.book Page 35 Friday, October 7, 2022 10:05 AM MAINTENANCE • Be careful not to get your fingernails caught in Close the lid and then insert the lower part of the filter when you handle the filter. the filter into the wash drum. Press the top of the filter until you hear a click sound.
Page 37
global_main.book.book Page 36 Friday, October 7, 2022 10:05 AM MAINTENANCE Remove any foreign objects and fluff inside pump casing and from the filter. Insert the filter along the guide ribs inside the pump casing and turn the cap clockwise to refit the cap.
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting.
Page 39
global_main.book.book Page 38 Friday, October 7, 2022 10:05 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Foreign objects, such as coins, pins, clips, etc.,are caught between the pulsator and the inner drum. FOREIGN OBJECTS ERROR • Turn off the appliance and then press the POWER button. Press the Spin button without selecting a cycle to drain and spin the laundry.
Page 40
global_main.book.book Page 39 Friday, October 7, 2022 10:05 AM TROUBLESHOOTING Symptoms Possible Cause & Solution A motor error has occurred. DRAIN MOTOR ERROR • Unplug the appliance and call for service. is not an error. This prevents children from changing cycles or operating the appliance.
Page 41
global_main.book.book Page 40 Friday, October 7, 2022 10:05 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance will not Appliance is unplugged. operate. • Make sure that the cord is plugged securely into a working outlet. Water supply is turned off. •...
Page 42
global_main.book.book Page 41 Friday, October 7, 2022 10:05 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Water leaking Drain hose has come out of drain or is not inserted far enough. • Tie drain hose to supply hose or standpipe to prevent it from coming out during drain.
Page 43
• Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance...
Page 44
global_main.book.book Page 43 Friday, October 7, 2022 10:05 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Your home appliance The wireless network name (SSID) is set incorrectly. and smartphone are • The wireless network name (SSID) should be a combination of English not connected to the letters and numbers.
