Make sure to always stop your vehicle in a safe place before operating these tions of this AXTON amplifier. Please read this manual carefully, before attempting the installation. functions. There are risks of causing an accident.
· 10-channel DSP-controlled preout (5 Volt) including REM out to control additional amplifiers DIMENSIONS A544DSP · Optical and coaxial Input to connect the High-Res Audio interface ABT50 or another Axton DSP · Optical Output to link the audio signal to another Axton DSP amplifier 177 mm ·...
Page 4
2* REM-Out: Connect this wire to the remote input of a separate amplifier, for example a mono amp for a subwoofer. A) Plug & Play: Find a place for the A544DSP and connect the optionally available car- specific wire (www.axton.de) to the amp, to the headunit and the cars main wire harness.
APP FUNCTIONS A544DSP For Android phones only: 1. Download the A544DSP_V1.0.apk by scan of the QR code or download from the Axton website www.axton.de. Install A544DSP_V1.0.apk to your Android smart phone. 2. Turn on Bluetooth, but do not pair the A544DSP in the Bluetooth settings.
So feel free to adjust the values by +/- 5 cm until you perceive a stable and accurate front staging. If you like an absolute exactly setup, contact your Axton dealer for a professional adjustment. The Time alignment settings also apply to the corresponding preamp outputs.
Page 7
Input EQ Output EQ Depending on the source it might be necessary to flatten the input signal to receive an accurate You can create your sound according to your settings in the EQ menu. Depending on the grade sound signal. This could be necessary especially in cars with basic OE speaker system without of required accuracy, you can adjust up to 15 bands of the parametric equalizer.
Page 8
Crossover In this menu you can assign a frequency band to the connected speakers that corresponds to their recommended operating range. You can choose independent crossover settings for each channel separately or for all left and right channels together. Simply use the button “Combine” in the lower right and choose to copy the values from the left channels to the right one or right to left.
Page 9
Wir danken Ihnen für den Kauf dieser innovativen AXTON Endstufe. SICHERHEITSHINWEISE Damit Sie die Wiedergabequalität und die Leistungsfähigkeit dieses Verstärkers voll ausschöpfen Bedienen Sie keine Funktion, die Sie während der Autofahrt ablenken könnte. können, bitten wir Sie, sich eingehend mit den Möglichkeiten und technischen Features dieses Funktionen, welche Ihre besondere Aufmerksamkeit erfordern, dürfen ausschliesslich...
Page 10
· Optischer und koaxialer Eingang für das High-Res Audio Interface ABT50 oder einen anderen 177 mm Axton DSP · Optischer Ausgang zum Verlinken des Signals zu einem weiteren Axton DSP Verstärker · Bluetooth Audio Streaming mit automatischer Quellenumschaltung · Plug’N’Play Installation mit optionalen fahrzeugspezifischen Anschlusskabeln ·...
Page 11
2* REM-Out: Schliessen Sie dieses Kabel an den Remote-Eingang eines separaten Verstärkers an, zum Beispiel einen Monoblock für einen Subwoofer. A) Suchen Sie sich einen geeigneten Platz für den A544DSP und verbinden Sie das optionale Anschlusskabel (siehe www.axton.de) mit dem Verstärker. Stellen Sie den...
Page 12
4. Öffnen Sie die A544DSP App und berühren Sie den “Connect” Button, um den Verstärker mit der App zu verbinden. Nur für iOS Smartphones: 1. Gehen Sie in den Apple AppStore, suchen Sie nach „A544DSP“ und laden Sie die App auf Ihr Smartphone. Connect/Verbinden 2.
Page 13
Sie können die Werte also gerne um +/- 5 cm anpassen, bis Sie eine stabile und genaue Bühnenabbildung wahrnehmen. Wenn Sie eine absolut exakte Einstellung wünschen, wenden Sie sich für eine professionelle Einmessung an Ihren Axton-Händler. Die Time Alignment-Einstellungen gelten auch für die entsprechenden Vorverstärkerausgänge.
Page 14
Input EQ/Eingangs-Equalizer Output EQ/Ausgangs-Equalizer Je nach Quelle kann es notwendig sein, das Eingangssignal zu glätten, um ein genaues Tonsignal Sie können Ihren Sound entsprechend Ihren Einstellungen im EQ-Menü gestalten. Je nach dem zu erhalten. Dies kann vor allem bei Fahrzeugen mit einem einfachen OE-Lautsprechersystem Grad der erforderlichen Genauigkeit können Sie bis zu 15 Bänder des parametrischen Equalizers ohne separate Hochtöner erforderlich sein.
Page 15
What is the validity period of AXTON’s Warranty? Under this Warranty, AXTON warrants, for a period of 2 years, that the product is free from defects in material and/or workmanship at the time of the original purchase. This 2-year period commences on the date of the original purchase as per the original invoice or until receipt. If you have purchased the product as a consumer, and the defect is identified within the first six months after the original purchase (see above), we will assume that the defect already existed at the time of purchase.
Schweiz („räumlicher Geltungsbereich“) von einem autorisierten Fachhändler erwerben. Für welchen Zeitraum gewährt AXTON die Garantie? Mit dieser Garantie gewährt AXTON für den Zeitraum von 2 Jahren, dass das Produkt zum Zeitpunkt des Ersterwerbs keine Material- und/oder Verarbei- Date of purchase / Kaufdatum: tungsfehler aufweist.
