- Page 1 TECHNICAL MANUAL JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators JBSFS42NMX00 JBSFS48NMX00 JBSS42E22L00 JBSS48E22L00 KBSD702M*S00 KBSD706MPS00 KBSD708M*S00 KBSN702M**00 KBSN708M**00 W11636548 Rev A...
- Page 2 FOREWORD This Technical Manual (Part No. W11636548 Rev A), provides the In-Home Service Professional with service information for the “JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators.” The Wiring Diagram used in this Technical Manual is typical and should be used for training purposes only. Always use the Wiring Diagram supplied with the product when servicing the refrigerator.
-
Page 3: Table Of Contents
TABLE OF CONTENTS JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators SECTION 1: GENERAL INFORMATION ................. 1-1 SAFETY ..............................1-2 PRODUCT SPECIFICATIONS ......................... 1-3 PRODUCT FEATURES ........................... 1-8 MODEL NUMBER NOMENCLATURE ....................1-14 MODEL NUMBER AND SERIAL NUMBER LABEL LOCATION ............. 1-16 TECH SHEET LOCATION ........................ - Page 4 Notes JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators...
-
Page 5: Section 1: General Information
GENERAL INFORMATION Section 1: General Information This section provides general safety, parts, and information for the “JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators.” ■ Safety ■ Product Specifications ■ Product Features • Using the Controls ■... -
Page 6: Safety
GENERAL INFORMATION (CONT.) Safety Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. -
Page 7: Product Specifications
GENERAL INFORMATION (CONT.) Product Specifications JennAir® Built-In Side by Side Refrigerators AHAM Volumes And Shelf Area Freezer Volume (cu ft) 9.2 or 10.3 Refrigerator Volume (cu ft) 16.3 or 19.1 or 25.5 Total Volume (cu ft) 25.5 or 29.4 Bottle Capacity Dimensions Capacity (cu ft) 25.5 or 29.4... - Page 8 GENERAL INFORMATION (CONT.) Controls Automatic Defrost Control Location Exterior or Interior Up Front Control Type Electronic Door Ajar/Open Alarm Max Cool/Fast Cool Sabbath Mode Water Filter Indicator/Reset Refrigerator Compartment Door Bins 1 Full-Width Gallon 3 Adjustable Full-Width Lighting Non Climate Control Drawers 2 Full Width Number of Interior Shelves Shelf Supports...
- Page 9 GENERAL INFORMATION (CONT.) Certifications CEE Tier Tier I Prop 65 Standard Star K Certified Energy Star® Qualified ENERGY STAR® Qualified Electrical Amps Volts KitchenAid® Built-In Side by Side Refrigerators AHAM Volumes And Shelf Area Freezer Volume (cu ft) 7.3 or 8.8 or 9.2 or 10.3 or 10.9 Refrigerator Volume (cu ft) 13.5 or 16.3 or 19.1 Total Volume (cu ft)
- Page 10 GENERAL INFORMATION (CONT.) Exterior Base Grille Color Black Cabinet Color Grey Cabinet Finish Smooth Door Color Black Stainless Steel or Panel Ready or Stainless Steel or Stainless Steel with PrintShield Finish Door Finish Smooth Door Style Flat Fingerprint Resistant Handle Color Stainless Steel Handle Material Metal...
- Page 11 GENERAL INFORMATION (CONT.) Freezer Compartment Door Bins 3 Adjustable Full-Width or 5 Adjustable Full-Width Freezer Drawer/Basket 1 Fixed Full Width Upper 2 Full Width Lower Freezer Number of Shelves Light Shelves 2 Fixed Full Width Wire 4 Adjustable Full Width Wire Dispenser Dispenser Options Light...
-
Page 12: Product Features
GENERAL INFORMATION (CONT.) Product Features 1. Fully Integrated and Flush Design with Articulating Hinge Creates an integrated appearance with custom cabinetry without exposed hinges or trim pieces. 2. Adjustable Door Bins with Metal Accents Refrigerator and freezer door bins can be positioned to accommodate a variety of container sizes. 3. - Page 13 GENERAL INFORMATION (CONT.) Using The Controls Dispenser Control Panel Non-Dispenser Control Panel 2. Setting the Temperature F°/C° IMPORTANT: Dispensing Models n The refrigerator control adjusts the refrigerator compartment Press and hold the Max Cool and Crisper buttons at the same temperature.
- Page 14 GENERAL INFORMATION (CONT.) 5. Max Cool/Max Freeze 7. Vacation Care The Max Cool feature assists with periods of heavy ice usage, full Vacation grocery loads, or temporarily warm room temperatures. If You Choose to Leave the Refrigerator On While You’re Away: n Press MAX COOL to turn ON the Max Cool feature.
- Page 15 GENERAL INFORMATION (CONT.) Power Outage Style 2 (Non-Dispenser Models) IMPORTANT: After connecting the refrigerator to a water source The power outage indicator lets you know if the power supply to the refrigerator has been cut off and the freezer temperature has or replacing the water filter, fill and discard two full containers of risen to 18°F (–...
- Page 16 GENERAL INFORMATION (CONT.) Water Dispenser 2. Press a sturdy glass against the ice dispenser pad. Hold the glass close to the dispenser opening so ice does not fall To Dispense Water: outside of the glass. 1. Press a sturdy glass against the water dispenser pad. NOTE: IMPORTANT: You do not need to apply a lot of pressure to n While dispensing water and for 3 seconds after...
- Page 17 GENERAL INFORMATION (CONT.) Measured Fill Calibrate Measured Fill Household water pressure may affect the accuracy of the Measured Fill feature. For optimum performance of your water dispenser, you must first calibrate Measured Fill. Start Calibration Mode 1. Press and hold the Measured Fill button for 3 seconds to enter Calibration Mode. The button will display along with the 0.2 L or 8 oz default settings.
-
Page 18: Model Number Nomenclature
GENERAL INFORMATION (CONT.) Model Number Nomenclature JennAir® Model Number Nomenclature Model Number INTERNATIONAL SALES OR MARKETING CHANNEL Brand J = JennAir® Category B = Built-In Refrigeration Configuration S = Side-by-Side Installation F = Flush Install (84 Inch tall) S = Standard Install (84 Inch tall) Product Detail S = SxS Size (Width) - Page 19 GENERAL INFORMATION (CONT.) Model Number Nomenclature KitchenAid® Model Number Nomenclature Model Number INTERNATIONAL SALES OR MARKETING CHANNEL Brand K = KitchenAid® Category B = Built-In Refrigeration Configuration S = Side by Side Product Detail D = External Ice and Water N = Non Dispenser Feature Pack 70 = Platinum Interior...
-
Page 20: Model Number And Serial Number Label Location
GENERAL INFORMATION Model Number and Serial Number Label Location Model Number and Serial Number Label Location Tech Sheet Location Tech Sheet Location 1-16 JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators... -
Page 21: Section 4: Component Access
COMPONENT ACCESS Section 4: Component Access This section provides service parts access, removal, and replacement instructions for the “JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators.” ■ Top of the Refrigerator • Removing the Front Decorative Cover •... -
Page 22: Top Of The Refrigerator
COMPONENT ACCESS (CONT.) Top of the Refrigerator Removing the Front Access Panel WARNING 1. Remove two (2) 1/4" screws and remove the cover over the ON/OFF switch. Electrical Shock Hazard Disconnect power before servicing. Replace all parts and panels before operating. Failure to do so can result in death or electrical shock. - Page 23 COMPONENT ACCESS (CONT.) Removing the Unit Top Cover 3. Remove two (2) 1/4" hex head screws from the power switch and humidity sensor mounting bracket, then remove the 1. Remove four (4) 1/4" screws from the right side and six (6) bracket.
- Page 24 COMPONENT ACCESS (CONT.) Removing the Light Switches 5. Disconnect the two (2) or three (3) wires (depends on model). 1. Complete the steps from section Removing the Front Decorative Cover. 2. Light switches are located on the left and right hinge at the top of the doors.
- Page 25 COMPONENT ACCESS (CONT.) Removing the Condenser Fan Assembly Accessing the Compressor and Inverter 1. Complete the steps from section Removing the Front 1. Complete the steps from section Removing the Front Decorative Cover. Decorative Cover. 2. Complete the steps from section Removing the Front 2.
-
Page 26: Inside The Refrigerator Compartment (Rc)
COMPONENT ACCESS (CONT.) Inside the Refrigerator Compartment (RC) 3. Disconnect the wire harness available on the right side. WARNING Electrical Shock Hazard Disconnect power before servicing. Replace all parts and panels before operating. Removing the RC Upper Air Diffuser Failure to do so can result in death or electrical shock. - Page 27 COMPONENT ACCESS (CONT.) Removing the RC Lower Air Diffuser and 2. Remove the four (4) 1/4" hex head screws and disconnect the wire harness to remove the assembly. Thermistor Assembly 1. Remove drawer to locate the air diffuser assembly. 3. Remove the gasket and foam to remove the air baffle. 2.
- Page 28 COMPONENT ACCESS (CONT.) Removing the RC Thermistor 4. Gently remove the gasket as you will re-use it. 1. Locate the Thermistor cover on the left side of the back wall. 2. Pull on cover from the left side to remove. 5.
-
Page 29: Inside The Freezer Compartment (Fc)
COMPONENT ACCESS (CONT.) Inside the Freezer Removing the Water Reservoir (Dispensing Units Only) Compartment (FC) 1. The water reservoir is located under the lower diffuser and thermistor assembly. The lower drawers will need to be WARNING removed. Electrical Shock Hazard Disconnect power before servicing. - Page 30 COMPONENT ACCESS (CONT.) Removing the Evaporator Cover 2. Remove four (4) sliders and eight (8) shelf studs. 1. Remove all drawers and shelves below the ice maker. Figure - Removing the Sliders Figure - Removing the Shelf Studs 4-10 JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators...
- Page 31 COMPONENT ACCESS (CONT.) 3. Remove thirteen (13) 1/4" hex head screws and remove 3. Remove four (4) 1/4" hex head screws. cover. 4. Disconnect the wire harness. 5. Lift the fan assembly from the bottom and pull out. Removing the Evaporator Fan 1.
- Page 32 COMPONENT ACCESS (CONT.) Removing the Evaporator Thermistor Removing the Ice Maker Assembly (Non-dispensing Units Only) 1. Complete the steps from section Removing the Evaporator Cover. 1. Loosen two (2) 1/4" hex head screws on top of the ice maker. 2. Complete the steps from section Removing the Evaporator Fan.
- Page 33 COMPONENT ACCESS (CONT.) Removing the Ice Maker Assembly Removing the Fill Tube Heater (Dispensing Units Only) (Non-dispensing Units Only) 1. Remove four (4) 1/4" hex head screws on bracket. Three (3) 1. Complete the steps from section Removing the Ice Maker are on the side wall and one (1) on ceiling wall.
- Page 34 COMPONENT ACCESS (CONT.) 5. Locate the fill tube from behind the refrigerator and remove 4. Remove center back panel by removing six (6) 1/4" hex head two (2) 1/4" hex head screws. screws. 6. Pull fill tube and water line out of refrigerator. Removing the Fill Tube (Dispensing Units Only) 1.
- Page 35 COMPONENT ACCESS (CONT.) Removing the Emitter Cover and Circuit 9. Locate cover over fill tube in front of compressor and remove three (3) 1/4" hex head screws and then remove the cover. Board (Dispensing Units Only) 1. Locate the Emitter on the outer wall and remove three (3) phillips head screws to remove cover and board.
-
Page 36: Fc Door (Dispensing Units Only)
COMPONENT ACCESS (CONT.) FC Door (Dispensing Units Only) Removing the Receiver Cover and Circuit Board (Dispensing Units Only) WARNING 1. Locate the Receiver on the inner wall and remove three (3) phillips head screws to remove cover and board. Electrical Shock Hazard Disconnect power before servicing. - Page 37 COMPONENT ACCESS (CONT.) Removing the Dispenser Pad Assembly 3. Remove door skin by removing three (3) phillips screws on top, six (6) phillips screws on the side and two (2) phillips 1. Complete the steps from section Removing the User screws on the bottom.
- Page 38 COMPONENT ACCESS (CONT.) Removing the Ice Door Motor Assembly Removing the Ice Auger Motor 1. Complete the steps from section Removing the User 1. Inside of the door, remove two (2) 1/4" hex head screws to Interface. remove the dispenser motor cover. 2.
-
Page 39: Under The Refrigerator
COMPONENT ACCESS (CONT.) 2. Remove four (4) 1/4" hex head screws and remove wiring 3. The harness connectors will catch on the back side of the harness to remove the dispenser motor. liner if pulled straight out. Under the Refrigerator WARNING Electrical Shock Hazard Disconnect power before servicing. - Page 40 COMPONENT ACCESS (CONT.) 2. Remove two (2) screws to remove the front grill. 3. Remove two (2) 1/4" hex head mounting screws from the front of the water valve housing, then collect the water valve housing. Figure - Water inlet valves with John Guest Fittings (Non-dispensing unit) Figure - Water inlet valves with John Guest Fittings (Dispensing unit)
-
Page 41: Back Of The Refrigerator
COMPONENT ACCESS Back of the Refrigerator 3. Remove four (4) 1/4" hex head screws to lower drain pan. WARNING Electrical Shock Hazard Disconnect power before servicing. Replace all parts and panels before operating. Failure to do so can result in death or electrical shock. - Page 42 COMPONENT ACCESS Notes 4-22 JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators...
- Page 43 PRODUCT SPECIFICATIONS & WARRANTY INFORMATION SOURCES IN THE UNITED STATES: FOR PRODUCT SPECIFICATIONS AND WARRANTY INFORMATION CALL: FOR WHIRLPOOL PRODUCTS: 1-800-253-1301 FOR TECHNICAL ASSISTANCE WHILE AT THE CUSTOMER’S HOME CALL: THE TECHNICAL ASSISTANCE LINE: 1-800-832-7174 HAVE YOUR STORE NUMBER READY TO IDENTIFY YOU AS AN AUTHORIZED IN-HOME SERVICE PROFESSIONAL FOR LITERATURE ORDERS (CUSTOMER EXPERIENCE CENTER): PHONE: 1-800-851-4605...
- Page 44 JennAir® and KitchenAid® 36", 42", and 48" Built-In Side by Side Refrigerators W11636548 Rev A...
