Operation Parameters - Custom Audio Electronics Scanner VeriPrint KUBE II User Manual

5.6 Operation parameters

This device allows the coniguration of the parameters listed in the following table.
The parameters marked with the symbol
Settings remain active even after the device has been turned off and they are stored in non-volatile memory.
PRINT MODE
AUTOFEED
CHARS / INCH
FONT TYPE
SPEED / QUALITY
PRINT WIDTH
PAPER THRESHOLD
D
are the default values.
Printing mode:
Normal D = enables printing in normal writing way
Reverse = enables printing rotated 180 degrees
Setting of the Carriage Return character:
CR disabled D = Carriage Return disabled
CR enabled = Carriage Return enabled
Font selection:
A = 11 cpi, B = 15 cpi
A = 15 cpi, B = 20 cpi D
NOTE: CPI = Characters Per Inch
Setting of the font type:
International D = Enables the use of the 256 characters font tables
Chinese GB18030 = Enables the use of the chinese extended font GB18030-2000
Korean CP949 = Enables the use of the korean font CP949
Setting of printing speed and printing quality:
Normal
High Quality
High Speed D
Width of printing area:
52 mm 60 mm
54 mm 62 mm
56 mm 64 mm
58 mm 66 mm
Threshold value (in percent) for the recognition of paper presence by the paper presence
sensor:
30% 60% 90%
40% 70%
50% 80% D
This parameter is not printed on setup report because it can be modiied only during setup
procedure by software (see
68 mm 76 mm
70 mm 78 mm
72 mm 80 mm D
74 mm
paragraph 5.2).
41
