- Page 1 U S ER G U I DE Air Wash 50/100/150 UGG037-0818 Operation Manual Corporate Of ce: 724.584. 5500 l Instant Access 24/7 (Parts and Service): 800.458.1960 l Parts and Service: 814.437.6861...
-
Page 2: Method Of Operation
Air Wash Operating Instructions: Method of operation: Thank you for purchasing a Conair Granulator Air There are 6 integral parts of the Air Wash system which Wash System. Please read these instructions prior work together to maximize the systems performance: to operation. - Page 3 How The Air Wash Works www.conairgroup.com The top mounted blower provides the required vacuum The patent pending diffuser (4) allows air to be injected to convey the material from grinder/and or bin to the at a variable rate at the bottom of the cyclone. By cyclone.(2) The material enters the cyclone tangential- injecting air 360 degrees around the diffuser (4) the ly.
- Page 4 The lighter material travels around the bottom The cyclone and diffuser combination assist with the plate and exits to the dust drum. Always consult with Conair before attempting to use primary cleaning. As discussed, the more air introdu- the open cyclone basket (3B).
-
Page 5: Initial Setup
Initial Set Up: www.conairgroup.com Once all the components of the Air Wash are installed Wash, the better the cleaning of the regrind. Observe properly and all the motors are turning in the correct the material being discharged underneath the rotation, we recommend the intitial settings of your cascaders and the dust drum. - Page 6 Basic Air Wash Unit...
- Page 7 www.conairgroup.com Spare parts list / Basic Air Wash Unit. Date: 2005, 10 Fig. Serial no. Part no. Pieces Notes 699116608 Air Wash Unit Main Stand 699116703 Air Wash Cyclone w. 10" Bottom Outlet Transition 699116605 Cyclone Basket for Air Wash Unit 699116790 Open Bottom Basket for Air Wash Cyclone 699116808...
-
Page 8: How To Contact Customer Ser Vice
We’re Here to Hel p Conair has made the largest investment in customer support in the plastics industry. Our service experts are available to help with any problem you might have installing and oper- ating your equipment. Your Conair sales representative also can help analyze the nature of your problem, assuring that it did not result from misapplication or improper use. -
Page 9: Performance Warranty
Equipment Guarante e www.conairgroup.com Conair guarantees the machinery and equipment on this order, for a period as defined in the quotation from date of shipment, against defects in material and workmanship under the normal use and service for which it was recommended (except for parts that are typi- cally replaced after normal usage, such as filters, liner plates, etc.).
