- Page 1 A COMPANY OF ATL DRONE Quick Start Guide V1.0...
-
Page 3: Introduction And Overview
Introduction and Overview LED Status Indicator Micro SD Card Port Camera Lens Gimbal... -
Page 4: Specifications
Specifications Gimbal General Number of Axis: Product Name: 3-Axis Gimbal Control Angle Accuracy: ± 0.02° Camera Model Name: E45S Weight: 440g Maximum Control Range: Tilt: -90° to 0°, Pan:165° Dimensions: 138x 133x113mm Environmental Maximum Control Speed: Tilt: 30°/s, Pan: 120°/s Operating Temperature Range: -10°C to 50°C... -
Page 5: Gimbal Installation
Gimbal Installation Assembling Step 1 Find the Unlocked Mark etched on the Gimbal Yaw Motor and align the Mark Line with the front of the damping plate. Step 2 Insert the Gimbal Yaw Motor into the damping plate and rotate it counterclockwise until the Mark Line of the Locked Mark aligns with the front of the damping plate to secure the gimbal. - Page 6 Gimbal Installation Disassembling Step 1 Hold the gimbal release button and rotate the Gimbal Yaw Motor clockwise until the Mark Line of the Unlocked Mark aligns with the front of the damping plate. Step 2 Pull the gimbal out from the damping plate. Notice: The X-connector series gimbal does not need a separate bin- ding.
- Page 7 WARNING 1 Do not try to repair the E45S. 2 Do not operate the E45S in the rain or in environments with high humidity. Wait until the initialization process is complete before touching or removing the camera. 3 The following language terms are used throughout the product literature to indicate various levels of potential harm when operating this product: a) If procedures are not correctly followed, there is a risk of device, property damage and personal injury.
- Page 8 5 Malfunction of the product caused by retrofitting or replacement with components which did not come from Yuneec. 6 Damage and/or injury caused by the use of replica parts (non-original parts).
-
Page 9: Eu Compliance Statement
Yuneec declares that this device complies with the essential requirements and other relevant provisions of the RED Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following internet address www.yuneec.com. Please visit the address above and enter the corresponding product page. - Page 10 This content is subject to change. Download the latest version from www.yuneec.com If you have any questions or inquiries about this document, please contact us by starting a conversation on www.yuneec.com Your local contact ATL Drone – Global Headquarters Rütistrasse 18, 8952 Schlieren, Switzerland...
