YUNEEC A-YNUK-BC02 Assembly Instructions Manual

Order Ref: A-YNUK-BC02
Thank you for purchasing the H520/H520E Bumper Cage.
The Bumper Cage has been developed to increase the operational safety of the aircraft and
get closer to objects with confidence and reduced risk of impacting propellers.
Each system is hand finished to ensure quality and includes a re-usable clear tube for transporting
all the rods and a cotton, pull string, bag to hold the motor arm clips when not in use.
Spare parts can be ordered on request.
It has been designed to fit onto both the H520 & H520E, and H3 System.
(The : A-YNUK-BC01
IMPORTANT
Before assembling the cage please ensure all the parts are included.
If any parts are missing please contact Yuneec UK immediately.
Care should be taken during assembly and disassembly that the rods do not cause injury.
Beware of the sharp points on the carbon rods when handling them.
An assembly video will be available on the Yuneec UK
Assembly Instructions
has been replaced by
WARNING - CHOKING & HANDLING HAZARDS
Small parts, and sharp points. Not suitable for children under 10 years
PLASTIC BAGS CAN BE DANGEROUS
To avoid danger of suffocation, please keep bags away from babies and children
: A-YNUK-BC02 version.)
website. www.yuneec.uk
