Evervue Ocea Pro Installation Manual

Ocea Pro Drill-Free Mount - Installation Manual
OK OK
Zepp Remote & Accessories
Ocea Pro Standard TV
(Located in the Compartment
on the back of Ocea Pro)
TV
Remote
Allen Key
3M Hook
Pads
Power Supply
Check the Items
1
Upon receiving your order, open the crate and inspect the
contents. Damages must be reported within 24 hours.
Mark the Holes
4
Place your TV wall box against the wall and mark
the holes where your hook pads will be placed.
Information is subject to change without prior notification.
© Copyright. Evervue USA Inc.
www.oceatv.com
Aluminum Frame
Aluminum Frame
Remove the Aluminum Frame
2
Using an allen key, remove the aluminum frame attached
to the TV.
Attach the Pads
5
Clean the wall by gently wiping isopropyl rubbing alcohol
on it, making sure there is no dust. Peel the protective
sticker at the back of the pads then stick them onto the wall
with the hooks facing in opposite directions. The placement
should match where the TV corners will be placed.
Back view of Ocea Pro
Ocea Pro
TV
Remove the TV Wall Box
3
Remove the TV wall box attached at the back.
Upwards
Downwards
Remove the Compartment Cover
6
Use a screwdriver to remove the compartment cover
located at the back of the TV.
TV Wall
Box
Compartment Cover
1
