Evervue Ocea Pro Installation Manual

Ocea Pro Swivel Mount - Installation Manual
OK OK
Allen Key
Zepp Remote &
Accessories
(Located in the Compartment
on the back of Ocea Pro)
TV
Remote
Swivel Mount
Power Supply
Check the Items
1
Upon receiving your order, open the crate and inspect the
contents. Damages must be reported within 24 hours.
Attach the Bracket to the Wall
4
Screw the swivel mount onto the wall.
Evervue USA Inc.
5020 Campus Drive,
#121, Newport Beach, CA 92660, U.S.A.
Ocea Pro Standard TV
Aluminum
Frame
Remove the Swivel and the VESA
2
Using a screwdriver, remove the swivel mount and VESA
bracket that are attached to your TV.
Aluminum Frame
Remove the Aluminum Frame
5
Using an allen key, remove the aluminum frame
attached on the TV.
VESA
Swivel
Mount
Mark the Holes
3
Place the swivel mount against the wall and mark where
your screws should be. Then drill holes into the marked
areas.
Back view of Ocea Pro
Ocea Pro
TV
Remove the TV Wall Box
6
Remove the TV wall box attached at the back.
TV Wall
Box
Information is subject to change without prior notification.
© Copyright. Evervue USA Inc.
www.oceatv.com
