Evervue Ocea Pro Installation Manual

Ocea Pro Recessed Mount - Installation Manual
OK OK
Zepp Remote &
Accessories Ocea Pro Recessed TV
and accessories
(Located in the Compartment
on the back of Ocea Pro)
TV
Remote
Allen Key
Power Supply
Check the Items
1
Upon receiving your order, open the crate and inspect the
contents. Damages must be reported within 24 hours.
Compartment Cover
Remove the Compartment Cover
4
Use a screwdriver to remove the compartment cover
located at the back of the TV
Evervue USA Inc.
5020 Campus Drive,
#121, Newport Beach, CA 92660, U.S.A.
Remove the TV Wall Box
2
Remove the TV wall box attached to the back.
To Power Source
Power Cord
Plug the Power Cord
5
Insert the power cord through the opening of the
compartment cover. Then plug it to the power input port
located at the back of the TV.
TV Wall TV Wall
Box Box
Prepare the Wall
3
Measure the width, height, and depth of your TV Wall Box.
Use the measurements to dig a hole in the wall. Then place
the TV wall box inside it.
Connect the Audio Cords
6
Insert one end of the stipped audio cord into the red clip
and insert the other end of the cord into the black clip.
Then do the same for the other stripped audio cord.
Information is subject to change without prior notification.
Width
Height
Depth
To Power
Source
© Copyright. Evervue USA Inc.
