SAVEO -PKT2 Series Quick Setup Manual

Scanning with Simplicity
SAVEO-PKT2-****
Unified Quick Set
kage
PKT2 c nne Bluetooth USB Dongle (CSR 4.0, Plug & Play)
U e Charging c e 1 x Attachable Lanyard
3M™ VHB™ Device Mount Plate 1 x Retractable Badge Reel Lanyard
Important Safety Information
Don't put scanner or cable in places of excessively high temperature, such as exposure to
direct sunlight. Don't use scanner in extremely humid conditions or in conditions of extreme
temperature change. Never damage the internal rechargeable battery. Damaging the casing
of the rechargeable battery might cause explosion or fire!
TIP:
Saveo® and Saveo Scan™ are trademarks of Stimare Limited. All other trademarks are property of their respective owners
Quick Setup Mobile (Bluetooth HID)
1.) Enter Pairing Mode
Pair Bluetooth
2.) Enable Bluetooth on
your mobile device
Go to your phone's homescreen
and find "Settings", then
"Bluetooth" and turn Bluetooth
on. Your device will search for
available devices within range.
After approx 20 seconds, Saveo
Scan will appear as an external
keyboard with a unique
identifier serial number (PKT2-
XXXXXXXXXX).
Select the scanner from
"Available Devices" and wait for
pairing process to complete.
Once "Connected" is displayed,
your device is paired to the
scanner. Your scanner is now
ready to use.
V 1.0
Scan this barcode code to
disconnect from any
previously connected
devices and put the
scanner into "Pairing
mode".
Please Note: Devices only
need to be paired once.
When they are within
Bluetooth range they will
automatically attempt to
connect to each other. If
you wish to connect to
another device it is
recommended you first
unpair this device.
-1-
Charging your device
1.) Connect the USB Type-C Cable (included)
Simply connect the USB Type-C cable
to the port on the bottom of the
scanner and connect the USB Type-A
end to a USB Type-A charging adaptor
(Minimum output Rating: 900mA+).
Transmission Modes
Direct Mode (Default)
Memory Mode
Memory Data Upload
Total Storage Count
Clear Memory
