SAVEO -SCAN-PKT-RCCD-BT Manual

SAVEO-SCAN-PKT-RCCD-BT
Getting Started
Switch on and Charge your Scanner
Please switch on and charge your scanner for 3~4 hours
before rst use.
Please Note: Saveo Scan Pocket LCD has a hibernate mode. To
enable hibernate mode, press the left and right (grey) buttons
simultaneously for 8 seconds. To wake the scanner from
hibernate mode press the middle (orange) button for 8 seconds.
Operating Elements
Exit window
(For iOS Devices
ONLY)
Button to
raise and lower
ON-Screen
Keyboard
Scan/Power
Power Saving
On Button
button:
Press the button for
2~3 seconds to
LED Indicator
enter power saving
mode
Mini USB port
with protective cover
Charge the pocket scanner with mini USB cable.
1
Connecting via Bluetooth
Enable Bluetooth on your device
Go to your phone's homescreen and nd "Settings", then
"Bluetooth" and turn Bluetooth on.
Enable Pairing Mode on the scanner
From the main menu, go to "Setup" and select "BT Setup".
2. select BT setup
1. select Setup
MAIN> S 12:52 S>
Memory-scan BT setup
Upload Status
Setup Power
↑ ENTER ↓ ESC
From the "BT Setup" menu, choose "HID device", then "Simple
Pairing". This will initiate pairing mode and the scanner will
become visible to Bluetooth enabled devices within range.
3. select HID device 4. select Simple Pairing
S/B/H>
S/B> S 12:52
Simple paring
SPP device
Paring
HID device
HID auto-unplug
dongle
ESC
ESC ENTER ↓
You will recieve this ccon rmation message. Your scanner is now
ready to pair with your device
Setting ...
Completed!!!
2
Your phone will automatically search for devices, Saveo Scan will
appear as an external keyboard with a unique identi er number
(R-xxxxxx).
Select R-xxxxxx
to connect
Devices are now
paired
S 12:52
ENTER ↓
S 12:52
Please note: devices only need to be paired once. When they are within
Bluetooth range they will automatically attempt to connect to each other. If
you wish to pair to another device it is recommended you rst unpair this
↓
ENTER
device.
You are now connected. Start scanning.
Search for devices
Select scanner from "Available
Devices" and wait for pairing
process to complete.
Once "Connected" is
displayed, your device is
paired to the scanner. Your
scanner is now ready to use.
3
