5.13 Freezers

Figure 44 Cylindrical & Rectangular Box Freezers
Pressing the "Freezer Control" button brings up the following screen (Figure 45):

Figure 45 Freezer Control screen

Current Temp
Set point
Range
Status
Shelves
Cylinderical freezer has a sliding tray with 2 or 3 shelves. Rectangle freezer has 5 removable
shelves.
Pure_Lab_Manual Rev 6_4-14-2015.docx
Indicates the actual temperature (°C) inside the freezer.
Allows the temperature inside the freezer to be adjusted.
Max set point is -35 c.
The deviation +/- °C from the set point.
Turns the freezer On and Off. By pressing the green start button or red stop
button.
System Operation
51 of 80
