7.

Scope of delivery

Pos. Pcs.
1 1
2 1
3 1
4 1
5 1
1
8.

Dimensions

For special designs, see the customer drawing for dimensions.
9.

Installation example

10. Assembly

☞
Important!
• Prior to the assembly process, flush the pipework in accordance with DIN 1988.
• Mount the emergency shower in accordance with EN 15154 Part 1.
☞
The manual actuator of the emergency shower can be plugged.
☞
To protect the tiles, use masking tape when marking and drilling. Drill at low speed.
☞
Depending on the composition of the wall, special wall plugs may have to be used
(to be provided by the customer).
10.1 Place the water supply (a) centrally at a height of 2310 ± 100 mm above the finished
floor.
10.2 Screw in the closed ball valve as far as possible, creating a seal and bringing it into
position as follows:
– The valve axis must point to
the left.
– The pivot motion of the valve lever must be aligned so that it is 90° to the wall.
10.3 Place the wall support (c) onto the guide (e) on the manual actuator and secure with
the grub screw (d).
10.4 Place the valve lever into the "close" position.
A: Closed
B: Open
10.5 Screw the manual actuator (g) into the fork head (f) of the deflection lever and lock
with a nut.
10.6 Using the spirit level, align the manual actuator (g) so that it is vertical.
10.7 Mark drill holes for the wall support (h) 40 mm above the triangular handle.
Name
Shower head
Wall bracket
Ball valve
Accessories kit:
First aid sign, Mounting set
Hand actuator and guide post support with plugging option
Installation and operating instructions
