Operator's Manual
SKID STEER BRUSH CUT TERS
Closed Front/Multi-Spindle Series
9000 SF
|
9000 HF
WHY READ THIS MANUAL?
Before operating your new Brush Wolf brush cutter, read this entire manual to understand
1) safety precautions, 2) operating instructions, and 3) maintenance schedule to help keep
you safe and your equipment running smoothly for years to come.
Advertisement
Table of Contents
Related Manuals for Brush Wolf Closed Front Series
Summary of Contents for Brush Wolf Closed Front Series
- Page 1 9000 HF WHY READ THIS MANUAL? Before operating your new Brush Wolf brush cutter, read this entire manual to understand 1) safety precautions, 2) operating instructions, and 3) maintenance schedule to help keep you safe and your equipment running smoothly for years to come.
- Page 2 TAKE A MINUTE TO WRITE DOWN THE FOLLOWING INFORMATION FOR FUTURE SERVICE, REPAIR, AND WARRANTY INQUIRIES. OWNER REFERENCE INFORMATION DATE OF PURCHASE ____________________________________________________ MODEL NO. ____________________________________________________ SERIAL NO. ____________________________________________________ DEALER NAME ____________________________________________________ SALES REP NAME ____________________________________________________ DEALER PHONE NO. ____________________________________________________ DEALER EMAIL ____________________________________________________ DEALER ADDRESS ____________________________________________________ ____________________________________________________...
-
Page 3: Table Of Contents
THANK YOU Welcome to the Brush Wolf family! You’ve made a smart choice! We hope you love your brush cutter as much as we love making it. If you have any issues, please contact us at any time. We’re here to help. -
Page 4: Safety First
Brush Wolf/Cross-Tech Manufacturing cannot cover every incident that might be a hazard. Extreme caution should be used at all times. Only use your Brush Wolf brush cutter for the purpose for which it has been designed. SITE INSPECTION ... - Page 5 BRUSH WOLF OPERATOR’S MANUAL | SAFETY FIRST! DO NOT DO NOT operate near bystanders, vehicles, raise the mower deck while blades pets, livestock, or buildings. Objects may are rotating. Operation with the mower raised discharge while cutting with the brush cutter will expose the cutting blades and may cause and has the potential to cause serious injury.
-
Page 6: Operating Your Brush Cutter
OPERATING YOUR BRUSH CUTTER FIGURE 1: SERIAL TAG START HERE Verify your skid steer’s hydraulic fl ow to ensure it is within the brush cutter’s rating range. The brush cutter’s gallons per minute (GPM) rating is located on the serial tag of the brush cutter. - Page 7 BRUSH WOLF OPERATOR’S MANUAL | OPERATING YOUR BRUSH CUTTER CONNECTING THE BRUSH CUTTER 1) Connect the brush cutter to your skid steer 3) Inspect the hydraulic couplers and wipe off with the universal Quick Tach Mount Plate. water, dust, or any debris which can damage hydraulic components.
- Page 8 BRUSH WOLF OPERATOR’S MANUAL | OPERATING YOUR BRUSH CUTTER OPERATING STEPS 1) Enter the shatter-proof cab door, engage When temperatures are below zero, allow the seat belt, release the brake, and start additional time for hydraulic fl uid to warm the engine.
- Page 9 BRUSH WOLF OPERATOR’S MANUAL | OPERATING YOUR BRUSH CUTTER WHEN DONE CUTTING When done, lower lift arms, make sure the cutter is placed flat on the ground, throttle down on the skid steer, and shut off the hydraulic flow to the brush cutter. Stop the engine and engage the parking brake before leaving the cab.
-
Page 10: Maintenance
MAINTENANCE BRUSH WOLF BRUSH CUTTERS ARE BUILT TO STRICT STANDARDS AND WILL DELIVER YEARS OF DEPENDABLE SERVICE WHEN YOU FOLLOW THESE MAINTENANCE GUIDELINES... MAINTENANCE SCHEDULE See pages 9-10 for details. BEFORE DAILY OR ITEM EACH USE EVERY 8 HOURS... - Page 11 BRUSH WOLF OPERATOR’S MANUAL | MAINTENANCE BEFORE EVERY OPERATION INSPECT BLADES CHECK THE GEARBOX FOR PROPER LUBRICANT Inspect blades before each use to ensure To check the lubricant level, remove the they are sharp, tightened correctly, and pipe plug from the side of the gearbox.
- Page 12 Also, tighten the castle nut holding the blade CHECK NUTS & BOLTS carrier to the output shaft of the gearbox, Every Brush Wolf brush cutter is tested at torque to 450 ft-lbs with a 1-1/2” socket the factory and all nuts and bolts have been wrench.
-
Page 13: Troubleshooting
TROUBLESHOOTING CONSULT YOUR DEALER OR CONTACT BRUSH WOLF FOR ANY QUESTIONS OR ADDITIONAL HELP. ISSUE POTENTIAL CAUSES • Low hydraulic fluid level • Overheated hydraulic fluid* • Contaminated hydraulic fluid* Loss of Power • Low gearbox lubricant level • Broken gearbox/motor shear pin •... -
Page 14: How To Replace Blades
HOW TO REPLACE BLADES Perform replacement on a level surface with the brush cutter blocked off the ground. Shut off the hydraulic power supply and disconnect hydraulic couplers. 1) Take off the access cover (see Figure 5 5) Use Primer Loctite on the bolts and nuts on page 10) by removing the nuts and according to the directions on the label. -
Page 15: Parts Section
PARTS SECTION ONLY USE GENUINE OEM PARTS ORDER PARTS DIRECTLY FROM BRUSH WOLF BY CALLING 877-390-9857 877-390-9857 | brushwolf.com... -
Page 16: 9000 Sf
PARTS: 9000 SF 41 3X DETAIL A PLUMBING LAYOUT (TYPICAL MOTOR ASSEMBLY) 877-390-9857 | brushwolf.com... - Page 17 ONLY USE GENUINE OEM PARTS. ORDER PARTS FROM BRUSH WOLF AT 877-390-9857 PART PART ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION NUMBER NUMBER 15060 BLADE, 14.750 X 4.000 X .500 COUPLER, FLAT FACED, 1/2 MALE, 15079 7/8-14, O-RING BOSS NUT, TOP LOCK, 1 1/8-12, GRADE C,...
-
Page 18: 9000 Hf
PARTS: 9000 HF DETAIL A (TYPICAL MOTOR ASSEMBLY) PLUMBING LAYOUT 877-390-9857 | brushwolf.com... - Page 19 ONLY USE GENUINE OEM PARTS. ORDER PARTS FROM BRUSH WOLF AT 877-390-9857 PART PART ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION NUMBER NUMBER 15060 BLADE, 14.750 X 4.000 X .500 15690 CLAMP, 0.750 HOSE, TOP HALF NUT, TOP LOCK, 1 1/8-12, GRADE C,...
-
Page 20: Warranty Information
1. 5 - Y E A R L I M I T E D W A R R A N T Y Warranties are valid from date of purchase with a warranty registration on file. Go to www.brushwolf.com for warranty details or scan the QR code. To file a warranty claim, call Brush Wolf at 877-390-9857 or email info@brushwolf.com.
