VIA C3 Low Power Processors Embedded SBC
User's Manual
Version 1.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW-E652 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aewin AW-E652

Summary of Contents for Aewin AW-E652

  • Page 1 VIA C3 Low Power Processors Embedded SBC User’s Manual Version 1.4...
  • Page 2 © Copyright 2005. All Rights Reserved Manual edition 1.4, Nov.2005 This document contains proprietary information protected by copyright. All rights are reserved, no part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without prior written permission of the manufacturer.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1. General Information 1.1 Introduction---------------------------------------------------------------------------------1 1.2 Specification---------------------------------------------------------------------------------1 1.3 AW-E652 Package--------------------------------------------------------------------------3 1.4 Board Layout--------------------------------------------------------------------------------4 1.5 Board Dimension---------------------------------------------------------------------------4 Chapter 2. Connectors Location and Configuration 2.1 Connectors/Jumpers Location and Define--------------------------------------------5 2.2 Onboard Processors-----------------------------------------------------------------------6 2.3 Installing System Memory----------------------------------------------------------------6 2.4 Connector and Jumpers Settings-------------------------------------------------------7...
  • Page 4 JP3: Clear CMOS-----------------------------------------------------------------------22 JP4: Watchdog Output Select--------------------------------------------------------22 JP5: COM2 RI/Voltage Select--------------------------------------------------------22 JP6: COM4 RI/Voltage Select--------------------------------------------------------23 JP7: COM3 RI/Voltage Select--------------------------------------------------------23 JP8: LCD Voltage Select---------------------------------------------------------------24 JP9: COM2 RS485 Wire Select---------------------------------------------------24 Chapter 3. BIOS Setup-----------------------------------------------------------------------25 3.1 Quick Setup--------------------------------------------------------------------------------25 3.2 Entering the CMOS Setup Program--------------------------------------------------26 3.3 Menu Options------------------------------------------------------------------------------27 Standard CMOS Features--------------------------------------------------------------29 Advanced BIOS Features---------------------------------------------------------------31...

  • Page 6: Chapter 1. General Information

    Chapter 1. General Information 1.1 Introduction The AW-E652 is a full function of 3.5” Embedded format SBC board use VIA VT8606 and VT82C686B chipset supports processors VIA Ezra/Eden (EBGA packaging) processors. The AW-E652 supports CRT and 36-bit TFT panels, Realtek RTL8139C+ Ethernet chipset with RJ45 jack for 10/100Mbps and AC-97 Audio Interface.

  • Page 7: Aw-E652 Package

    Operating temperature Board size 5.7"(L) x 4"(W) (145mm x 102mm) Weight 0.26 lb. (0.57 Kg) (bare) 1.3 AW-E652 Package Please make sure that the following items have been included in the package before installation. AW-E652 VIA C3 Single Board AW-E652...

  • Page 8: Board Layout

    Please make sure you properly ground yourself before handling the AW-E652 board or other system components. Electrostatic discharge can be easily damage the AW-E652 board. Do not remove the anti-static packing until you are ready to install the AW-E652 board. Ground yourself before removing any system component from it protective anti-static packaging.

  • Page 9: Board Dimension

    User’s manual 1.5 Board Dimension Chapter 2. Connectors/Jumpers Location and Configuration AW-E652...

  • Page 10: Connectors/Jumpers Location And Define

    User’s manual 2.1 Connectors/Jumpers Location and Define CN19 CN10 CN12 CN15 CN14 CN13 CN11 CN17 CN16 CN18 CN22 CN20 CN23 CN21 JP6 JP7 AW-E652...

  • Page 11: Onboard Processors

    COM2 RS485 Wire Select 2.2. Onboard Processors The AW-E652 has onboard built-in VIA Ezra or EDEN EBGA Package processor. The CPU cooler fan will be mounted when board with 800MHz or 667MHz CPU and the high profile Heatsink will be mounted when 667MHz CPU.
  • Page 12 User’s manual 2.4 Connector and Jumper Settings CN1: VGA Connector Define Green Blue MONID0 Ground Ground Ground Ground Ground MONID1 DDC Data H-Sync V-Sync DDC Clock AW-E652...
  • Page 13 User’s manual CN2: COM1 Connector (D-Sub) Define Ground CN3: PS/2 Mouse/Keyboard Connector (MINI DIN Jack) Define KBDATA MSDATA Ground KBCLK MSCLK AW-E652...
  • Page 14 The onboard IR connector with a 2.0mm pitch pin header Define Fast IR Receive IR Receiver Ground IR Transmitter CN5: LAN Connector (JR-45) Define TX0+ TX0- RX0+ RX0- LED: D1: Speed indicated LED 10 Mbps 100 Mbps GREEN D2 :Link/Activity LED Link YELLOW Activity BLINKING AW-E652...
  • Page 15 User’s manual CN6: USB Connector Define 5VUSB0 USBDT0- USBDT0+ Ground 5VUSB0 USBDT1- USBDT1+ Ground CN7: Internal KB/MS Connec tor The AW-E652 supports an internal keyboard/mouse with 2mm pitch pin header for flexible using. Define KB-CLK KB-DATA MS-CLK Ground KBMSVCC MSDAA AW-E652...
  • Page 16 User’s manual CN8: LVDS Connector The AW-E652 supports LVDS by using a 20-pin of connector for LVDS Panel Define Define Ground Ground Ground Ground VCCLCD VCC LCD Ground V12P0 V12P0 CN9: COM2 Connector The AW-E652 supports four serial ports, onboard COM2 with a 2.00mm pitch pin header.
  • Page 17 User’s manual CN10: PCI Interface The AW-E652 supports one micro PCI slot for expansion. Signal Signal Signal Pin Signal 26 PCICLK1 51 +3.3V SERR- PCIRST- +3.3V AD15 +12V AD22 C/BE1- +12V GNT4- AD21 AD13 AD20 AD14 REQ2- AD19 AD18 AD19...
  • Page 18 User’s manual CN11: LPT Connector The AW-E652 supports a 26-pin pin header LPT connector by using 2mm pitch connector. Define Define PT_STB# PTAFD# PT_D0 PTERROR# PT_D1 PTINT# PT_D2 PTSLIN# PT_D3 Ground PT_D4 Ground PT_D5 Ground PT_D6 Ground PT_D7 Ground PTACK#...
  • Page 19 A20 SYSCLK SA10 A21 IRQ7 A22 IRQ6 A23 IRQ5 A24 IRQ4 A25 IRQ3 A26 NC A27 TC A28 BALE A29 +5V A30 OSC A31 Ground Ground A32 Ground Please see how to install the PC/104 module in Appendix C. AW-E652...
  • Page 20 CN14: GPIO Port Connector The onboard supports eight digital input and eight output which using a 2.0mm pitch connector Define Define V5P0 V3P3 GPIN0 GPIN1 GPIN2 GPIN3 GPIN4 GPIN5 GPIN6 GPIN7 Ground Ground GPOUT0 GPOUT1 GPOUT2 GPOUT3 GPOUT4 GPOUT5 GPOUT6 GPOUT7 AW-E652...
  • Page 21 User’s manual CN15: IDE Connector The AW-E652 supports one 2.0mm pitch 44-pin pin header for up to two IDE devices. Define Define RSTPIDE# Ground PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4 PDD11 PDD3 PDD12 PDD2 PDD13 PDD1 PDD14 PDD0 PDD15...

  • Page 22: Cn16: Lcd Backlight Connector

    V12P0 Ground ENABKL CN17: Floppy Connector Define Define Ground DEN0 Ground DEN1 Ground INDEX# Ground MTR#0 Ground DS#1 Ground DS#0 Ground MTR#1 Ground DIR# Ground STEP# Ground WDATA# Ground WGATE# Ground TRAK0# Ground Ground RDATA# Ground HDSEL# Ground DSKCHG# AW-E652...

  • Page 23: Cn19: Atx Power Connector

    User’s manual CN18: USB3/4 Connector (Pin-Header) The AW-E652 supports four USB ports, CN18 with 2.0mm pitch pin header for USB3/4. Define Define 5VUSB1 5VUSB1 USBDT2- USBDT3- USBDT2+ USBDT3+ Ground Ground Ground CN19: ATX Power Connector Define 5V_SB PWR_TYPE PS_ON# CN20: AC97 Connector...

  • Page 24: Cn21: +5V/+12 Input Connector

    User’s manual CN21: +5V/+12V Input Connector Define V5P0 Ground V12P0 Ground CN22: COM3/COM4 Connector (Pin-Header 2.0mm) Define Define DCD3#IN DSR3#IN RXD3_IN RTS#3OUT TXD3_OUT CTS3#IN DTR#3OUT RI3#_5V_12V Ground DCD4#IN DSR4#IN RXD4_IN RTS#4OUT TXD4OUT CTS4#IN DTR#4OUT RI4#_5V_12V Ground AW-E652...

  • Page 25: Cn23: Lcd Display

    FP_D18 FP_D19 FP_D20 FP_D21 FP_D22 FP_D23 FP_D024 FP_D25 FP_CLK FP_VS FP_DEN FP_HS Ground ENABKL FP_D26 FP_D27 FP_D28 FP_D29 FP_D30 FP_D31 FP_D32 FP_D33 FP_D34 FP_D35 Note: The factory default at +3.3V, please make sure your Panel Voltage setting by JP8 AW-E652...

  • Page 26: Jp1: Com1 Ri/Voltage Select

    User’s manual JP1: COM1 Voltage Select Setting Define Ring (Default) JP2: COM2 Mode Select (RS232/422/485) Setting Define RS-232 (Default) RS-422 RS-485 AW-E652...
  • Page 27 User’s manual JP3: Clear CMOS Setting Define Hold Data (Default) Clear CMOS JP4: Watchdog Output Select Setting Define IRQ11 Reset (Default) JP5: RI/Voltage Select for COM2 Setting Define (Default) +12V AW-E652...
  • Page 28 User’s manual JP6: RI/Voltage Select for COM4 Setting Define Ring (Default) JP7: RI/Voltage Select for COM3 Setting Define Ring (Default) AW-E652...

  • Page 29: Jp8: Lcd Voltage Select

    User’s manual JP8: LCD Voltage Select Setting Define +3.3V (Default) JP9: COM2 RS485 Wire Select Setting Define 2 wire 4 wire AW-E652...

  • Page 30: Chapter 3. Bios Setup

    User’s manual Chapter 3. BIOS Setup The ROM chip of your AW-E652 board is configured with a customized Basic Input/Output System (BIOS) from Phoenix-Award BIOS. The BIOS is a set of permanently recorded program routines that give the system its fundamental operational characteristics.

  • Page 31: Entering The Cmos Setup Program

    1. Turn on or reboot the system. After the BIOS performs a series of diagnostic checks, the following message appears: “Press DEL to enter SETUP” 2. Press the <DEL> key to enter CMOS Setup program. The main menu appears: AW-E652...

  • Page 32: Menu Options

    STANDARD CMOS FEATURES: Configure the date & time, hard disk drive type, floppy disk drive type, primary display type and more ADVANCED BIOS FEATURES: Configure advanced system options such as enabling/disabling cache memory and shadow RAM AW-E652...

  • Page 33: Advanced Chipset Features

    COS Setup main menu, but you can not enter other menus in the CMOS Setup program. SAVE & EXIT SETUP: Save changes of values to CMOS and exit the CMOS setup program EXIT WITHOUT SAVING: Abandon all CMOS changes and exit the CMOS setup program AW-E652...
  • Page 34 If your drive is not one of the predefined types, choose “User” and enter the following drive specifications: Cylinders, heads, Wpcom, L-Zone, sectors, and mode Consult the documentation received with the drive for the values that will give you optimum performance. AW-E652...
  • Page 35 Choose: All Errors (Default) No Errors All, But Keyboard All, But Diskette All, But Disk/Key 3. After you have finished with the Standard CMOS Features program, press the <ESC> key to return to the main menu. AW-E652...
  • Page 36 If this happens, you can use an anti-virus utility on a virus-free, bootable floppy disk to reboot and clean your system. The default setting is Disabled. CPU Internal/External Cache Cache memory is an additional memory that is AW-E652...
  • Page 37 Device” function. The system will automatically boot the other device. Choose: Enabled / Disabled Swap Floppy Drive This would be effective only in systems with two floppy drives. To select enable assigns physical drive B to logical drive A, and physical drive A to AW-E652...
  • Page 38 Supervisor Password & User Password later in this chapter. OS Select for DRAM > 64MB Set to OS/2 if your system is using OS/2 and has a memory size of more than 64MB Small Logo Choose: Enabled / Disabled AW-E652...
  • Page 39 F10:Save ESC: Exit F1: General Help F7:Optimized Defaults F5:Previous Value F6:Fail-Safe Default 2. Move between items and select values by using the arrow keys. Modify the selected fields using the PnUP/PgDN keys. For information on the various options, press <F1> key. AW-E652...
  • Page 40 When 4X mode enabled, it will enhance your system performance. Choose: Enabled / Disabled OnChip USB You could enable this function if the system contains USB (Universal Serial Bus) controller and USB keyboard. When disabled, the system will not be able to access USB keyboard. AW-E652...
  • Page 41 AGP Master 1 WS Read When enabled, the system will run single wait state delay before reading data from buffer; if users disable the system, it will run twice wait states and the system can be stable. Choose: Enabled / Disabled AW-E652...
  • Page 42 TX RX inverting enable No, Yes Onboard Parallel Port <378/IRQ7> Onboard Parallel Mode <Normal> X ECP Mode Use DMA X Parallel Port EPP Type EPP1.9 Enter:Select +/-/PU/PD:Value F10:Save ESC: Exit F1: General Help F5:Previous Value F6:Fail-Safe Default F7:Optimized Defaults AW-E652...
  • Page 43 VGA card IDE HDD Block Mode Enabled/Disabled the IDE HDD Block Mode function. Note: Not all drives support this function Onboard FDC Controller Enabled/Disabled. Select enabled if your system has a floppy disk controller installed on the system board and AW-E652...
  • Page 44 This option lets you to determine onboard parallel port controller I/O address setting. Parallel Port Mode Default Setting: SPP Select an operating mode for the onboard parallel port. ECP Mode Use DMA Select a DMA channel for the port Choose: 3 / 1 AW-E652...
  • Page 45 User’s manual Parallel Port EPP Type Select EPP port type 1.7 or 1.9 Choose: EPP1.9 / EPP1.7 AW-E652...
  • Page 46 PM Control by APM When the advanced power management is installed on the system, users would select “Yes” to save more power. Choose: Yes / No Video off Option Select the power saving modes when the monitor is blank. AW-E652...
  • Page 47 Green monitor, use the Blank Screen option MODEM Use IRQ Choose the IRQ used by the modem. Default: Disabled 3. After you have finished with the Power Management Setup, press the <ESC> key to return to the main menu. AW-E652...
  • Page 48 “Enable” – PNP configuration data is reset in BIOS “Disable” – PNP configuration date is retained in BIOS Resources Controlled By Choose Auto or Manual. This option specifies whether resources are controlled by automatic or manual configuration IRQ Resources IRQ-3 Assigned to <PCI Device> AW-E652...
  • Page 49 Current CPU Temp. 30/86 Menu Level Menu Level Current CPUFAN Speed 31/87 Vcore 1.16 V 2.5V 2.61 V 3.3V 3.38 V 5.30 V 15.54 V Enter:Select +/-/PU/PD:Value F10:Save ESC: Exit F1: General Help F7:Optimized Defaults F5:Previous Value F6:Fail-Safe Default AW-E652...
  • Page 50 Esc : Quit : Select Item F10 : Save & Exit Setup (Shift)F2: Change Color Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... AW-E652...
  • Page 51 Then type your new password at the prompt. The password is case sensitive and you can use up to 8 alphanumeric characters. Press <Enter> after entering the password. At the Next Prompt, confirm the new password by AW-E652...
  • Page 52 Set Supervisor Password Power Management Set User Password PnP/PCI Configuration Save & Exit Setup PC Health Status Exit Without Saving Esc : Quit : Select Item F10 : Save & Exit Setup (Shift)F2: Change Color Time, Date, Hard Disk Type... AW-E652...
  • Page 53 Esc : Quit : Select Item F10 : Save & Exit Setup (Shift)F2: Change Color Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... AW-E652...
  • Page 54 User’s manual Chapter 4. Driver Utility The system driver installation procedure must be performed first. 1. Insert the AW-E652 CD-ROM driver into the CD-ROM Drive 2. Select the Drivers\system file to click the Setup icon. 3. Click Next AW-E652...
  • Page 55 User’s manual 4. Click Yes 5. Select Normally Install, and then click Next AW-E652...
  • Page 56 User’s manual 6. Remain the default setting, and then click Next 7. Click Next AW-E652...
  • Page 57 User’s manual 8. As the following picture, click Next 9. Select Install VIA AGP VxD in Turbo Mode, and click Click AW-E652...
  • Page 58 User’s manual 10. Click Next 11. Click Finish AW-E652...

  • Page 59: Audio Driver Installation

    User’s manual Installation process is completed and allowed the system to reboot. Audio Driver Installation 1. Insert the AW-E652 CD ROM into the CD-ROM Drive 2. Select the Drivers\audio\ad1881 file to click the Setup icon AW-E652...
  • Page 60 User’s manual (3) Click Next (4) Click “OK” AW-E652...

  • Page 61: Vga Driver Installation

    User’s manual VGA Driver Installation 1. Install the AW-E652 CD ROM into the CD-ROM Drive 2. Select the Drivers\vga\Win9x ME file to click the Setup icon A driver installation screen will appear, please follow the onscreen instruction to install the driver in sequence...
  • Page 62 User’s manual 3. At last, click Next 4. Click Next Installation process is completed and allowed the system to reboot AW-E652...

  • Page 63: Ethernet Driver Installation

    User’s manual Ethernet Driver Installation 1. Insert the AW-E652 CD ROM into the CD-ROM Drive 2. Click the Start button 3. Select the Setting item 4. Click the Control Panel item 5. Select the Systems icon to open the System Properties box 6.
  • Page 64 User’s manual 7. Select the Network Adapters item Another file will appear below this file, and then click on the file 8. Click the Driver Tab 9. Click the Update Driver Button The Update Device Driver Wizard will appear AW-E652...
  • Page 65 User’s manual 10. Click Next AW-E652...
  • Page 66 User’s manual 11. Select CD ROM Drive, Drivers\lan\Win98, and click Next Notice: We take the LAN installation under Win98 for example only, please choose the file depending on your Windows OS. AW-E652...
  • Page 67 User’s manual AW-E652...
  • Page 68 User’s manual Click Next AW-E652...
  • Page 69 User’s manual Click Finish Installation process is completed shutdown the computer and will allow the system to reboot AW-E652...

  • Page 70: Appendix A. Programming The Watchdog Timer

    User’s manual Appendix A: Programming the Watchdog Timer The AW-E652 provides a watchdog timer that resets the CPU or generates an interrupt if processing comes to a stop. This function ensures greater system reliability in industrial stand-alone and unmanned environments.

  • Page 71: Appendix B. Audio Kit

    User’s manual Appendix B: Audio Kit 1. Board Layout 2.Board Dimension Board Dimension (mil) AW-E652...
  • Page 72 Speaker-Out CD Audio Input AC97 Audio Input CN1: This MIC-In jack connects to a microphone CN2: This Line-In jack connects to a tape player or other audio sources. CN3: This Speaker-Out jack connects to a headphone or a speaker. AW-E652...
  • Page 73 User’s manual CN4: CD Audio Input Connector 1 2 3 4 Pin Signal CD AIDIO-L CD AUDIO-R CN5: AC-97 Audio Input Connector Signal Signal +12V AC97-BTCLK +3.3V KEY PIN AC97-SDIN0 AC97-SYNC AC97-RESET AC97-SDOUT PC-BEEP AW-E652...

  • Page 74: Appendix C. Installing Pc/104 Module

    PC/104 module. Please follow these steps to install the PC/104 modules to the AW-E652: 1. Set all jumpers or switches for the AW-E652. Once the PC/104 module is installed you may have difficulty setting these. 2. Seat the PC/104 module male connector into the AW-E652 CN12 3.

  • Page 75: Appendix D. Programming The Gpio Port

    User’s manual Appendix D: Programming the GPIO Port The AW-E652 provides an 8-bit GPI port and an 8-bit GPO port that you can use to read and write data through. The GPIO Port Base Address is 440 (hex). Reading the GPIO Data...

  • Page 76: Appendix E. Interrupt Controller

    Appendix E: System Resource Interrupt Controller The AW-E652 is a fully PC compatible control board, it consists of 16 ISA interrupt request lines and most of them already in used by other part of the board. Both of ISA and PCI expansion cards may need to use IRQs, please make sure that the IRQs do not conflict if you would like to use extra add-on cards.
  • Page 77 Available for PCI and ISA Slot DMA6 DMA7 Available for PCI and ISA Slot Memory Map The following table indicates memory of AW-E652. The address ranges specify the runtime code length. Memory below 1MB (1Mb ~ 640KB) Address Range Type...
  • Page 78 1F0 ~ 1F7 IDE Controller 220 ~ 22E Sound Card 2F8 ~ 2FF Communication Port (COM2) Midi IDE Controller 378 ~ 37A LPT1 3B0 ~ 3BB VGA Adapter 3C0 ~ 3DF VGA Adapter 3F0 ~ 3F5 FDD Controller IDE Controller AW-E652...

  • Page 79: Appendix F. Optional Cable List

    CF8 ~ CFF PCI Bus E000 ~ E0FE Ethernet Controller F000 ~ F00E IDE Controller Appendix F: Optional Cable List Part Number Cable Description AW-E652 Terminating Connector Connector 46-I00IDE-00 IDE Cable CN15 44-pin Dual IDE Cable, 20cm 46-IFDC01-00 Floppy Cable CN17 2.54mm-2.0mm Floppy Cable...
