- Page 1 (TSC) RAILER AFETY ONTROL ANUAL...
-
Page 3: Table Of Contents
ONTENTS System Overview Trailer Safety Control TSC Brake Controller Compatibility How it works Operation System Troubleshooting Failure Diagnosis Trailer Safety Phone App Diagnostics Reference Appendix A: Trailer Brake Controller Compatibility Guideline... -
Page 4: System Overview
ODULE The “brain” of the system is the control unit which The Status Lamp Display Module informs the receives all the data from wheel speed and trailer driver of the status of the TSC system. The lamp motion sensors. Automotive... -
Page 5: Trailer Safety Control Tsc
Electric Brake Controller in the the road. tow vehicle or on the trailer/caravan. The primary trailer braking control remains the Trailer Safety Control (TSC) is an advanced responsibility of the Electric Brake Controller braking modulation system specifically designed and the vehicle driver. -
Page 6: How It Works
HANGE ONTROL Lane Change Control activates when it detects a TSC uses an advanced network of sensors to sharp, sudden change in direction. This works monitor your trailer’s speed, direction, lateral differently from TSM as there is no gradual build- motion, grip –... -
Page 7: Operation
20 minutes of trailer standstill without a trailer/caravan battery. braking signal detected. • TSC will go into a low power sleep mode after 120 minutes of trailer standstill without a braking signal detected. TSC will shut down if power is removed from •... -
Page 8: Trailer Safety Phone App
15 second period to commence the Lamp Flash diagnostic mode. ONNECTING ISCONNECTING TO Reading/Decoding Lamp Flash Diagnostics: After opening TSC Phone App, it indicates that it is not connected with status “Not Connected”. Each active fault will flash a code in sequential... - Page 9 If the phone is paired with the Veepeak device but fails to complete connection and download data, the TSC is not communicating. The TSC will enter sleep mode after 2 hours at standstill and no longer communicate via the Bluetooth link. If the ECU is asleep, connect to an electric brake controller to trigger it to awake (status lamp on).
-
Page 10: Diagnostics Reference
IGHT TATUS RIVER CTION TATUS AUSES ECU powered ECU has no power Connect power to TSC, press All lamps OFF off / sleep / no brake pedal, press brake brake signal in sleep mode. controller manual override. Operational lamp (green) - Page 11 TATUS EFERENCE CONTINUED YSTEM OSSIBLE IGHT IGHT TATUS RIVER CTION TATUS AUSES System status can’t be reliably reported to driver. Drivers Operation lamp should expect no operation (green) System is in full from the system and adjust intermittent Operation light operation;...
- Page 12 Flashes Flashes Description No fault No fault. No action required. TSC detects more than one wheel speed sensor has a problem. The system will operate in a reduced state until corrected. Suggested service actions: • Check wheel bearings and brakes...
- Page 13 IAGNOSTIC ERVICE CTION CONTINUED Fault Service # Amber # Green Fault Service Detail Code Flashes Flashes Description 0561 Battery condition warning 0562 Battery under voltage fault Refer to “Power Supply Service Guide”. 0563 Battery over voltage fault Front Axle, Left Wheel Locate the brake magnet within the 40B0 Brake Magnet Fault...
- Page 14 Service Brake Signal correctly. 5300 Plausibility Fault • Check wiring and all plug/socket connections between tow vehicle electric brake controller (EBC) and TSC ECU. If fault persists, return to service dealer for investigation.
- Page 15 Tone Wheel or WSS Mount Guide”. Internal TSC ECU fault detected. 5137 Suggested service actions: 5138 • Check condition of TSC ECU, its 5139 TSC ECU Internal Fault mounting and wiring. 513A If fault persists, return to service dealer 513B for investigation.
- Page 16 Flashes Description Lamp module failure, system has detected a fault within the operational light. Suggested service actions: • Check all connections of the TSC ECU lamp module. 4218 No Lamp Operational Light Fault Lamp • Check wiring between lamp module and TSC ECU.
- Page 17 • Check tolerance between tone wheel and wheel speed sensor. • Check wheel speed sensor is correctly plugged into wiring harness. Wheel Speed • Inspect condition of wiring from wheel speed sensor to TSC ECU for Sensor damage. Service Instruction REPAIR / RESOLVE ACTIONS •...
-
Page 18: Appendix A: Trailer Brake Controller Compatibility Guideline
The Trailer Safety Tekonsha Primus IQ Control TSC system can work with a time based Prodigy P2 controller, however this brake control is not optimised and will likely result in increased Prodigy P3 activation of the ABS system. - Page 19 Typically, vehicle integrated controllers have simulated load can be switched on to the brake more advanced brake control and diagnostics. circuit by the TSC (to be configured and installed Inertia is often the main brake control parameter. by workshop or dealer).
- Page 20 Robert Bosch (Australia) Pty. Ltd. 1555 Centre Road Clayton VIC 3168 AUSTRALIA www.bosch.com.au F005EP0085.01 | 2023.06...
