Cooper Lighting Luminous Wall Sconce 606 Specification Sheet

D E S C R I P T I O N
606 Luminous Wall Sconce features an angled horizontal body with a
center perforated panel and two matte acrylic side panels. The
luminaire provides soft uniform front illumination as well as a subtle
perimeter back glow. ADA compliant.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Painted or plated cold-rolled
steel base metal with matte
white acrylic front panels and a
3/32" x 5/32" staggered round
perforated center.
F i n i s h
Standard: Matte White (MW).
Premium: Satin Chrome (SC),
Polished Chrome (PC), Oxidized
Brass (OBRS), Satin Brass (SB),
Polished Brass (PB), Satin
Copper (SCP), Polished Copper
(PCP), Oxidized Copper (OCP),
Satin Nickel (SN), Polished Nickel
(PN), Gun Metal (GNM),
Lacquered Satin Chrome (SCL),
Lacquered Satin Nickel (SNL) or
Custom Color (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
O R D E R I N G I N F O R M AT I O N
Sample Number: 606-CFL/2-277V-PCP
Series Lamp Voltage
606 Luminous = 120V
CFL/2
Sconce
277V
CFL/2/13
347V
INC/2/60
Notes:
1
Available with CFL only.
2
Supplied by others.
3
Consult factory for more patterns and pricing.
4
Interior applications only
L a m p / S o cke t
Two (2) 26W (GX24q-3 base),
32W (GX24q-3 base) 4-pin triple
tube CFL or two (2) 13W (2GX7)
low watt 4-pin CFL or two (2)
60W frosted T-10 lamps. CFL
socket injection molded plastic.
INC socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring. Front shield
rotates up for ease of relamping.
Horizontal or vertical mount.
O p t i o n s
Hand Painted Faux Alabaster
Panels (FP), Hand Painted Faux
Linen Panels (LNP), Perforated
Panels (PP), Custom Laser Cut
Center Panel (LCP) - Contact
factory for pattern options,
Remote Emergency Battery -
Supplied by others (REM).
Energy Star Rating - Contact
Factory. Damp Locations (DL): All
Painted finishes, Lacquered Satin
Chrome (SCL), Lacquered Satin
Nickel (SNL), finishes only.
Finish
Standard
1
MW Matte White =
1
Premium
CC Custom Color =
GNM =Gun Metal
OCP =Oxidized Copper
OBRS Oxidized Brass =
PB Polished Brass =
PC Polished Chrome =
PCP Polished Copper =
PN Polished Nickel =
SB Satin Brass =
SC Satin Chrome =
SCL Lacquered Satin Chrome =
SCP Satin Copper =
SN Satin Nickel =
SNL Lacquered Satin Nickel =
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements. ADA
compliant.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
4
DL Damp Location =
REM Remote =
2
Emergency Battery
FP Hand Painted Faux =
Alabaster Panels
LCP Custom Laser Cut =
3
Center Panel
PP Perforated Panels =
shaperlighting.com
Type
Date
606 SERIES
I n t e r i o r W a l l L u m i n a i r e
L u m i n o u s S c o n c e
AMERICAN
DISABILITIES
ACT (ADA)
Shaper offers a large selection of ADA
interior and exterior wall luminaires.
ADA requires all fixtures below 68" to
have a maximum projection of 4".
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
