Cooper Lighting Shaper 607 Series Specification Sheet

D E S C R I P T I O N
607 Luminous Wall Sconce features a classic "craftsman" style which
provides forward, direct and indirect illumination.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Solid brass (PB, SB, SC or PC
finishes) with 1/8" matte acrylic
panels.
F i n i s h
Standard: Matte White (MW).
Premium: Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Polished Brass (PB),
Oxidized Brass (OBRS), Satin
Copper (SCP), Polished Copper
(PCP), Oxidized Copper (OCP),
Satin Nickel (SN), Polished Nickel
(PN), Lacquered Satin Chrome
(SCL), Lacquered Satin Nickel
(SNL), Gun Metal (GNM), or
Custom Color (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
O R D E R I N G I N F O R M AT I O N
Sample Number: 607-16-CFL/2/13-277V-PCP
Series Size Lamp
607 Craftsman = 16"
Vanity
24"
Notes:
1
Available in 16".
2
Available in 24".
3
Available with CFL only.
4
Consult the factory for available options.
5
Supplied by others.
6
Recommended for side and front panels only.
L a m p / S o cke t
16": Two (2) 18W (2G11) 4-pin
high lumen CFL lamps or two (2)
60W A-19 lamps.
24": Two (2) 14W T5 linear
fluorescent lamps or three (3)
60W A-19 lamps. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring. Mounting
centered on the back of the
luminaire. Vertical or horizontal
mount.
O p t i o n s
Mica Panels (MP) -
recommended for side and front
panels only, Opal Glass (OG),
Hand-Painted Faux Alabaster
Panels (FP), Hand-Painted Faux
Linen Panels (LNP), Perforated
Panels (PP), Remote Emergency
Battery - Supplied by others
(REM), Energy Star Rating -
Contact factory. CFL Dimming
Voltage Finish
1
120V Standard
CFL/2/18
2 3
MW Matte White =
T5/2/14 277V
1 3
INC/2/60 347V Premium
2
CC Custom Color =
INC/3/60
GNM=Gun Metal
OBRS Oxidized Brass
OCP=Oxidized Copper
PB Polished Brass =
PC Polished Chrome =
PCP Polished Copper =
PN Polished Nickel =
SB Satin Brass =
SC Satin Chrome =
SCL Lacquered Satin Chrome =
SCP Satin Copper =
SN Satin Nickel =
SNL Lacquered Satin Nickel =
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
Ballast - contact the factory for
options (DM), Damp Locations
(DL): All Painted finishes,
Lacquered Satin Chrome (SCL)
and Lacquered Satin Nickel (SNL)
finishes only.
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
DL Damp Location =
DM CFL Dimming Ballast =
OG Opal Glass =
REM Remote Emergency =
Battery 5
=
FP Hand Painted Faux =
Alabaster Panels
LNP= Hand Painted
Faux Linen
MP Mica Panels =
PP Perforated Panels =
I n t e r i o r W a l l L u m i n a i r e
4
6
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
shaperlighting.com
Type
Date
607 SERIES
" C r a f t s m a n " Va n i t y
