28–3/16"
(715 mm)
Air pressure range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air volume requirements
(With .062 in spray tip, included)
Pump ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Max. recommended pump speed
Pump discharge pressure
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound pressure level* at 100 psi (6.8 bar, 0.68 MPa)–40 cycles/min (at one meter).
Sound power level* at 100 psi (6.8 bar, 0.68 MPa)–40 cycles/min.
* Sound power level was tested in accordance with ISO 9614–2.
14 306817

Dimensions

14–3/4"
(375 mm)

Technical Data

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1/2 npt air inlet
06019
150 to 850 kPa (1.5 to 8.5 bar, 20 to 120 psi)
3
23 cfm (0.64 m /min) at 480 kPa (4.8 bar, 70 psi),
3
32 cfm (0.90 m /min) at 690 kPa (6.9 bar, 100 psi)
60 cycles per min. or 3 gpm
8.3 MPa (83 bar, 1200 psi)
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10:1
55 lb (24.95 kg)
83 dBa
96 dBa
