Version No.: V1.01 USER
SafeLogic BackLit Operating Instructions
This manual is for the SafeLogic BackLit EC-0601A-BL series EntryPad used in conjunction with
EL-0601, EL-0701, EL-0801 or EL-0901 lock bodies.
Important:
● For indoor use only.
● Battery Low Voltage: 5.2 ± 0.2V. The display will alert low battery when battery voltage
reaches 5.2±0.2V. PLEASE REPLACE THE BATTERY IMMEDIATELY.
Battery Replacement Instructions
a) In the back of Entry Pad you will see one 9 V alkaline battery. Take the battery out of
the battery compartment. Gently pull on the battery until it drops out.
b) Gently remove the connector by unsnapping it from the two terminals on the top of the
battery.
Never Pull on the Battery Leads
c) Connect a new 9V Alkaline battery to the battery clip.
d) Put the battery and the leads completely back into the battery compartment.
FEATURES:
1. Manufacturer default code is 1-2-3-4-5-6
Doc.No.:BLU-EC0601ABL130402
1
Advertisement
Table of Contents
Related Manuals for Securam SafeLogic BackLit EC-0601A-BL Series
Summary of Contents for Securam SafeLogic BackLit EC-0601A-BL Series
- Page 1 Doc.No.:BLU-EC0601ABL130402 Version No.: V1.01 USER SafeLogic BackLit Operating Instructions This manual is for the SafeLogic BackLit EC-0601A-BL series EntryPad used in conjunction with EL-0601, EL-0701, EL-0801 or EL-0901 lock bodies. Important: ● For indoor use only. ● Battery Low Voltage: 5.2 ± 0.2V. The display will alert low battery when battery voltage reaches 5.2±0.2V.
- Page 2 2. Function of Code a. Unlock safe lock system b. Change code 3. Backlight Button Features a) The middle of the “ ” button is raised for easier navigation in the dark. Press “ ” or any other button and the backlighting will be switched on. b) Pressing the “...
- Page 3 Manufacturer recommends the use of 9-Volt standard alkaline batteries (Duracell or Energizer brands are recommend) replaced annually. USER PROGRAMMING INSTRUCTIONS 1. ALWAYS PERFORM OPERATIONS WITH THE SAFE LOCK SYSTEM UNLOCK AND THE SAFE DOOR OPEN. 2. Before closing the door, make sure all the program changes are correct. 3.
- Page 4 Battery Low Voltage: 5.2±0.2V Working Temperature: 0 ~ +49 Working Humidity (max): <90% Code Length: 6 Digits Mechanical System Life Span: >10,000 Cycles (UL requirement) >100,000 Cycles (SecuRam design criteria) SecuRam Systems Inc. U.S.A.
