Hi-Flame Precision III HF910 Instruction Manual

Free-standing multi fuel non-boiler stove
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
P recision
Instruction Manual
Precision III HF910
Free-standing Multi Fuel Non-Boiler Stove
Published September 2012
Please note This appliance must, at
all times, be operated in accordance
with the instructions to minimise the
amount of smoke produced.
You will need to refer to the serial
number of your stove shown above
should you ever need to make a claim
under the Precision Warranty. You will
also find the serial number, beginning
with HF, on the CE plate at the rear of
the stove as well as on the lid of the
www.hi-flame.com
outer packaging.
Ref: HF910 / UK-NI-ROI / V1-ND.15-09-12
