Sharp Carousel SMO1754JS Operation Manual page 33

C A R E A N D C L E A N I N G
INSTALL/REPLACE CHARCOAL FILTER
Charcoal Filter
If your oven is vented to the inside, the charcoal filter should be replaced if it is used for approximately
6 months.
You can purchase Charcoal Filter from 1-800-BE-SHARP. Accessory Model # RK-233.
Vent grille mounting screws
Vent grille
Charcoal lter
1. Unplug the oven or turn off the power at the main
power supply.
2. Remove the grille air mounting 2 screws and open
the door.
3. Slide the grille air to the left, then pull it straight out.
4. Push the charcoal lter backwards and remove it.
5. Slide a new charcoal lter into place.
6. Replace the grille air and 2 screws and close the
door.
7. Plug the oven in or turn on the power at the main
power supply.
33
