OVER THE RANGE
MICROWAVE OVEN
OPERATION MANUAL
• Consumer Limited Warranty .......................
• Important Safety Instructions .....................
• Federal Communication Commission Radio
• Grounding Instructions ...............................
• Installation Guide ........................................
• Specifications ..............................................
• Features Diagram ........................................ 10-12
• Operation Procedure ..................................
• Controls ....................................................... 14-28
• Care and Cleaning ...................................... 29-33
• Before You Call ............................................
• Questions and Answers .............................
• Cooking Instructions .................................. 36-46
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
※ Keep the waveguide cover clean at all times.
Wipe the oven interior wth a soft damp cloth after each use.
If you leave grease or fat anywhere in the cavity it may overheat, smoke or even catch
fire when next using the oven.
M O D E L
SMO1754JS
C O N T E N T S
Microwave Energy .................... 3
4
5
6
6
7-8
9
13
34
35
