Mina Mobile
ASSEMBLY INSTRUCTIONS
The following instructions will guide you through the steps required to assemble your
new Mina Mobile.
Please read entire installation guide before beginning installation.
The appropriate hardware kits for each mobile will be packaged with each product.
Binder Post (x6)
Binder Screw (x6)
Protective Sleeve (x6)
Casters (2 locking, 2 non-locking) Mina Mobile
Steel legs (x4)
WARNING
Risk of injury to installers and users
Read the entire assembly directions before
beginning assembly.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the calyx Mina Mobile and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Claridge calyx Mina Mobile

  • Page 1 Mina Mobile ASSEMBLY INSTRUCTIONS The following instructions will guide you through the steps required to assemble your new Mina Mobile. Please read entire installation guide before beginning installation. The appropriate hardware kits for each mobile will be packaged with each product. Binder Post (x6) •...
  • Page 2 Mina Mobile Assembly Step 1 Place panel on a clean work bench or table. We recommend you place a blanket or pro- tective cloth to prevent any scratching of the writing surface. Overhang panel to one side of table 3”, to allow for leg assembly. Step 2 Position legs as shown.
