K-SPORT KSOZ015 Assembly Instructions Manual

Download this manual

KSOZ015

A S S E M B L Y I N S T R U C T I O N S

WWW.K-SPORT-DE.DE

Page 1 KSOZ015 A S S E M B L Y I N S T R U C T I O N S WWW.K-SPORT-DE.DE...
Page 2 KSOZ015 1e x 2 2e x 4 3e x 4 5e x 2 6e x 4 7e x 1 1s x 6 2s x 36 3s x 32 60mm 70mm 2c x 4 1c x 68 4s x 72 50 mm x 50 mm...
Page 3 KSOZ015 17mm...
Page 4 KSOZ015...
Page 5 KSOZ015 ATTENTION!!! When anchoring the frame to the ground, you should spread the lower "frame feet" outwards (shown by arrows) to stiffen the frame structure.
Page 6 KSOZ015 ATTENTION!! The frame requires a stable attachment to the ground. You can use screws with wall plugs, anchors or pegs with a minimum length of 60 cm. These fixings are not included in the set.
Page 7: Safety Information
The unit must be assembled according to the instructions. If the unit is incomplete, please contact the Technical and Sales Service at the following e-mail address: info@k-sport-de.de and indicate the article number of the missing item. If the unit cannot be assembled for technical reasons (e.g. there is no opening available, the opening is in a different place, the part is bent, etc.), please contact the Sales and Technical...
Page 8 12. If the unit cannot be assembled for technical reasons (e.g. there is no opening available, the opening is in a different place, the part is bent, etc.), please contact the Sales and Technical Support Service at the following e-mail address: info@k-sport-de.de and attach a photo of the defective part.
