TP-Link MA180 Quick Installation Manual

Quick Installation Guide
3.75G HSUPA USB Adapter
MA180
MODEL NO.
2
LED Explanation
LED
Status Indication
No SIM/USIM card is inserted.
Flashing Red
The Adapter is initializing.
Solid Red
The SIM/USIM card has registered to
Flashing Green
the network.
The network is available with a
Solid Green
successful Internet connection.
7106503935
Package Contents
3.75G HSUPA USB Adapter
MODEL NO. MA180
MA180 QIG
System Requirement
Operating System： Windows 7/Vista/XP 32/64-bit
CPU: 500MHz Pentium or above
Hard Disk: 20G or above
RAM: 128M or above
3
Software Installation
(The installation procedures in Windows 7/ Vista/ XP are similar. Here we use the procedures in Windows 7 as an example.)
1 The following window will automatically appear
on your desktop. Click the Run AutoRun.exe.
The InstallShield Wizard window will
2
appear. Click Next to continue.
1
Hardware Installation
1
3
1
Open the cover.
2
Insert the SIM/USIM card and the Micro SD card in the direction indicated on the Adapter.
A Micro SD card is an optional accessory. You need to buy one yourself. To remove the
Micro SD card, press it to eject it from the Adapter.
3
Replace the cover.
4
Plug the Adapter directly into the USB port on your computer．
Click Change to specify the destination
3
you wish the application to be located
or leave it in the default location. Click
Next to continue.
4 Click Install to begin the installation.
SIM/USIM Card
Micro SD Card
2
4
The installation process may take 1~2
5
minutes. Please wait.
The following screen will then appear.
6
Click Finish to complete the setup.
After installation, the
icon
your desktop. Double-
clicking the icon can
start the utility.
will appear on
