- Page 1 WNER’S PERATING ANUAL WP-42HD High-Definition LCD Monitor ™ with ’ ™ ORLD INEST HEATRE RODUCTS...
-
Page 3: One Year Limited Warranty
WHAT IS COVERED UNDER THE TERMS OF THIS LIMITED WARRANTY: SERVICE LABOR: Runco will pay for service labor by a Runco Authorized Service Center when needed as a result of a manufacturing defect for a period of one (1) year from the effective date of delivery to the end user. - Page 4 IMPORTANT – WARRANTY REGISTRATION: Please fill out and mail your warranty registration card. It is imperative that Runco knows how to reach you promptly if we should discover a safety problem or product update for which you must be notified.
- Page 5 ADDITIONAL INFORMATION: To locate the name and address of the nearest Runco Authorized Service Center, or for additional information about this Limited Warranty, please call or write: Attn: Customer Service Department RUNCO VIDEO-PRODUCT INFORMATION RETAIN THIS INFORMATION FOR YOUR RECORDS...
-
Page 6: Safety Precautions
The rear finned section around the cabinet functions as a heat sink, removing heat away from the monitor. The external surface of the cabinet (finned area) must not be covered or the airflow restricted in anyway by enclosing the LCD monitor. Runco WP-42HD Owner’s Operating Manual... - Page 7 Do not attempt to bypass the safety purpose of the grounding type plug. THIS UNIT IS NOT DISCONNECTED FROM THE MAINS UNLESS THE MAINS LEAD IS UNPLUGGED. THE INSTALLER MUST MAKE SURE THE WATERPROOF INLINE COUPLER IS EASILY ACCESSIBLE. Runco WP-42HD Owner’s Operating Manual...
- Page 8 For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG. For lamp specific disposal information check WWW.LAMPRECYCLE.ORG. Your Runco product is designed and manufactured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately.
- Page 9 2 below), royalty-free license to use the Software upon and with the Product. 2.You may not transfer any of your license rights in the Software without the prior written consent of Runco and if consent is provided then the Software shall only be transferred in conjunction with the transfer of the Product AND provided that the transferee has read and agreed to accept the terms and conditions of this license.
- Page 10 Runco shall be entitled to bring a claim in the courts of any jurisdiction. 2. This End-User License is governed by the laws of the State of California. The End-User and Runco agree that any action to enforce or interpret the terms of this End-User License shall be brought only in the appropriate state or federal court located in Los Angeles County, California.The End-User and Runco hereby submit to the exclusive jurisdiction and venue...
-
Page 11: Table Of Contents
Runco WP-42HD Owner’s Operating Manual ONE YEAR LIMITED WARRANTY ....... . .iii Safety Precautions . - Page 12 Notes: Runco WP-42HD Owner’s Operating Manual...
-
Page 13: Installation
Runco WP-42HD Owner’s Operating Manual DVI-D DVI-D 1. Installation Connections to the WP-42HD... - Page 14 11. AV2 Video Output AV2 OUT is to output the Y, Pb, Pr or RGB H/V video signal from the AV2 IN so that you can connect monitors with the use of a loop through function. Runco WP-42HD Owner’s Operating Manual...
-
Page 15: Rs-232 Controller Connection
PC or home theater control/automation system (if present) to the RS-232 port on the WP-42HD. For more information about using this connection, refer to Serial Communications on page 19. Runco WP-42HD Owner’s Operating Manual To PC or Control System... - Page 16 Installation Notes: Runco WP-42HD Owner’s Operating Manual...
-
Page 17: Operation
11. SURROUND Press to select the Surround mode (OFF, MID or MAX). 12. Press and hold for five seconds to access the Installation menu (refer to page 13). Runco WP-42HD Owner’s Operating Manual 2. Operation Remote Control ➤ Remote Control Operation... -
Page 18: Battery Installation
60Hz. To completely switch off the mains, or when the display unit is not to be used for an extended period of time, it is advisable to disconnect the power cord from the power outlet Runco WP-42HD Owner’s Operating Manual... -
Page 19: Controls And Indicators
To turn the monitor into standby mode, press the 4 button. The blue power indicator illuminates more brightly. To turn the monitor ON from standby mode, press any of the following buttons: 4, or 0 - 9 buttons. Runco WP-42HD Owner’s Operating Manual button at the Operation ➤ Controls and indicators... -
Page 20: Menu Operation
OFF / AV1-AV3 / RGB / DVI / PC Max Volume ON / OFF Winter Mode ON / OFF RC Inhibition ON / OFF Child Lock ON / OFF Address 000 ... 999 Baud Rate 9600 / 19200 Runco WP-42HD Owner’s Operating Manual... -
Page 21: Main Menu
Press the MENU button to return to Main Menu. These settings automatically store when you exit the menu. Press the MENU button again to exit the Main Menu. Runco WP-42HD Owner’s Operating Manual button and pressing the 1 button when... -
Page 22: Picture Menu (Pc)
Connect your PC to either PC-IN or RGBHV on the rear of the set. Then, select PC mode Picture Menu (PC) or AV2 (RGBHV) via the TV/b button on your remote control. The set will become a monitor for the PC. -
Page 23: Sound
Note remote control or by the standby switch 4 on the bottom of the LCD monitor, the timer settings will be cancelled. Runco WP-42HD Owner’s Operating Manual buttons, press Personal / Talk / Music / Normal OFF / Mid / Max... -
Page 24: Setting Menu (Pc)
Operation ➤ Setting Menu (PC) Runco WP-42HD Owner’s Operating Manual AV2 Setting: In setting menu, to select AV2 press the 6 button and set to Y,Pb,Pr or RGB, H/V depending on your external equipment. 1. Press the MENU button. Select Setting using the 5 or 6 button. Press the 1 button to enter. -
Page 25: Installation
RC Inhibition: You can prevent unwanted remote control operation by selecting RC Inhibition. When selected an inhibit symbol will appear on screen when a pressed on the remote control. Runco WP-42HD Owner’s Operating Manual / AV1-AV3 /RGB/ DVI/ PC ON/ OFF... - Page 26 Operation Runco WP-42HD Owner’s Operating Manual Select using the 5 or 6 button. Press the 2 or1 button to select ON or OFF. To re-instate RC operation, press and hold the green button on the remote control and select RC inhibition OFF Child Lock: You can prevent unwanted operation of the LCD monitor via the buttons on the bottom edge of the monitor.
-
Page 27: Screen Mode
■ Normal The correct ratio is maintained with black bars on the left and right. Runco WP-42HD Owner’s Operating Manual 14:9 16:9 Letterbox Video The height is The picture fills the The black bars top... - Page 28 Operation Notes: Runco WP-42HD Owner’s Operating Manual...
-
Page 29: Helpful Hints
POOR PICTURE, SOUND OK NO COLOUR, PICTURE OK REMOTE CONTROL DOES NOT WORK PICTURE OK, NO SOUND Runco WP-42HD Owner’s Operating Manual Solution • Check if monitor is plugged in. • Check monitor is not in standby mode • Adjust BRIGHTNESS/ contrast levels (too low). - Page 30 Helpful Hints Notes: Runco WP-42HD Owner’s Operating Manual...
-
Page 31: Serial Communications
Functional execution command: A001C05<CR> means address is 001 and the control command is C05. Status read command: A001CR0<CR> means address is 001 and command is CR0 Runco WP-42HD Owner’s Operating Manual 4. Serial Communications RS-232 Connection and Port Configuration Setting the Monitor... -
Page 32: Serial Command Syntax
Power Save ON CF PSAVE ON Power Save OFF CF PSAVE OFF Child Lock ON CF CLOK ON Child Lock OFF CF CLOK OFF RC Inhibition OFF CF DEA RMCY RC Inhibition ON CF DEA RMCN Description Runco WP-42HD Owner’s Operating Manual... - Page 33 CR WIDE Picture mode (Dynamic, Standard, Eco or Personal) CR PICTURE Signal existence (Signal/No Signal) CR SIGNAL Child Lock (On/Off) CR CHILD Power Save (On/Off) CR PSAVE Panel operating time CR TM Runco WP-42HD Owner’s Operating Manual Description Serial Communications...
- Page 34 Serial Communications Notes: Runco WP-42HD Owner’s Operating Manual...
-
Page 35: Specifications
FCC part15 Class B, UL Listed Limited Warranty: One (1) year parts and labor from the date of the delivery to the end user. Specifications are subject to change without notice. Runco WP-42HD Owner’s Operating Manual 5. Specifications WP-42HD Specifications... -
Page 36: Computer/Video Signal Support
SVGA 74.00 Mac. 60.00 XGA VESA 60Hz 70.00 XGA VESA 70Hz 75.00 XGA VESA 75Hz 54.58 58.20 58.30 60.02 72.00 74.92 75.70 75.08 MAC_Normal 19" 60.00 SXGA VESA 60Hz 75.025 SXGA VESA 75Hz 58.60 SXGA Runco WP-42HD Owner’s Operating Manual... - Page 37 Frequency (kHz) 720x480 15.735 720x576 15.625 720x480 31.25 720x576 31.25 1280x720 45.00 1280x720 37.50 1920x1080 33.75 1920x1080 28.13 Runco WP-42HD Owner’s Operating Manual Vertical Remark Frequency (Hz) 60.01 SXGA 59.98 SXGA 60.01 SXGA 60.18 SXGA 60.00 SXGA 67.19 SXGA 72.00 SXGA 76.107...
- Page 38 VGA VESA 60Hz 72.81 VGA VESA 72Hz VGA VESA 75Hz 66.6 Mac LC 13" 66.67 MAC_Normal 13" 56.25 SVGA VESA 56Hz 60.32 SVGA VESA 60Hz SVGA VESA 75Hz 59.94 480p 575p 720p-50Hz 720p-60Hz 1080i-50Hz 1080i-60Hz Runco WP-42HD Owner’s Operating Manual...
- Page 40 SERIAL NUMBER 020-0711-00 Rev. A October 2007 Runco International • 2900 Faber Street • Union City, CA 94587 • Ph (510) 324-7777 / (800) 23RUNCO / Fax (510) 324-9300 www.runco.com Part No. 1KA6P1P0390-A...
