JVC KD-R338 Instructions Manual

Hide thumbs Also See for KD-R338:
Table of Contents

Advertisement

Quick Links

Download this manual
KD-R338/KD-R330
CD RECEIVER
For installation and connections, refer to the separate manual.
INSTRUCTIONS
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet.
Retain this information
for future reference.
Model No.
Serial No.

Advertisement

Table of Contents
loading

Related Manuals for JVC KD-R338

Summary of Contents for JVC KD-R338

  • Page 1 KD-R338/KD-R330 CD RECEIVER For customer Use: Enter below the Model No. and Serial No. which are located on the top or For installation and connections, refer to the separate manual. bottom of the cabinet. Retain this information INSTRUCTIONS for future reference.
  • Page 2 – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2.

  • Page 3: Maintenance

    How to attach/detach the control Condensation : When the car is air- panel conditioned, moisture may collect on the laser lens. This may cause disc read errors. In this case, remove the disc and wait for the moisture to evaporate. Temperature inside the car : If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car...

  • Page 4: Canceling The Display Demonstration

    Canceling the display demonstration Turn on the power. Select <DEMO OFF>. [Hold] [Hold] (Initial setting) Finish the procedure. (Initial setting) Setting the clock Turn on the power. [Hold] [Hold] (Initial setting) Select <CLOCK>. Select <CLOCK SET>. Adjust the hour. (Initial setting) Adjust the minute.

  • Page 5: Preparing The Remote Controller

    Preparing the remote controller When you use the remote controller for the first Caution: time, pull out the insulation sheet. • Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. • Battery shall not be exposed to excessive heat Insulation sheet such as sunshine, fire, or the like.

  • Page 6: Basic Operations

    Basic operations Loading slot Control dial Display window Ejects the disc Remote sensor Front auxiliary input jack • DO NOT expose to bright sunlight. Detaches the panel When you press or hold the following button(s)... Remote Main unit General operation controller —...

  • Page 7: Listening To The Radio

    Listening to the radio • [Press] Searches for stations automatically. Ÿ • [Hold] Searches for stations manually. “M” flashes, then press the button ] “FM” or “AM” repeatedly. “ST” lights up when receiving an FM stereo broadcast with sufficient signal strength. Improving the FM reception Manual presetting (FM/AM) You can preset up to 18 stations for FM and 6...

  • Page 8: Listening To A Disc

    Listening to a disc Ÿ Playback starts automatically. ] “CD” All tracks will be played repeatedly until you change the source or eject the disc. Stopping playback and ejecting Selecting a track/folder from the list the disc If the ejected disc is not removed within 15 seconds, it is automatically inserted into the loading slot.

  • Page 9: Connecting The Other External Components

    Connecting the other external components You can connect an external component to the auxiliary input jack on the control panel (F-AUX) and/or on the rear side of the unit (R-AUX). Summary of using the external components through the auxiliary input jacks: Preparation Connecting Auxiliary...

  • Page 10: Selecting A Preset Sound Mode

    Selecting a preset sound mode You can select a preset sound mode suitable for the music genre. FLAT = NATURAL = DYNAMIC = VOCAL BOOST = ] <PRO EQ> ] <BASS/ MIDDLE/ BASS BOOST = USER = (back TREBLE> to the beginning) While listening, you can adjust the subwoofer and tone level of the selected sound mode.
  • Page 11 Menu item Selectable setting, [Initial: Underlined] DIMMER SET AUTO : Changes the display and button illumination between the Day/Night adjustments in <BRIGHTNESS> setting when you turn off/on the car headlights. * ON : Selects the Night adjustments in <BRIGHTNESS> setting for the display and button illumination.

  • Page 12: Additional Information

    Menu item Selectable setting, [Initial: Underlined] LOW POWER : VOLUME 00 – VOLUME 30 (Selects if the maximum power GAIN * of each speaker is less than 50 W to prevent damaging the speakers.) / HIGH POWER : VOLUME 00 – VOLUME 50 AREA US : When using in North/Central/South America.

  • Page 13: Troubleshooting

    UNIT” / “WARNING CHK WIRING THEN with insulating tape properly, then reset the unit. (page 3) RESET UNIT” appears on the display and no If the message does not disappear, consult your JVC car audio operations can be done. dealer or a company supplying kits.

  • Page 14: Using Bluetooth ® Devices

    Using Bluetooth ® devices For Bluetooth operations, it is required to connect the Bluetooth adapter, KS-BTA100 (not supplied) to the auxiliary input jack (R-AUX/BT ADAPTER) on the rear of the unit. (page 9) • For details, refer also to the instructions supplied with the Bluetooth adapter and the Bluetooth device.

  • Page 15: Specifications

    Microsoft and Windows Media are either Frequency Response : 40 Hz to 15 000 Hz registered trademarks or trademarks of Stereo Separation: 40 dB Microsoft Corporation in the United States AM Tuner : and/or other countries. Sensitivity/Selectivity : 20 μV/40 dB JVC Stereos Car Audio...
