  • Page 1 SYSTEM Video Entertainment System R6400V...
  • Page 2 All Rights Reserved Information in this document is subject to change without notice. Rosen Products LLC may have patents, patent applications, trademarks, copyrights or other intellectual property rights covering subject matter in this document. The furnishing of this document does not grant the use license to these patents, trademarks, copyrights, or other intellectual property.
  • Page 5 Never try to drive and view the screen. Keep the back of the driver's seat forward of the screen. If you have a question, please call the Rosen Tech Center at 1-888-883-2790.
  • Page 6 Depending on your type of vehicle, and the particular Auto Video™ System installed, the Auto Video™ screen will deploy and stow in one of the following ways: The push button on the overhead console releases the Auto Video™ screen just far enough so that it can easily be position for optimal viewing.

  • Page 7: Channel Up/Down

    The buttons located on the side of the screen perform many of the same functions as the system remote. By depressing any of these buttons once, the OSM displays the button’s function. Press again and the function is carried out. CHANNEL UP/DOWN Scrolls up and down preset TV channels or scrolls up and down TV channels (see...
  • Page 8 The status indicator light is located on the right side face of the viewing panel just under the word "POWER". This indicator will display green when the vehicle’s key is turned on. This indicates that the system is ready for operation. The video entertainment system includes a temperature sensor.
  • Page 10 System Remote Control OSM (on-screen menus)
  • Page 11 Video selection may be made by this remote control. The TV Tuner is accessed by remote for channel selection and for fine tuning. When your system is equipped with a Rosen video cassette player, the VCP will operate using the same system remote control.
  • Page 12 LCD POWER This button sends power to the flat panel display when pressed. It also turns off the power to the entire system. MUTE This button mutes audio to both the headphones and the factory sound system. AUDIO This button allows the sound of the video system to be heard through the vehicle speakers, the headphones, or both.
  • Page 13 The engineering that went into the Auto Video OSM makes it very unique and easy to use. The following steps will guide you through the OSM. Pressing the MENU button on the system remote will display the OSM. When in the AV1 or AV2 selection and you press MENU, the display looks like the illustration at right: PICTURE...
  • Page 14 Selecting PICTURE will display this sub-menu. You can scroll up or down to make your selection for adjustment. Brightness, color, tint and contrast are preset at the factory. There is a "Restore to Factory" selection under OPTIONS which will restore the factory settings. The PICTURE adjustments are displayed as follows: BRIGHTNESS ENTER...

  • Page 15: Audio Mode

    By selecting AUDIO, you can change settings that configure the tuner and initial speaker selection of your Auto Video system. PICTURE AUDIO MODE - configures the tuner to receive STEREO or SAP (second AUDIO audio program) broadcasts. This setting effects all channels. OPTIONS NOTE: Configuring your system to SAP will effect ALL TV channels.
  • Page 16 PICTURE AUDIO OPTIONS ENTER MENU TO EXIT Choosing OPTIONS - CONFIGURE provides setting that will configure the power mode. Your Auto Video system should be configured to the STANDBY powered mode. The STANDBY selection enables your Auto Video system components to be powered and available in a STANDBY mode when you turn the vehicle's ignition switch.
  • Page 17 PICTURE AUDIO OPTIONS ENTER MENU TO EXIT SAVE USER RESTORE: USER FACTORY ENTER MENU TO EXIT CONFIGURE PICTURE ENTER MENU TO EXIT Selecting OPTIONS - PICTURE allows you to either save or restore the picture adjustments you have made. To save your settings, select SAVE USER and press ENTER.
  • Page 18 Operation and features of the Rosen RVP9800 video cassette player...
  • Page 19 To load a VHS tape into the VCP, gently insert the cassette, label-side up, into the cassette compartment until it stops. The VCP will continue loading the tape and begin playing it automatically. A. POWER button: Press this button to turn the VCP on or off.
  • Page 20 E. PLAY button: Press this button to play a video tape. If a video tape is loaded, pressing this button will power the VCP. F. FF button: Press this button to fast forward the tape. You can view the tape in fast forward if the tape is playing.
  • Page 21 4-2 Wireless Headphones 4-3 Factory Sound System Adapter (System Audio Modulator)

  • Page 22: Fine Tuning

    Using the wireless radio frequency (RF) headphones allows some passengers to listen to the Auto Videosystem while others can listen to the radio. To select the wireless headphones, be sure the on/off switch is in the ‘on’ position and the volume is turned all the way down.
  • Page 23 When desired, Auto Video system sound can be enjoyed by all passengers in your vehicle through the factory radio sound system. Even though you cannot see the Rosen Audio Modulator because it is installed behind the dashboard, it enables the audio signal from the video source you select to work with your vehicle radio.
  • Page 24 TV Tuner OSM (On-Screen Menu) TV Tuner Remote Control Functions TV Antenna System...
  • Page 25 Pressing the MENU button on the system will display the OSM. If the system is in the TV mode and you press MENU, the display PICTURE looks like the diagram to the left. From here you can toggle the AUDIO position arrow up and down using the OPTIONS remote.
  • Page 26 PICTURE AUDIO OPTIONS TUNING ENTER MENU TO EXIT Choosing the OPTIONS menu (diagram 1, above) and moving into the CONFIGURE menu will allow you to set the SCAN TYPE to either RT SCAN (Real Time Scan), or PRE-SCAN. PWR MODE: RT SCAN sets the tuner to always scan to the next strongest signal INSTANT when tuning up or down.
  • Page 27 PICTURE AUDIO OPTIONS TUNING ENTER MENU TO EXIT Choosing the TUNING menu will display the AFC (Automatic Fine Tuning Control) screen. In this menu, you can fine tune with the you have selected on screen. The AFC will display OFF and a green right or left as you fine tune.
  • Page 28 The system remote control is the main control for the television tuner. Other than the two manual controls on the display for channel up and down, all other tuner functions are controlled by the system remote control. This section of the manual will explain the tuner control buttons.
  • Page 29 While in TV tuner mode and with the system configured to SCAN PRE-SCAN, this button will scan through all 69 channels and preset the strongest channels to memory. When the system is con-figuring to RT SCAN, this button will unlock all channels. (See 5-3 for SCAN TYPE) There are 10 selections on the remote with blue numbers NUMBERS...
  • Page 30 DISPLAY During the tuner mode, this button when pressed will display the TV channel while viewing the television. It will also exit the user out of the fine tuning OSM. The RECALL button should be thought RECALL of as a recall/memory button and not last display channel recall.
  • Page 31 Connections for Game Systems and Camcorders AC Power Inverter Additional Headphones...
  • Page 32 Connecting game systems or camcorders is as easy as matching the colors of the RCA plugs on the device to the colors on the INPUT jacks on the TV Tuner Interface. Yellow -> Yellow (Video) White -> White (Left Audio) ->...
  • Page 33 Specification: Most game systems require an inverter supplying a minimum of 140 watts output Some video game systems, camcorders, and other video devices require 120 VAC "household" current instead of the 12 VDC supplied by your vehicle. These Power Inverter devices require the use of an AC power inverter (not a converter) to change the vehicle’s 12 VDC to 120 VAC.
  • Page 34 Additional sets of wireless headphones are available by contacting your dealer/installer or by calling Rosen Products at 1 (800) 284-7677.
  • Page 39 Rosen's only obligations are those in the Rosen Standard Terms and Conditions of Sale for this product, and in no case will Rosen be liable for any incidental, indirect or consequential damages arising from the sale, resale, use or misuse of the product.

  • Page 40: Entertainment Systems

    E N T E R T A I N M E N T S Y S T E M S Manual Part Number 9100-0102-807...
