Cooper Lighting Quiet Ceiling Series QCT-1975BK Specification Sheet

DESCRIPTION:
Recessed downlight trimless fixture. 360
o o
rotational and 30 (+/- 15 ) angle adjusta-
bility with angle locking mechanism in
trim. Exclusive adjustable mud ring
accommodates 1/2", 5/8", 3/4" & 1"
ceilings.
ELECTRICAL:
120V input, 12V output. Junction box is
U.L. listed for through branch wiring.
CONSTRUCTION:
Housing and plaster frame: 18 gauge CRS
Trim ring, j-box and hanger assemblies:
16 gauge CRS.
SYSTEM PROTECTION:
Thermal protection provided to guard
against overheating and misuse of insu-
lation over and around fixture. Vent holes
in housing provide cooler operation.
Steel Safety
Cable
Adjustment
Locking Knob
4.00"
Dia.
3.00"
Dia.
Ball
Detent
Retainers
Item #
QCT-1975WH / QCT-900
QCT-1975BK / QCT-900
QCT-1975S / QCT-900
QCT-1975SS / QCT-900
QCT-1975PM / QCT-900
For 277 volt transformer add "277" to end of item #.
Suitable for Damp Location.
Type:
4" Adjustable Downlight Trimless Fixture
w/ Internal Specular Reflector
New Construction Housing - 4.75" Height
12V Bi-Pin Base MR16 Lamp 75 Watts Max.
o
Hanger Bars extend from
14.00" to 25.25" max.
Internal rotation
ring with locking
adjustment.
Provides 360º
rotation and
secures original
trim position after
relamping or
maintenance.
Lamp holder can accept
up to three (3) optical
accessories
30º (+/- 15º) locking
angle adjustment
Description
Quiet Ceiling Series Adjustable Downlight Trimless Fixture
with New Construction Housing w/ Magnetic Transformer
For 277 Volt Transformer, add '277' to the end of the catalog number.
RSA LIGHTING 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: 818-349-3031 • www.rsalighting.com
©2004 RSA Lighting All Rights Reserved • Specifications subject to change without notice.
Project:
Mud Ring adjusts in plaster
frame to accommodate
1/2", 5/8", 3/4" & 1" ceilings.
Perforated flap for secure
drywall installation
7.25"
4.63"
Housing adjusts in
plaster frame to accommodate
1/2", 5/8", 3/4" & 1" ceilings.
QCT-1975WH QCT-1975BK
QCT-1975S QCT-1975SS
QCT-1975PM
w/ QCT-900 Housing
Mudding Compound
Ceiling mudding compound
is applied right to the edge
of the fixture.
Magnetic
Transformer
13.25"
Butterfly Brackets
8.22" for commercial
installations
Finish Voltage / Wattage
White 12V / 75W Max.
Black
Silver
Stainless Steel
Primer
REV 062904
QC13
