Getting Started; Knowing Your Camcorder Parts - AIPTEK Action R-HDV21X User Manual

Getting Started

Knowing your camcorder parts

Speaker
Battery cover
MODE button
LCD monitor
Previous button/
Fast backward button
Play/Pause button
Next button/
Fast forward button
Macro mode
switch
Flash switch
OK key/
Joystick 5-way
For select model only. If your camera only indicates " AV OUT", it does not
support "AV IN" function.
Flash strobe
White balance switch
LED lights switch
Microphone
Lens
LED lights
Strap hook
Bottom view
Power button
Tripod socket
SD card slot
(inside the battery cover)
Status LED (left) /
Charging LED (right)
MENU button
Shutter button
Zoom (in/out) button
Record button
AV IN ( ) /OUT connector
/Earphone
USB connector *
HD OUT *
* inside the cover
